Tektite Kubota KuL3902-001 ROPS Cab Installation Manual

Rops cab is designed and built to fit: kubota l3902 / l3302 / l2502.
Hide thumbs

Advertisement

Quick Links

Download this manual
March 2025
Kubota L3902 Installation Manual
Kubota L3902 ROPS Cab
* Shown with optional equipment *
Kubota KuL3902-001 ROPS Cab
This ROPS cab is designed and built to fit:
Kubota L3902 / L3302 / L2502.
Designed and built by:
Tektite Manufacturing Inc:
P.O. Box 639, 427 Buffalo Street
Winkler, MB, Canada
R6W 4A8
PH: 204-331-3463
sales@tektite.ca
One-year standard product warranty provided by Tektite Manufacturing Inc.
www.tektite.ca
/
www.tektitecabs.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Kubota KuL3902-001 ROPS Cab and is the answer not in the manual?

Questions and answers

Related Manuals for Tektite Kubota KuL3902-001 ROPS Cab

Summary of Contents for Tektite Kubota KuL3902-001 ROPS Cab

  • Page 1 This ROPS cab is designed and built to fit: Kubota L3902 / L3302 / L2502. Designed and built by: Tektite Manufacturing Inc: P.O. Box 639, 427 Buffalo Street Winkler, MB, Canada R6W 4A8 PH: 204-331-3463 sales@tektite.ca One-year standard product warranty provided by Tektite Manufacturing Inc. www.tektite.ca www.tektitecabs.com...
  • Page 2 March 2025 Kubota L3902 Installation Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 3 Kubota L3902 Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota L3902 ROPS Cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of protection.
  • Page 4 March 2025 Kubota L3902 Installation Manual Parts List Standard Cab: Description Front Bracket, LEFT Front Bracket RIGHT Nut, Flange, 5/8”, Gr. 8, YD Washer, Flat, ¼” Structural, YD Isolator, Rubber (pre-installed) Bolt, Hex, 5/8” x 3”, Gr. 8, YD Under Seat Shield (pre-upholstered) Bolt, Hex, ½”...
  • Page 5 March 2025 Kubota L3902 Installation Manual...
  • Page 6 March 2025 Kubota L3902 Installation Manual Standard Cab Installation Instructions: Prior to starting, park tractor in a well-ventilated location, lower all tractor attachments. Remove quick-attach portion of loader to make installation a little easier. If there is no loader present, use provided no-loader spacers and bolts provided. •...
  • Page 7 March 2025 Kubota L3902 Installation Manual • Move to the right front loader mount. Remove the top two fasteners, and the bottom rearmost bolt. • Take the right front bracket and position over the right front loader sub-frame mount plate. Re-use the factory bolts and loosely attach the bracket to the cab, for now. •...
  • Page 8 March 2025 Kubota L3902 Installation Manual • Place the seat and seat tracks back onto the tractor, and re-attach with factory hardware.
  • Page 9 March 2025 Kubota L3902 Installation Manual • Remove the two cab doors by un-hooking the gas shock at the ball stud mounted to the door. To remove the gas shock on the left cab door, slide a flat screwdriver underneath the small clip on the end cap that must be pulled UP order to pop the shock off the ball stud.
  • Page 10 March 2025 Kubota L3902 Installation Manual • Take the right lower front shield and position on the inside of the cab frame and against the tractor. Use the provided ¼” x ¾” flange bolts and fasten shield into place.
  • Page 11 March 2025 Kubota L3902 Installation Manual • Take the provided 1” x 1” NDA-X and cut short pieces to install in the openings between the loader mount, the hood shield, and under the loader valve. • Route the wire harness to the left side of the engine. Connect the heavy red wire to constant power on the alternator.
  • Page 12 March 2025 Kubota L3902 Installation Manual • Connect each end to the heater with the provided hose clamps. • Drain the engine coolant. • Take the elbow fitting and install onto rad hose coupler provided. Use Teflon tape on the threads of the fitting to prevent water leaks. •...
  • Page 13 March 2025 Kubota L3902 Installation Manual • Un-bolt alternator tensioner and let alternator hang down as far as possible. • Remove the thermostat sensor adaptor from the engine block. • Insert the provided 12mm sensor tee fitting into engine block. •...
  • Page 14 March 2025 Kubota L3902 Installation Manual • Route the heater hoses from the cab forward into the engine bay. Use provided zip ties to secure into place. Keep away from hot components and moving parts. • Cut hose. Connect heater hose to each fitting, securing into place with provided hose clamps.
  • Page 15 This ROPS cab is designed and built to fit: Kubota L3902 / L3302 / L2502. Designed and built by: Tektite Manufacturing Inc: P.O. Box 639, 427 Buffalo Street Winkler, MB, Canada R6W 4A8 PH: 204-331-3463 parts@tektite.ca One-year standard product warranty provided by Tektite Manufacturing Inc. www.tektite.ca www.tektitecabs.com...
  • Page 16 March 2025 Kubota L3902 Operator Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.

  • Page 17: Safety Precautions

    “as is” basis; c) wiper blades, light bulbs, fuses, clear vinyl or other consumables; d) glass where the point of failure has not been preserved intact and delivered to Tektite for analysis of the cause of the failure;...
  • Page 18 March 2025 Kubota L3902 Operator Manual Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS. Danger: Indicates an immediate hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 19 March 2025 Kubota L3902 Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the tractor. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use. 3.
  • Page 20 March 2025 Kubota L3902 Operator Manual Safe Operation on Rough Terrain 1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns. 2. Always drive slowly enough over rough ground or obstructions. Drive at speeds slows enough to ensure your safety.
  • Page 21 3. New ROPS decals and tractor decals are available from your tractor dealer. ROPS Safety 1. Install the ROPS in accordance with Tektite mounting instructions. Failure to do so may affect the ROPS ability to withstand a roll over. 2. If the ROPS is subjected to alteration, structural damage or involved in an over turn accident, the entire structure must be replaced.
  • Page 22 March 2025 Kubota L3902 Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
  • Page 23 DO NOT leave options activated when tractor is not running as battery run down can occur. Please note: Tektite does have a key switch power option to provide maximum protection against accidental battery rundown and circuit overload. A relay is ignition activated and prevents the operator from accidentally leaving fan motors, lights on after turning the tractor off and leaving for the day.
  • Page 24 Kubota L3902 Operator Manual After your ROPS Cab has been installed: Before starting a tractor equipped with a Tektite ROPS cab: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can cause operator interference which could lead to bodily injury and/or damage the machine.
  • Page 25 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-14 Daryl Furkalo...

  • Page 26: Windshield Assembly

    Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-13_OP Daryl Furkalo...
  • Page 27 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-12_OP Daryl Furkalo...
  • Page 28 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-07R_OP Daryl Furkalo...
  • Page 29 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-07_OP Daryl Furkalo...
  • Page 30 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-06R_OP Daryl Furkalo...
  • Page 31 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality L3902-ASM-06_OP Daryl Furkalo...
  • Page 32 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality TEKT-ASM-088_OP Daryl Furkalo...
