- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 935936 2PC NESTING TABLE REVISION 0 : 06/11/2020 REVISION 1 : 12/15/2022 PAGE 1 OF 8 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
935936 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. -
Page 3: Hardware Identification
935936 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION PARTS IDENTIFICATION SMALL BOTTOM FRAME SMALL CROSSBAR 3PCS HARDWARE IDENTIFICATION SHORT BOLT SUCTION CUP 12PCS 6PCS (1/4" x 12mm GD) ∅ 12mm) ALLEN WRENCH LONG BOLT 6PCS (4mm) (1/4" x 28mm GD) LEVELER 8PCS (1/4"... - Page 4 935936 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 4 OF 8 COASTERFURNITURE.COM...
- Page 5 935936 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 8 COASTERFURNITURE.COM...
- Page 6 935936 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 PAGE 6 OF 8 COASTERFURNITURE.COM...
- Page 7 935936 ITEM: ASSEMBLY INSTRUCTIONS STEP 7 STEP 8 COMPLETE PAGE 7 OF 8 COASTERFURNITURE.COM...
- Page 8 935936 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 508 DIA X 578 H (MM) Product Size : 349 DIA X 432 H (MM) Product Size : 20" DIA X 22.75" Product Size : 13.75" DIA X 17" 20" 13.75" Note : Dimension tolerance ±5% PAGE 8 OF 8 COASTERFURNITURE.COM...
