- Page 1 Thermo Scientific Barnstead Remote Dispenser Type D8952-Series 895 Operating Manual and Parts List LT895X2 Rev. 0 _________________________________________________________________________________ Part of Thermo Fisher Scientific...
- Page 2 Preface Models covered in this manual Model Number Description D8952 (316940) Remote Dispenser Kit MANUAL NUMBER LT895X2 (327142) 8/27/10 Transfer to Marietta (was LT895X2 3/28/08) ECR/ECN DATE DESCRIPTION Thermo Scientific Remote Dispenser...
- Page 3 Thermo Fisher Scientific makes no representations or warranties with respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to the use of this manual. ©2010 Thermo Fisher Scientific. All rights reserved. Remote Dispenser Thermo Scientific...
- Page 4 Always use the proper protective equipment (clothing, gloves, goggles, etc.) 4 Always dissipate extreme cold or heat and wear protective clothing. 4 Always follow good hygiene practices. 4 Each individual is responsible for his or her own safety. Thermo Scientific Remote Dispenser...
- Page 5 We can also provide you with a quotation on our Extended Warranty for your Thermo Scientific products. Whatever Thermo Scientific products you need or use, we will be happy to discuss your applications. If you are experiencing technical problems, working together, we will help you locate the problem and, chances are, correct it yourself...over the telephone without a service...
-
Page 6: Table Of Contents
Ordering Procedures ........6-2 Thermo Scientific... -
Page 8: Introduction
Introduction Section 1 Congratulations on your purchase of a Thermo Scientific Barnstead Remote Dispenser. The unit is designed to deliver Type I reagent grade water up to 8 feet (2.4 meters) away from an existing Quad Style Series 747 NANOpure or E- pure water system. -
Page 10: Safety Information
Safety Information Section 2 Your Thermo Scientific Barnstead Remote Dispenser has been designed with function, reliability, and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, pay attention to Notes, Cautions, and Warnings throughout the manual. -
Page 12: Specifications
Operating: 17°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation Category II (over-voltage) in accordance with IEC 664. Pollution Degree 2 in accordance with IEC 664. Altitude limit: 2,000 meters. Storage: -25°C to 65°C; 10% to 85% relative humidity. Thermo Scientific Remote Dispenser... -
Page 14: Installation
4. Remove the bracket holding the existing Series 663 Remote Dispenser by unscrewing one screw and securing nut from the bracket. 5. Locate the bracket shipped in the “NANOpure” bag with the Series 895 Remote Dispenser. (continued) Thermo Scientific Remote Dispenser... - Page 15 9. Reattach the top cover with the two screws you removed previously. 10. Remove the tubing adapter from the New Series 895 Remote Dispenser. Ensure that the o-ring, grab ring and backup ring stay on the remote dispenser. See Figure 4-2 for part identification. Remote Dispenser Thermo Scientific...
-
Page 16: Mounting Dispenser In An E-Pure System
Insert the screw you removed earlier through the remaining exposed hole in the aligned cartridge head bracket and dispenser bracket. Tighten the last screw you put in. Tighten remaining screws that were previously loosened (Step 2). Thermo Scientific Remote Dispenser... - Page 17 12. Hang the Series 895 Remote Dispenser on the E-pure unit by placing the fitting at the end of the remote dispenser into the U-shaped groove on the bracket you just mounted. The dispenser goes filter-up between the nuts on the Luer fitting. Remote Dispenser Thermo Scientific...
-
Page 18: Operation
4. Install a Thermo Scientific Barnstead 0.2 micron cross flow filter (part no. FL703X2) into the housing by screwing onto Luer fitting at outlet of dispenser. Hand-tighten only. Rinse 8-10 liters of water to drain through new filter. -
Page 20: Maintenance And Servicing
Part # ......Description FL703X2 . .Package of one (1) 0.2 micron final filter Thermo Scientific Remote Dispenser... -
Page 21: Ordering Procedures
All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory. - Page 22 Thermo Fisher Scientific 401 Millcreek Road Marietta, Ohio 45750 United States www.thermofisher.com...
