Environmentally processed active studio monitor (14 pages)
Summary of Contents for YORKVILLE U15P
Page 1
SERVICE MANUAL MODEL TYPE: YS1042 U15P WEB ACCESS: http://www.yorkville.com WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920...
IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance.
Page 3
AP800 Parts List 7/7/2009 YS # Description Qty. YS # Description Qty. YS # Description Qty. YS # Description Qty. 5906 RED 3MM LED 1V9 20MA.4SPCER T&R 5903 12000U 35V 20%CAP RAD 25X45MM ELS 4604 1/4W 33R2 1% T&R RES 8847 1/4-20 X 1 1/4 FLAT PH MS JS500 6408 GRN 3MM LED 1V9 5MA FROSTED...
Page 4
Level Enclosure Program Delay Settings Select 0, 2, 3, 8 ms Fixed Time Align Delay Block-Diagram-U15P-1v0.ai...
Page 7
put goop on Q3T put goop on Q7T put goop on Q3M put goop on Q7M TO92 MJF15030 MJL21193 MJL21194 MJF15031 TO92 MJF15030 MJL21193 MJL21194 MJF15031 BASE EMIT BASE EMIT BASE EMIT BASE EMIT Q12T Q12M Q13M 120R 120R MPSA56 MPSA56 Q13T R15T...
Page 8
U4:A MINI 4148 4K99 470P TL072 1/4W R130 1/4W TL072 MINI 10K0 MINI 200V R123 TL072 R128 1/4W TL072 U7:C U7:B 1/4W 10K0 4148 MINI 4K99 U4:C U7:A MINI R129 1/4W U4:B 10K0 100P 100V MINI MINI 1/4W MINI MINI 1/4W 1/4W W40:A...
Page 11
DON'T PLACE COMPONENTS HERE Pcb Mech M1234 V4.00 ETCH BlankSize - 18000x9000 CHASSIS SCREWS BRACE TOP OF BOARD ETCH Into Wave GUIDE GUIDE HERE 2 oz copper Tweeter Out W62_ W57_ R T V Pin 1 3903 3903 Set P1 for 8mv PCB CONN 4 CIR BOTTOM .156 PCB CONN 4 CIR BOTTOM .156 BAV21...
SEE LAYOUT DIAGRAM M1234 U15P PRODUCTION NOTES Board Assembly 1 - INSERT #8829 THROUGH THE TWO TOOLING HOLES ON THE HEATSPREADER 2 - INSERT #8741 THROUGH THE FOUR CORNERS OF THE HEATSINK AND ADD For two .081" heatsinks #8701 NUTS ON PCB SIDE 3 - MOUNT Q12,Q13,Q26,Q27 SCREWS FROM THE TOP 2 of 8761 TO3 device...
SEE LAYOUT DIAGRAM M1234 Database History M1234 Pending List MODEL(S):- MODEL(S):- U15P U15P DATE VER# DESCRIPTION OF CHANGE DATE VER# DESCRIPTION OF CHANGE 13SEPT2005 R3 2006 --> 4688 14SEPT2005 Added CONHOLE to chassis for GND 31OCT2005 Modified XFMR colours 8NOV2005 Q14,15,24,25 from 3205 (#6954) to 2910 (#6966) 9NOV2005 Removed X33, changed X6,7...
Page 19
SEE LAYOUT DIAGRAM PRODUCTION NOTES M1235 Database History MODEL(S):- U15P ------------------------------------------- DATE VER# DESCRIPTION OF CHANGE 1. Do not stuff (DNS) Q9 when U21 is a 2FEB2006 Updated ribbons, move parts under encoder legs, fixed output stages, fixed input limiter Updated diode packages to SOD80, change R133 100k->10k CS4362.
Page 20
TRANSFORMER WIRED FOR 245 E TRANS. PRIMARY WIRES...
Page 21
TRANSFORMER WIRED FOR TRANS. PRIMARY WIRES...
