- Page 1 STCC450 TOOL CART OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
- Page 2 5. Close Lid to lock all Drawers, then lock Lid with Key before moving. 6. Use only on a flat, level, hard and smooth surface capable of safely supporting a fully loaded Cart. Do not roll Cart over concrete seams or other rough/uneven surfaces WWW.SGS-ENGINEERING.COM PAGE 2 PAGE 3...
- Page 3 2. Attach two Swivel Casters (14) to one side of the Bottom Shelf (12), using eight sets of Bolts (13), Washers (3) and Nuts (4). 3. Attach two Locking Swivel Casters (11) to the other side, using eight sets of Bolts (13), Washers (3) and Nuts (4). WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5...
- Page 4 8. Attach the Handle (7) to lower holes on same side as Locking Swivel Casters, using two sets of Handle Bolts (9) and Nuts (4). 9. Secure Posts to Chest using fourteen sets of Bolts (2), Washers (3) and Nuts (4). 10. Tighten all hardware. WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7...
-
Page 5: Parts Diagram
Nut (M8) 52 901995 Chest 903554 Left Post 903555 Handle 903556 Handle Knob 903557 Handle Bolt (M8x16) 902203 Cross Support 903558 Locking Swivel Caster 903559 Bottom Shelf 903560 Bolt (M8x16) 16 902203 Swivel Caster 903561 WWW.SGS-ENGINEERING.COM PAGE 8 PAGE 9... -
Page 6: Ec Declaration Of Conformity
SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Tool Chest/Cabinet TYPE OF EQUIPMENT: STCC450 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
