URYU UBX-T40D Instruction Handbook Manual

Smaller & lighterauto shut-off battery pulse tools
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Handbook for UBX-T40D
SMALLER & LIGHTER
AUTO SHUT-OFF
BATTERY PULSE TOOLS
Version 4-0
April 2024
・ Use this tool (hereafter UBX-T) correctly reading through
everything in this instruction handbook (hereafter handbook) before
use. A shock, fire or severe injury is possible if you fail to follow all
the instructions.
・ After reading, save this handbook at the place where users can
read any time.
