SpinPoint M40 Series Model: M P 0 3 0 2 H M P 0 4 0 2 H M P 0 6 0 3 H M P 0 8 0 4 H manual HARD DISK DRIVE service H a r d D i s k D r i v e Contents 1. -
Page 2: Specification Summary
SAMSUNG HARD DISK DRIVE 1. Specification Summary Items Specification Remarks DC +5V / ± 5% Voltage Requirement Interface ATA - 6 MP0302H(2CH) MP0402H(2CH) UDMA133supporting Capacity MP0603H(3CH) (UDMA100 Default) MP0804H(4CH) MP0302H(1Disk/2Head) MP0402H(1Disk/2Head) Disk / Head MP0603H(2Disk/3Head) MP0804H(2Disk/4Head) S.M.A.R.T Compliant Features Buffer size 8 Mbytes... -
Page 3: Block Diagram Of Hdd
SAMSUNG HARD DISK DRIVE Block Diagram of HDD PREAMP & READ/WRITE WRITE DRIVER CHANNEL IC Marvell Marvell 88C6590 G214M CUSTOMIZED IC including SPINDLE MOTOR & AT CONTROLLER, EMBEDDED ACTUATOR COMBO SERVO CONTROLLER, DSP DRIVER PROCESSOR, ADC & DAC TLS2282 88I6522-BCT... -
Page 4: Connector & Jumper Pin Assignments
SAMSUNG HARD DISK DRIVE 3. Connector / Jumper Pin Assignment ● 40 Pin I/O Connector Interface Signals Number Signal Number Signal Remark RESET- DB10 DB11 DB12 DB13 DB14 DB15 Key Pin DMARQ DIOW - : STOP DIOR - : HDMARDY... - Page 5 SAMSUNG HARD DISK DRIVE ⓒ ⓐ ⓒ ⓐ ⓒ ⓐ ⓓ ⓑ ⓓ ⓑ ⓓ ⓑ MASTER CABLE SLAVE (1DRIVE) SELECT <MP0302H, MP0402H, MP0603H, MP0804H 점퍼 핀 Setting 시 > ● BIOS Setup Parameter 모 델 구 분 SIZE Number of Logical...
-
Page 6: Exploded View
SAMSUNG HARD DISK DRIVE 4. Exploded View SpinPoint M40 Series... - Page 7 SAMSUNG HARD DISK DRIVE << Major components of HDD >> HDD is formed by major components as follows: Base, Cover, ARM(E-Block), Latch, Crash Stop, Pivot Bearing, Breather Filter, Window Clock, Window Push Pin, Jump Pin, Spindle Motor, Actuator, Magnetic Head, Magnetic Disk, PCBA 1 Base Base could be a basic frames for HDD assembly.
- Page 8 SAMSUNG HARD DISK DRIVE 5 Crash Stop Crash stop is made of elastic material and weaken a impact of actuator in emergency condition, head getting out of data zone when it move to parking zone or seek. 6 Pivot Bearing Pivot bearing is a roll bearing fixed the center of gyration of ARM.
- Page 9 SAMSUNG HARD DISK DRIVE element (these are sensitive to voltage change). The magnetic disk of hard disk is running by DC Brushless direct drive motor directly. Brush has long life and high reliability because it doesn't have belt. Recently we use flat motor to be adopted to the request of minimizing.
- Page 10 SAMSUNG HARD DISK DRIVE 16. Ramp 2.5 inch drives usually adopt Load /Unload ramp system to prevent head slap for disk basically. Head is putted safely on the ramp which is located off disk-outer diameter at non-operating It makes head avoid to slap disk during the external shock. and play a major role to move to disk smoothly at loading and move smoothly and safely to itself to park head at power-off.
-
Page 11: Maintenance Cylinder Configuration
SAMSUNG HARD DISK DRIVE - ROM: Checking HDD basic function and management basic spec. 5.Maintenance Cylinder Configuration Contents Disk Location sector size Header 20,0,1 4,0,581 SPN_MNTR LATCHFRC 4,0,4 SPESB0 4,0,601 SPES SPESB1 4,0,603 SPES SPESB2 4,0,605 SPES SPESB3 4,0,607 SPES... - Page 12 SAMSUNG HARD DISK DRIVE Contents Disk Location sector size Header UINTABLE 0,0,197 UNITABLE SETMAX 0,0,233 SETMAX WB_RLT 0,1,5 WB_RLT GAIN 0,0,691 GAIN WKHEAD 4,0,72 WK_HEAD 4,0,77 4,0,533 SPEST 20,0,11 SPES SKTIME 0,0,11 SEEKTIME TSTPICSC 4,0,544 TSTPICSC 4,0,544 SpinPoint M40 Series...
-
Page 13: How To Use Hutil Program
SAMSUNG HARD DISK DRIVE 7. How to use HUTIL Program 1) Before you start HUTIL support from Voyager11P to VERNA series.(HUTIL 1.09 version) (HUTIL has been upgrading constantly whenever new model comes out.) - Preparation before use Diskette or HDD containing HUTIL.EXE should be boot-up to MS-DOS mode,that is, should be contained IO.SYS, MSDOS.SYS,COMMAND.COM (IO.SYS, MSDOS.SYS: hidden file). - Page 14 SAMSUNG HARD DISK DRIVE which defect occurred. ※ This function is applying to Voyager10,11,11P currently and this function can't show the defects during process. 3) The others - Difference of read test and auto test (Difference from HUTIL user, refer to supplement ) ①...
- Page 15 SAMSUNG HARD DISK DRIVE cylinder. (Check 30 times per 1 cylinder) → Remark "failure" when error occurred more than 3 times per 1 cylinder. ③ Maintenance Cylinder Check(M/C): Read Maintenance cylinder from the number of 0 to the last. → In case of "MC", remark "failure" when error happened in one time.
- Page 16 SAMSUNG HARD DISK DRIVE ③ Example for Head related failure < Error List > HD(Head) Error List ECC Err Data Am Not Found ECC Err ECC Err ECC Err ECC Err ECC Err < Error List > HD(Head) Error ECC Err...
- Page 17 SAMSUNG HARD DISK DRIVE read the edge of cylinder again then it is head failure if error still be continuous at the particular head and disk failure in sporadic case. And failure occurred with changing cylinder and head continuously, it is called assembly failure in inner HDA or caused from other problem.
- Page 18 SAMSUNG HARD DISK DRIVE Codes marked as red among broken codes are displaying automatically in HUTIL Program HUTIL Test Flow/Error Label error [AJ44] Label damaged [AJ45] PCBA ERROR N> Appearance PCBA burnt [AJ12] HDA ERROR PCBA ding,break [AJ13] HDA ding,scratch...
- Page 19 SAMSUNG HARD DISK DRIVE ※ Explanation of terms for HDD repairing CONTENTS SYMPTOMS Motor doesn't drive. When HDD power on, LED is in on and motor Led is still on/off mode when power on NOT READY start to drive. At this time head make...
-
Page 20: How To Progress Burn-In Test
SAMSUNG HARD DISK DRIVE 7. How to progress Burn-In Test 1) Summary of B/I Test Progress defect detection and reliability test of HDD according to program written in maintenance/cylinder in temperature 40±5℃, humidity 50± 10% stress condition. 2) Progress B/I Test ①... - Page 21 SAMSUNG HARD DISK DRIVE 5) Failure status and repairing Failure state State Method Remarks Jumper pin -LED off after -Check the location of jumper pin ●●DXX:All sorts of jumper connection ready when drive and execute to change. ●●DCF:Size operation pin failure is connected.(Not...
- Page 22 SAMSUNG HARD DISK DRIVE 8. Caution ※ Hard disks are very fragile electro-mechanical devices, which are very sensitive to external shock and vibration, therefore be careful when you use not to be impacted and broken by static electricity. 1) Handling Damage example from impact ①...
- Page 23 SAMSUNG HARD DISK DRIVE 2) Damage example for static electricity ① Man is easily charged with electricity so if we handle PCBA of HDD, the high-voltage affect on IC or circuit and this become a failure cause. 3) Unconsciousness characteristic of product ①...
- Page 24 SAMSUNG HARD DISK DRIVE . The basic information related HDD Attachment 1 ※ The basic information of HDD 1) The logical elements constituted hard disk ① Track: The data inputted by computer was written at tracks on disk. The tracks, in spite of invisible,are the concentric circles from the center of disk to the outside.
- Page 25 SAMSUNG HARD DISK DRIVE 2) The logical mechanism of hard disk Hard disk consists of boot record, FAT, root directory, data field. ① Boot Record: Boot record is consists of sector 1, track 0, side 0. Boot record is the one of most important parts. It has some information about the physical structure of disk.
- Page 26 SAMSUNG HARD DISK DRIVE ⓐ DOS PARTITION : This is to dos as system disk is to floppy disk and dos is run by this partition. ⓑ EXTENDED DOS PARTITION : The rest region of the disk was occupied by dos partition.
- Page 27 SAMSUNG HARD DISK DRIVE ⑬ ECC On-the-Fly: A region isn't able to read exist in media. When we find defect like this in manufacturing process, we replace with the normal region. Thus we can supply perfect drive to user. Defect magnet is a method can arrange the defects in read/write from the replaced sector.
- Page 28 SAMSUNG HARD DISK DRIVE 2. Explanation of HDD terms Attachment Access Read, write, or update inforamtion on some storage medium such as a disk. The interval between the time a request for data is made by the system and the time the data Access time is available from the drive.Access time includes the actual seek time, rotational latency and...
- Page 29 SAMSUNG HARD DISK DRIVE Abbreviation of pivot bearing, Mediator of Arm and Base which is located in the center of ARM BEARING and it can rotate smoothly. Bezel A plastic panel that extends the face of a drive so that it covers a computer's drive bay opening.
- Page 30 SAMSUNG HARD DISK DRIVE Data is recorded on lots of circle in media in HDD, we call these circles track.. We record data at both sides of media and HDD has many media layers. so it has several tracks which have Cylinder/Trac the same radius, we call this concentric circle collection of track Cylinder.
- Page 31 Height more specified mechanical design. Form factor Industrial specification decided diameter of Disk. 3.5", 2.5" in case of Samsung. Recording the particular signal to divide track and sector and this information should be recorded Format on disk in first before user want to store data. Be careful because formatting erase all recorded information.
- Page 32 SAMSUNG HARD DISK DRIVE Hard Disk Drive, memory device by transferring data to permanent magnetic field rather than digital pulse. It organized HDA and PCBA. Head Read/write data on disk directly. (MIG, Thin film, MR,GMR) The damages of read/write and media cause a sudden contact between head and disk surface, Head Crash they are also occurred because of dust,particles or other contamination within HDA.
- Page 33 SAMSUNG HARD DISK DRIVE LBA mode Logical block allocation. DOS mode to resolve 528MB capacity restriction. Light Emitting Diode. Used for signal light to all kind of electric containing computer. Low profile One of standard height of HDD, the real height is 1 inch.
- Page 34 SAMSUNG HARD DISK DRIVE Time to perform the real order for controller, host adaptor and drive. The faster overhead is, Overhead the faster performing time. Overwrite Recorded data erased by overlapping the existing data. Parking = Landing Zone Zone When we use one HDD for multi ones dividing section logically, every memory section is Partition partition, For example, 2.5GB HDD can be used for one 2.1GB computer and one 400MB.
- Page 35 SAMSUNG HARD DISK DRIVE RETAINER Component could fix bearing when inserted to ARM. RING Encoding method "run length limited data" to magnetic pulse. It can store data 50% more than MFM(Modified Frequency Modulation) method. Return Material Authorization Searching only memory. memory would not erase during off, so we use this to program or data need not change in PC.
- Page 36 SAMSUNG HARD DISK DRIVE Transfer rate Data transferring speed among PC and other devices of HDD. The existing thin film head have 2 ABS and adding one more ABS, head is designed to be Tri-pad head profitable to low flying height. Produced by SAE, ReadRite company.
- Page 37 SAMSUNG HARD DISK DRIVE Attachment3. Q&A ※ Customer's Q&A 1) What is "Bad Sector"? Bad sector is divided physical Bad sector(Hard defect) and logical Bad sector(Soft defect). ① Physical Bad sector Visual defect occur in the surface of disk where is recorded data, it contain the minute defect could checking with electric microscope.
- Page 38 SAMSUNG HARD DISK DRIVE mode, and extend capacity by raising the number of cylinder. Currently most of hard disk is applied to LBA mode, so it set as LBA or AUTO in BIOS set-up. 4) PC is downed with the message of "Stack Over Flow" while HDD running or can't recognize HDD.
