- Page 1 Trace Elliot® TE 1200 Bass Instrument Amplifier F-1200B Bass Head (Super Festival Series) Manual Owner’s Manual www.peavey.com...
- Page 2 Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le Warning: Changes or modifications to the equipment not approved by Peavey Electronics brouillage est susceptible d’en compromettre le fonctionnement. Corp. can void the user’s authority to use the equipment. Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the Note - This equipment has been tested and found to comply with the limits for a Class user’s authority to use the equipment. ...
- Page 3 Caution: Please look over this guide and read any caution or warning statements found within. Following these warnings is crucial to your personal safety and the safety of your Peavey product. Additional safety warnings are located on the bottom of the unit.
-
Page 4: Input Jacks
Top Panel (1) INPUT JACKS The input jacks of your F-1200 are arranged in a unique switching circuit that allows added flexibility in matching various input levels. Input “1” has about twice as much gain as input “2”. If the amp is being overloaded in -this more sensitive jack·, the less sensitive jack “2”... -
Page 5: Master Volume
The bass control is part of an electronic crossover and serves to boost or cut the lower frequencies. This control should be regarded as a level control for the low end response. This function is augmented by the use of the first three sections of the equalizer, labeled 100, 300, 600. -
Page 6: Ground Lift
Rear Panel (8) USB RECORD OUT This is provided for connection to a computer or a digital audio workstation for recording. It is the preamp master out signal which includes all preamp functions. There is no input capability. (9) Footswitch Connect the F-1200B footswitch here for for control of mute, boost, overdrive, and effects loop functions. -
Page 7: Voltage Selector Switch
(16) SPEAKER OUTPUT CONNECTORS This is the amplifier output, with two paralleled connectors. These connect to the speaker cabinets. The minimum load for the amplifier is 4 Ohms. This can be a single 4 Ohm cabinet, two 8 Ohm cabinets, or any combination of cabinets whose parallel combination is greater than 4 Ohms, total. -
Page 8: Specifications Are Subject To Change Without Notice
Specifications Weight: 11.5 lbs (5.22 kg) Dimensions (W x D x H): 15.2”W x 10.5”D x 5.7”H (386mm x 267mm x 145mm) Mains Voltage: 120 VAC 50/60 Hz, Fuse = T10AL/250V 220-240 VAC 50/60 Hz, Fuse = T5AL/250V Protection: Over temperature Over current Clip limiting Short circuit... - Page 12 Trace Elliot • Hwy. 5022 Hwy. 493 North • Meridian, MS 39305 Features and speci cations subject to change without notice. Tel: (601) 486-2255 • Fax: (601) 486-1156 • www.traceelliot.us ©2016 Printed in U.S.A. 80305734 Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
