PREMIER TECH REWATEC Installation Manual page 2

Installation guide
Dosing distribution box
This guide contains the information needed to install the
procedure must be performed by a duly trained installer. To get a list of installers or to get
replacement parts, please contact Premier Tech at
TOOLS NEEDED
• Level
• Measuring tape
• 5'' hole saw
• 9/16'' combination wrench
TOOLS PROVIDED
• 1 gasket
• 5 watertight outlet adapters
IMPORTANT
The Rewatec dosing distribution
box is limited to five (5) outlets
in configurations that include the
Ecoflo linear biofilter.
35 1/4"
[896 mm]
24"
[600 mm]
[610 mm]
2
|
24"
17 3/4"
[451 mm]
Rewatec dosing distribution
1 800 632-6356.
Exclusive design
Water inlet
Reservoir (18 gal/68 L)
Maintenance access
Doser*
Distribution chamber
Water outlets (up to 7)
* Protected intellectual property (reference: 8296)
patentmarking.premiertech.com
63 3/4"
[1,621 mm]
Rewatec dosing distribution box | Installation guide
™
box. This
Maximum
6'' riser available
17 3/4"
[451 mm]
