- Page 1 STCC400 SERVICE CART OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
- Page 2 SPECIFICATION WARNING 1. Wear approved safety goggles and heavy‑duty work gloves during as‑ MODEL No STCC400 sembly. TRAY DEPTH 75mm WHEELS 100mm 2. Keep assembly area clean and well lit. DIMENSIONS 785mm x 420mm x 885mm 3. Keep bystanders out of the area during assembly.
- Page 3 Drawer Frame with the four holes in the bottom of side of the Shelf. Bolt in place using four of the Bolts (1), Small Washers (2), the Upper Shelf. Secure in place using Bolts (4), and Nuts (9). and Nuts (6). WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5...
- Page 4 Bolt in place using four of the Bolts (1), Small Washers (2), and Nuts (6). Note: Check that the unit is square and the drawer slides easily. Retighten all bolts if needed to adjust the cart. WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7...
- Page 5 Note: The Casters need to be tapped into their slots for a snug fit. The nylon Caster Holder expands as the Caster is tapped into place. CAUTION: Do not tap directly on the Caster with the rubber mallet. The Caster may break. WWW.SGS-ENGINEERING.COM PAGE 8 PAGE 9...
- Page 6 SGS Engineering (UK) Ltd PARTS LIST West Side Park Raynesway Description Qty. Part No. Derby, DE21 7AZ Cross Screw M6x35 903309 Flat Washer 6 902094 EC Declaration of Conformity Handle 903310 Hex Bolt M8x10 902527 This is an important document and should be retained...
