Urban CHELSEA Assembly Instructions

ASSEMBLY INSTRUCTIONS
*Left and right are in the direction of facing the product.
Left Side Plate:1 pc
G1 G2
Back Legs
Front Legs
with 2 holes on the top crossbar
Metal Washer:4 pcs
CHELSEA
Parts List
Right Side Plate:1 pc
Adjustable Feet:4 pcs
Screw:4 pcs
C1 C2
Left Door Right Door
Shelf:4 pcs
Door Pin:2 pcs
Information
If in doubt contact the supplier
Please read these instructions thoroghly
before commencing assembly
Inspect all packages for damage and check
that all components have been supplied
Assembly should be undertaken by at least
two people
Caution During Assembly.
Same corners may have sharp
Wear appropriate clothing. Protective gloves
and footwear are recommended
Dispose of packaging materials responsibly
Make sure the floor is level
Allow adequate working space and be aware
of others working around you
Not suitable for use in damp or wet
environments
Take care when handling heavy items
particularly when lifting or stretching
Screwdriver and rubber
Back Plate:2 pcs
Shelf Holder:12 pcs+4 extra
Plastic Washer:2 pcs
edges.
mallet included
Top Plate:1 pc
F1 F2
Right Bottom Plate
Left Bottom Plate
Handle:2 pcs
Key:2 sets Hanger:1 pc
