Tektite Massey Ferguson 1800E ROPS Cab Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual
Massey Ferguson 1800E ROPS Cab
Note: Cab may be shown with optional accessories.
Massey Ferguson MF1800E-01 ROPS Cab.
This ROPS cab is designed and built to fit:
Massey Ferguson 1825E, 1835E and 1840E tractors.
Designed and built by:
Tektite Manufacturing Inc:
P.O. Box 639 - 427 Buffalo Street
Winkler, MB, Canada
R6W 4A8
PH: 204-331-3463
parts@tektite.ca
One-year standard product warranty provided by Tektite Manufacturing Inc.
www.tektite.ca
/
www.tektitecabs.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Massey Ferguson 1800E ROPS Cab and is the answer not in the manual?

Questions and answers

Related Manuals for Tektite Massey Ferguson 1800E ROPS Cab

Summary of Contents for Tektite Massey Ferguson 1800E ROPS Cab

  • Page 1 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual Massey Ferguson 1800E ROPS Cab Note: Cab may be shown with optional accessories. Massey Ferguson MF1800E-01 ROPS Cab. This ROPS cab is designed and built to fit: Massey Ferguson 1825E, 1835E and 1840E tractors.
  • Page 2 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 3 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Massey Ferguson 1800E ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of protection.
  • Page 4 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual Parts List Standard Cab: Mounting Parts Bag: Description Flange Bolt, 1/4" x 3/4", YD Flange Nut, ¼”, YD Bolt, Hex, 5/8” x 3”, Gr. 8, YD Washer, Flat, ¼” thick Nut, Flange, 5/8”, Gr. 8, YD Bolt, Hex, ½”...
  • Page 5 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual...
  • Page 6 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual Standard Cab Installation Instructions: Prior to starting, park tractor in a well-ventilated location, lower all tractor attachments. • Disconnect tractor battery. • Remove the front left and right lower cab shields from cab. Save fasteners for re- installation once cab is on tractor.
  • Page 7 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Re-install the seat mount bracket and re-connect seat harness underneath the seat plate. • Take the left front mounting bracket. Remove the four fasteners shown below.
  • Page 8 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Position the left front bracket into place and using factory bolts, loosely bolt bracket into place.
  • Page 9 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Take the right front mounting bracket. Remove the four fasteners shown below. The hydraulic fitting shown may need to be rotated slightly to provide clearance. • Position the front bracket into place, re-use factory bolts and loosely fasten bracket into...
  • Page 10 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Un-bolt the loader hydraulic valve mount bracket from the loader. • Un-bolt the loader valve from the valve mount bracket and position down onto tractor until cab is installed. • Remove the upper hoop of the 2-post ROPS.
  • Page 11 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Take the clevis pin and re-install the seat onto the tractor.
  • Page 12 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Return to the cab in order to install cab lift bolts. • To remove the doors, the gas shock must be released from the pin. Use a flat screwdriver underneath the small clip on the end cap that must be pulled UP to pop the shock off the ball stud.
  • Page 13 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Once all FOUR isolators are started, you can apply torque to the fasteners. Tighten isolators first, 205 ft-lbs, front brackets last, same torque. • Disconnect the hoist from chain/lift strap and remove from the cab lift bolts.
  • Page 14 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Take the right front lower cab shield and re-install onto cab. Position on outside of the cab and fasten into place with original bolts and nuts.
  • Page 15 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Route the main power harness toward the engine bay from the cab A-post. Connect the black wire to the battery negative terminal. Use the provided ¼” loop, shorten wire if necessary, then solder on loop.
  • Page 16 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Locate the coolant bypass hose and remove.
  • Page 17 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Route the heater hoses into the engine bay, keeping away from hot surfaces and moving components. Route to the top fitting location first, cut hose and connect to open port with provided HS-6 hose clamp.
  • Page 18 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Using the factory hardware, bolt the loader valve to the mount plate on the cab.
  • Page 19 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Take the left cab floormat and position onto the left floorboard of the tractor. Slide around pedals ensuring there is no interference with pedal range of motion. necessary, cut floormat if there is interference.
  • Page 20 March 2025 Massey Ferguson 1800E ROPS Cab Installation Manual • Take the right cab floormat and position onto the right floorboard of the tractor. Position around hydrostatic pedal, ensuring the pedals have full range of motion. If necessary, cut down floormat to remove interference.
  • Page 21 Massey Ferguson 1825E, 1835E and 1840E tractors. Designed and built by: Tektite Manufacturing Inc: P.O. Box 639 - 427 Buffalo Street Winkler, MB, Canada R6W 4A8 PH: 204-331-3463 parts@tektite.ca One-year standard product warranty provided by Tektite Manufacturing Inc. www.tektite.ca www.tektitecabs.com...
  • Page 22 Massey Ferguson 1800E ROPS Cab Operator Manual March 2025 DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW. 1) Always wear personal protective equipment. 2) A minimum of two people is necessary to safely install the cab. 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 23 “as is” basis; c) wiper blades, light bulbs, fuses, clear vinyl or other consumables; d) glass where the point of failure has not been preserved intact and delivered to Tektite for analysis of the cause of the failure;...

  • Page 24: Safety Precautions

    Massey Ferguson 1800E ROPS Cab Operator Manual March 2025 Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.
  • Page 25 Massey Ferguson 1800E ROPS Cab Operator Manual March 2025 General Safety 1. Never let an unqualified or untrained driver operate the tractor. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
  • Page 26 Massey Ferguson 1800E ROPS Cab Operator Manual March 2025 Safe Operation on Rough Terrain 1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
  • Page 27 3. New ROPS decals and tractor decals are available from your tractor dealer. ROPS Safety 1. Install the ROPS in accordance with Tektite mounting instructions. Failure to do so may affect the ROPS ability to withstand a roll over. 2. If the ROPS is subjected to alteration, structural damage or involved in an over turn accident, the entire structure must be replaced.
  • Page 28 Massey Ferguson 1800E ROPS Cab Operator Manual March 2025 Operating Instructions Important The following section locates, identifies, and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
  • Page 29 DO NOT leave options activated when tractor is not running as battery run down can occur. Please note: Tektite does have a key switch power option to provide maximum protection against accidental battery rundown and circuit overload. A relay is ignition activated and prevents the operator from accidentally leaving fan motors, lights on after turning the tractor off and leaving for the day.
  • Page 30 March 2025 After your ROPS Cab has been installed: Before starting a tractor equipped with a Tektite ROPS cab: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can cause operator interference which could lead to bodily injury and/or damage the machine.
  • Page 31 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality TEKT-ASM-088_OP Daryl Furkalo...
  • Page 32 Daryl Furkalo 2018-10-01 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 33 Daryl Furkalo 2018-10-01 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 34 Daryl Furkalo 2018-10-02 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 35 Daryl Furkalo 2018-10-02 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 36 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality MF1726E-ASM-11_OP Daryl Furkalo...
  • Page 37 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality MF1726E-ASM-12_OP Daryl Furkalo...
  • Page 38 Daryl Furkalo 2018-10-02 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 39 Daryl Furkalo 2018-10-02 transmitted. The material remains the property of specified Tektite and shall be returned upon request. The Checked By: Date: Size: material may not be reproduced or disclosed to third X.X =...
  • Page 40 Tektite Manufacturing Inc. 427 Buffalo Str, Box 639, Winkler MB, R6W 4A8, Canada Notice of Confidentiality MF1726E-ASM-15 Daryl Furkalo...
