- Page 1 Installation and Care Guide Whirlpool and Air Bath Standard Installation Retain serial number for reference. Conserver le numéro de série pour référence. Guarde el número de serie para referencia:____________ Français, page “Français-1” Español, página “Español-1” 1208027-2-G...
-
Page 2: Installation Instructions
Do not relocate the whirlpool pump motor or blower motor, or make other modifications to the bath system, as this could adversely affect the performance and safe operation of the product. Kohler Co. shall not be liable under its warranty or otherwise for personal injury or damage caused by any such unauthorized modification. -
Page 3: Tools And Materials
• Conventional Woodworking Tools and Materials • Drop Cloth • Construction Adhesive (Optional) • Cement* or Mortar (Optional) • 2x4s • Plastic Film (Optional) • 1/8" (3 mm) Spacers * Do not use gypsum cement. 100% Silicone Sealant Kohler Co. 1208027-2-G... - Page 4 NOTICE: Measure your actual product for site preparation. Note the model number located on the pump/blower end of the bath, then visit the product page at www.kohler.com for more information. NOTICE: Drop-in models are not intended for alcove installation. Use a flanged model for alcove areas.
- Page 5 Make sure the rubber isolation feet are in place. Drop-In Installation Install the drain tee and tailpiece. Secure the tailpiece into the trap. Install the faucet valve. Check the drain connections for leakage. Kohler Co. 1208027-2-G...
- Page 6 Use large-head galvanized nails to secure the nailing-in flange to the studs. Nail 1/4″ (6 mm) thick furring strips to the studs. Insert the drain tailpiece into the trap. Secure the drain tailpiece to the trap. Install the faucet valve. Check the drain connections for leakage. 1208027-2-G Kohler Co.
- Page 7 24″ (610 mm) power cords. Plug the pump motor, blower, and in-line heater (if included) into these outlets. NOTE: Make sure the air actuator tubing is securely attached to the pump, and is not kinked or damaged. Kohler Co. 1208027-2-G...
- Page 8 A 120 V, 15 A dedicated circuit is required for each device. Provide a Class A GFCI or RCD for each dedicated circuit. Provide a separate equipment grounding conductor for the inside ground or ground lug. The conductor must not be connected to any current-carrying conductor. Bond in accordance with national and local codes. 1208027-2-G Kohler Co.
-
Page 9: Complete The Installation
″Operating the Air System″ sections. Finish the Installation IMPORTANT! Kohler Co. strongly recommends the use of 100% silicone sealant as instructed. Other sealants with high filler contents should be avoided, as they may shrink, separate, and peel over time Install water-resistant wallboard and all finished wall, deck, and floor materials. - Page 10 WARNING: Risk of personal injury. Never drop or insert any object into any opening. Use this bath only for its intended purpose as described in this guide. Do not use attachments not recommended by Kohler Co. The bath must be connected only to a supply circuit that is protected by a Ground-Fault Circuit-Interrupter (GFCI)*.
- Page 11 Press the air switch a second time to turn off the pump. Carefully exit the bath, then open the drain and empty the water. NOTE: If the whirlpool system does not function properly, refer to the ″Troubleshooting″ section. Kohler Co. 1208027-2-G...
-
Page 12: Care And Cleaning
NOTE: If the bath does not function properly, refer to the ″Troubleshooting″ section. Care and Cleaning For best results, keep the following in mind when caring for your KOHLER bath: • Always test your cleaning solution on an inconspicuous area before applying to the entire surface. -
Page 13: Flush The System
Use a soft cloth to wipe the keypad after each use. If the surface becomes dirty, use a non-abrasive soap and warm water to clean. For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care & Cleaning information, call 1-800-456-4537. -
Page 14: Troubleshooting
Troubleshooting NOTICE: This section is for general aid only. A Kohler Co. Authorized Service Representative or qualified electrician should correct any electrical problems. For warranty service, call 1-800-4KOHLER from within the USA and Canada, or 001-800-456-4537 from within Mexico. - Page 15 Blower turns off by itself A. The Purge Mode icon was A. Press the On/Off icon on the keypad. See the ″Operating after running for two pressed instead of the On/Off minutes. icon. Instructions″ section. Kohler Co. 1208027-2-G...
-
Page 16: Warranty
10. Bath does not purge A. Blower does not work. A. Replace the blower. automatically. Warranty ONE-YEAR LIMITED WARRANTY KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year from date of installation. 1208027-2-G Kohler Co. - Page 17 It is recommended that at the time of purchase, you verify that all accessories and components are complete in this package. This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the date of purchase as shown on the invoice or receipt.
- Page 18 CHIHUAHUA, CHIH., MEXICO C.P. 31060 R.F.C. CIN141022IE9 TEL: 52 (614) 429-11-11 IMPORTER: GAMA MATERIALES Y ACEROS, S.A. DE C.V. AVE LOS ANGELES NO. 1800 COL VALLE DEL NOGALAR, SAN NICOLAS DE LOS GARZA N.L. MEXICO R.F.C. GMA901220U11 TEL: 81-1160-5500 1208027-2-G Kohler Co.
