Oxford Locker
OXFORD LOCKER
ASSEMBLY INSTRUCTIONS
Assembly should be undertaken
by at least two people.
Take care when handlling heavy items
particularly when lifting or stretching.
READ INSTRUCTIONS BEFORE ASSEMBLING!
Dispose of packaging
materials responsibly.
Inspect all packages for damage and check
that all components have been supplied.
If in doubt
Caution During Assembly. Same
contact supplier.
corners may have sharp edges.
urbanlockers.co.uk
Make sure the
Wear appropriate clothing protective
floor is level.
gloves and footwear are recommended.
Allow adequate working space and be
aware of the others working around you.
1/16
