LineATA Quick Guide
Package Contents
LineATA – LINE USB Gateway
◼
◼
Telephone RJ11 cable
◼
LineATA Setup Wizard CD with LineATA & LINE setup program, user
manual and quick guide. User can download latest LineATA related
document from Regin Tech web site:
https://www.regintech.com.tw/download.htm
LineATA introduction YouTube
You can enable YouTube caption setting.
LineATA can run recent SkyATA software to work as a Skype gateway
Important Notice before Use:
1. LINE@ account is for business use with text communication function.
Please apply consumer version Windows LINE account for LINE gateway
application!
Make sure that your PC has internet access and running the supported
LINE version like 9.1.2.3379. Suggest having automatically login your LINE
account via email or mobile phone number instead of mobile phone QR
code as below figure. User needs to login LINE account whenever LINE
restarts if user chose to log in LINE via QR code. It is not convenient for
such application.
https://youtu.be/rd5xjo09GWE

Advertisement

loading
Need help?

Need help?

Do you have a question about the LineATA and is the answer not in the manual?

Questions and answers

Related Manuals for Regin Tech LineATA

Summary of Contents for Regin Tech LineATA

  • Page 1 LineATA introduction YouTube https://youtu.be/rd5xjo09GWE You can enable YouTube caption setting. LineATA can run recent SkyATA software to work as a Skype gateway Important Notice before Use: 1. LINE@ account is for business use with text communication function. Please apply consumer version Windows LINE account for LINE gateway...
  • Page 2 2. When you run LineATA at the first time, there will pop out below window. Please refer five steps as the below figure to set LineATA as the device for LINE Speaker and Microphone. If you don’t need the reminder again, please choose “Don’t inform again”.
  • Page 3 LineATA’s control of LINE GUI when there are calling out, taking calls, or hanging up activities. Otherwise, LineATA might not work correctly. User can use the computer during a LINE talk, but the calling window can’t be closed.
  • Page 4 LINE call. There is no such problem under Win 7. 7. If user has any problem to use LineATA, please refer the recent LineATA user manual chapter 4 FAQs - Frequently Asked Questions in our web site...
  • Page 5 Remove LineATA dongle and setup wizard CD from LineATA package. Plug LineATA dongle into your computer USB port. Connect LineATA RJ-11 port to a regular analog phone RJ-11 port or PBX trunk line through phone cable and make sure phone is on-hook properly.
  • Page 6 LineATA when mouse cursor is put on LineATA system tray icon. And you can hear the dial tone when you pick up the phone receiver and the LED of LineATA is solid on at blue color. Then LineATA should be successfully installed.
  • Page 7 Dial” individually to have the data sorted in a sequential order for easy finding. If user wants to delete some friends, user can hold keyboard “ctrl” key and choose all friends to be deleted, then press “Delete” button. The selected friends will be deleted. Note: LINE friend display name might be modified, user needs to modify on “Friends”...
  • Page 8 Below picture pops out. Click content circled in red and copy & paste on “Contact” of Speed Dial page. 10. When LineATA is not in use, user can set preferred Windows default audio device to play music or record voice. Please click "OK" or "Apply" after the change.
  • Page 9 11. Support LINE DID: incoming LINE calls can be forwarded to the assigned PBX extension for easy customer service support.
  • Page 10 12. Pick up your phone receiver or handset and dial LINE friend’s speed number + “#” key through the phone keypad after hearing a dial tone and enjoy a LINE call. You can pick up phone first and then make a LINE call from LINE GUI.
  • Page 11 1. LineATA setup installation needs to be under user with administrator privilege. 2. LineATA is quite different with regular USB devices like USB keyboard or mouse. It needs 5V, 500mA power from the USB port. If LineATA can't work properly after this device is successfully installed, please unplug this...

  • Page 12: Customer Support

    Customer support Regin Technology Corp. LTD. TEL: 886-3-5735360 Mobile: 886-936071552 E-mail: henry@regintech.com.tw LINE ID: Henry Chou Regintech web site Skype: regin.skype Service hours: 0900~1800 (GMT+08:00 Taipei) office hour Regintech customer support LINE account (By searching mobile number 0936071552 or scan above QR code)
