INFINITY HD56kWe continuous flow water heater
Commissioning
Applicable model
These commissioning instructions are for the following model:
•
HD56kWe external
Important
These instructions MUST BE retained with the appliance and returned to the storage pocket inside the
front cover after use.
All settings MUST be set for the particular model/application in accordance with these instructions.
Incorrect settings may result in a dangerous situation or damage to the appliance.
The PCB interface and dip switch settings must only be changed by a licensed gasfitter. They have been
provided as there may be a requirement to change the temperature of the water delivered from the water
heater.
Care must be taken when changing the temperature or dip switch settings as they can be easily
switched or bumped into the wrong position. Fully check the operation of the water heater before
WARNING
leaving including the temperature of the water delivered. Ensure building occupants do not have
access to any hot water outlets during this procedure.
The cover of the water heater will need to be removed to carry out this operation. As this will
expose live mains voltage wiring please disconnect the power supply before removing the
WARNING
front cover.
We wish to draw your attention to the requirements of the New Zealand Building Code and compliance
document G12. This requires that water delivered to sanitary fixtures be no more than 55 °C. Increasing
the water heater set temperature will require that you protect all sanitary fixtures to which the appliance
is plumbed with suitable tempering valves or something similar.
Rinnai will accept no liability for issues arising out of the use of this information. If you have any doubts
about the performance of the water heater, please contact Rinnai by phoning 0800 RINNAI
(0800 746 624).
Gas supply requirements
With all gas appliances in operation at maximum gas rate, the flowing inlet pressure at the incoming test
point on the water heater should read 1.13-3.0 kPa on Natural Gas and 2.75-3.0 kPa on ULPG. If the
pressure is lower, the gas supply is inadequate and the appliance unit will not operate to specification.
Check gas meter, regulator and pipework for correct operation/sizing and rectify as required.
(REU-AM3237WC-ZK)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rinnai Infinity HD56kWe external
Summary of Contents for Rinnai Infinity HD56kWe external
- Page 1 Rinnai will accept no liability for issues arising out of the use of this information. If you have any doubts about the performance of the water heater, please contact Rinnai by phoning 0800 RINNAI (0800 746 624).
- Page 2 PCB changeover is required. The PCB replacement and data transfer MUST BE performed by a licensed gasfitter. Consult the relevant Rinnai INFINITY service manual or contact Rinnai Dipswitch detail viewed from front regarding PCB changeover and data transfer.
-
Page 3: Gas Pressure Setting
Confirm the maximum hot water temperatures for all that shown on the appliance, do not proceed— hot water outlets. Requirements of contact Rinnai. To check the gas type enter AS/NZS 3500 MUST BE considered regarding the programming mode by pressing PB2 (red... - Page 4 70 °C 75 or 85 °C 01 / 02 Factory preset temperature The Rinnai HD56kWe will come factory preset to 55 °C (01A + 02A), the default setting. If this needs changing, refer Table 2 above. 07 Auto reset Relates to the status of the unit should a power disruption occur. For both settings 07A and 07b, if the unit is on, with a fixed temperature setting, before a power disruption occurs, the unit will auto reset to come back on when the power is restored.
- Page 5 56 kW. Where this is the case the attending IMPORTANT service person MUST reset the parameter back to 22b ON and check this before leaving the site. Rinnai INFINITY HD56kWe commissioning 01-22 | 5...
-
Page 6: Wiring Diagram
Wiring diagram 6 | Rinnai INFINITY HD56kWe commissioning 01-22... -
Page 7: Diagnostic Points
Below 1 Ω BK-R DC11-14 V Pulse: More than 6 Hz (1.0 Water flow sensor L/min) Y-BK DC4-7 V* Remote controller(s) BK-BK DC11-14 V * Value to be measured while unit is in operation Rinnai INFINITY HD56kWe commissioning 01-22 | 7... - Page 8 Ensure all current menu values are recorded, along with the date that any commissioning and/or programmed setting changes were performed. IMPORTANT Depending on the model, some parameter settings may not be displayed. Menu Menu value Date Additional notes Rinnai.co.nz U359-0821 (00) REU-AM3237(NZ) Tel: 0800 746 624 http://www.youtube.com/rinnainz http://facebook.com.rinnainz Commissioning...
