URYU UAN Series Instruction Manual

Angle nutrunners
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Intended Use : The tool is designed to tighten or loosen threaded fasteners.
-The tool is intended for professional use only.
-Avoid misuse and abuse of the tool.
(e.g. Do not throw the tool on the floor, strike the housing in any way or use the tool as a hammer to knock material into place.)
1-2-11, Fukae-Minami, Higashinari, Osaka, 537-0002, Japan.
Tel.
E-mail : uryuair@uryu.co.jp
UAN series
Angle Nutrunners
Instruction Manual
-Read and understand the safety instructions before installing,
operating, repairing, maintaining, changing accessories on or
working near the angle nutrunner. Failure to follow the
warnings and instructions in this handbook can result in
serious bodily injury.
-Do not discard the safety and operating instructions. Give them
to the operator. Retain these instructions for future reference.
: +81-(0)6-6973-9415
Fax : +81-(0)6-6972-0346
http:// www.uryu.co.jp/en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UAN Series and is the answer not in the manual?

Questions and answers

Related Manuals for URYU UAN Series

Summary of Contents for URYU UAN Series

  • Page 1 UAN series Angle Nutrunners Instruction Manual -Read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on or working near the angle nutrunner. Failure to follow the warnings and instructions in this handbook can result in serious bodily injury.

  • Page 2: Description Of Functions

    Description of Functions Locking Nut Throttle Lever Casing Protector Angle Casing Throttle Lever Air Inlet Lubricate from here. Torque Adjuster Hole Reverse Lever Set the lever to ‘R’ for clockwise operation and ‘L’ for anticlockwise operation. Safety Instructions General Safety -Only qualified and trained operators should install, adjust or use the tool.
  • Page 3 -Use hearing protection in accordance with employer’s instructions and as required by occupational health and safety regulations. -Always ensure that the silencer is in place and in good working order when the tool is operating. Vibration Exposure to vibration can cause disabling damage to the nerves and blood supply of the hands and arms. If you experience numbness, tingling, pain or whitening of the skin in your fingers or hands, stop using the tool, tell the employer and consult a physician immediately.

  • Page 4: Maintenance Instructions

    General Instructions -Use correct jigs for proper service. Contact the nearest URYU distributor or URYU Japan for jigs. -When grasping a tool or part in a vice, always use leather-covered or copper-covered vice jaws to protect the surface of the part and help to prevent distortion.
  • Page 5 Install the ball bearing and roller pin into the driven gear. Install the above driven gear into the angle casing. Install the O-ring into the driven gear. Install the adjusting spacer into the angle casing cover. (Note: The adjustment spacers are used to adjust the gear lash.) (See figure 2.) Install the angle casing cover into the angle casing.

  • Page 6: Technical Data

    We, URYU SEISAKU, LTD., cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we have no control.

This manual is also suitable for:

Uan-rm seriesUan-611r-60cUan-611r-50cUan-611r-40cUan-611r-30cUan-701r-60c ... Show all
