PREMIER TECH REWATEC Installation Manual page 4

INSTALLING THE UNIT'S LID
WARNING – Ensure that the main access is directly above
the doser and that the two inlet labels are aligned, as shown
in figure 3.
CONNECTING THE OUTLET PIPES
ADDITION OF OUTLETS #6 AND #7.
When a sixth and seventh outlet are necessary, simply drill the unit
according to the drawing below. As the outline of these two outlets
are not shown, it is important to closely follow these instructions.
Keep an appropriate distance from the other outlets and from the
top of the reservoir. Use the watertight outlet adapters provided
by Premier Tech.
PT Water and Environment
+1 800 632-6356
info.ptwe.na@premiertech.com
PT-WaterEnvironment.com
4
Oulets
Figure 4 | Connections of the Rewatec dosing distribution box
The information contained in this document was up-to-date and consistent with the information available at the
time of publication. Premier Tech Ltd and its affiliated companies make no warranties or representations as
to its accuracy. Because of its continuous improvement policy, Premier Tech Ltd and its affiliated companies
reserve the right to change and/or discontinue the manufacture of any product and/or modify technical data
and prices, for any reason whatsoever and at its sole discretion, without further notice and without liability
to anyone in this regard. ECOFLO
are trademarks of Premier Tech Ltd or its affiliates. For current data regarding all patent application(s) and
patent(s) for the gravity dosing distribution box, reference 8296, or any part thereof, consult the website
patentmarking.premiertech.com.
© 2024 Premier Tech Ltd. All rights reserved.
Figure 3 | Installing the lid
Provided
watertight
adapters
INITIAL EXIT
Figure 5 | Position of outlet 6 and 7
® , REWATEC TM , PREMIER TECH
Rewatec dosing distribution box | Installation guide
™
Water inlet side
90
127,0
1
3 2 "
5"
287
5
11 16 "
153
6"
103
1
4 16 "
