  • Page 1 STCC400 SERVICE CART OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.

  • Page 2: Specification

    SPECIFICATION MODEL No STCC400 DIMENSIONS 762mm x 406mm x 889mm CAPACITY 158kg WARNING Read and understand instructions before use. Always wear eye/face and hand protection when assembling the tool cart. Assemble only according to these instructions. Improper assembly can create hazards.
  • Page 3 WARNING 1. Wear approved safety goggles and heavy‑duty work gloves during as‑ sembly. 2. Keep assembly area clean and well lit. 3. Keep bystanders out of the area during assembly. 4. Do not assemble when tired or when under the influence of alcohol, drugs or medication.
  • Page 4 1. Attach two swivel casters (7) to one side of the lower shelf (5) using eight carriage bolts (11), washers (15) and lock nuts (13). 2. Attach two locking swivel casters (8) to the other side, using eight carriage bolts, washers (15) and lock nuts (13). WWW.SGS-ENGINEERING.COM PAGE 4...
  • Page 5 ASSEMBLY 3. Attach the upper shelf (2) to the drawer frame (1) using four bolts (12), eight washers (15) and four lock nuts (13). PAGE 5...
  • Page 6 5. Attach one post (3) to each corner of the drawer/shelf assembly and lower shelf using twenty four bolts (10), washers (16) and lock nuts (14) total, eight on top and sixteen on the bottom as shown below. WWW.SGS-ENGINEERING.COM PAGE 6...
  • Page 7 ASSEMBLY 6: Attach one handle (6) to each end using eight bolts (9), washers (16) and lock nuts (14). 7: Tighten all hardware and slide the drawer (7) into the drawer frame PAGE 7...

  • Page 8: Parts List

    Locking Swivel Caster 903321 Bolt M6 x 35 903309 Bolt M6 x 10 903314 Carriage Bolt M8 x 16 903311 Bolt M8 x 16 903315 Lock Nut M8 903316 Lock Nut M6 904917 Washer Ø8 905857 Washer Ø6 906969 WWW.SGS-ENGINEERING.COM PAGE 8...

  • Page 9: Parts Diagram

    PARTS DIAGRAM PAGE 9...

  • Page 10: Ec Declaration Of Conformity

    SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd TOOL CART TYPE OF EQUIPMENT: STCC400 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
