Temposonics R Series Operation Manual

Magnetostrictive linear position sensors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation Manual
R-Series V SSI
Magnetostrictive Linear Position Sensors
V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R Series and is the answer not in the manual?

Questions and answers

Related Manuals for Temposonics R Series

Summary of Contents for Temposonics R Series

  • Page 1 Operation Manual R-Series V SSI Magnetostrictive Linear Position Sensors...

  • Page 2: Table Of Contents

    3.8 Approvals ........................................ 18 3.9 Scope of delivery ..................................... 18 4. Product description ............................19 4.1 Functionality and system design ................................19 4.2 Installation and design of Temposonics RP5 ............................20 ® 4.3 Installation and design of Temposonics RH5 ............................22 ®...
  • Page 3 R-Series V SSI Temposonics ® Operation Manual 8. Technical data ..............................74 8.1 Technical data of Temposonics RP5 ..............................74 ® 8.2 Technical data of Temposonics RH5 ..............................76 ® 8.3 Technical data of Temposonics RM5 ..............................78 ® 8.4 Technical data of Temposonics RF5 ...............................

  • Page 4: Introduction

    This product may be used only for the applications defined under item 1 and only in conjunction with the third-party devices and components recommended or approved by Temposonics. As a prerequisite of prop- er and safe operation the product requires correct transport, storage, mounting and commissioning and must be operat ed with utmost care.

  • Page 5: Installation, Commissioning And Operation

    The technical personnel. If danger of injury to persons or of damage to Temposonics obligation is limited to repair or replacement of any de- operating equipment is caused by sensor failure or malfunction, ad- fective part of the unit.

  • Page 6: Identification

    R-Series V SSI Temposonics ® Operation Manual 3. Identification 3.1 Order code of Temposonics ® optional a Sensor model f Connection type Connector 5 Profi le 0 M16 male connector (7 pin) b Design 4 M12 male connector (8 pin) G Magnet slider backlash free (part no.
  • Page 7 R-Series V SSI Temposonics ® Operation Manual g System n Resolution 1 Standard 1 5 µm 2 10 µm h Output 3 50 µm S SSI 4 100 µm 5 20 µm i Function 6 2 µm 1 Position 7 0.1 µm* 2 Differential measurement (2 magnets and 1 output) 8 1 µm...

  • Page 8: Order Code Of Temposonics ® Rh5

    R-Series V SSI Temposonics ® Operation Manual 3.2 Order code of Temposonics ® optional a Sensor model f Connection type 5 Rod Connector 0 M16 male connector (7 pin) b Design 4 M12 male connector (8 pin) B Base unit (only for replacement) Angled cable outlet J Threaded fl ange M22×1.5-6g (rod Ø...
  • Page 9 R-Series V SSI Temposonics ® Operation Manual g System n Resolution 1 Standard 1 5 µm 2 10 µm h Output 3 50 µm S SSI 4 100 µm 5 20 µm i Function 6 2 µm 1 Position 7 0.1 µm* 2 Differential measurement (2 magnets and 1 output) 8 1 µm...

  • Page 10: Order Code Of Temposonics ® Rm5

    R-Series V SSI Temposonics ® Operation Manual 3.3 Order code of Temposonics ® R M 5 optional a Sensor model f Connection type 4 M12 male connector (8 pin) R M 5 Super shield housing (only for RM5-B) X XX m/ft. PUR cable (part no. 530 052) b Design H01…H30 (1…30 m/3…99 ft.)

  • Page 11: Data Length

    R-Series V SSI Temposonics ® Operation Manual k Mode o Additional options (optional) 1 Measuring direction forward, asynchronous mode 2 FIR fi lter (2 measurements) 2 Measuring direction forward, synchronous mode 1 4 FIR fi lter (4 measurements) 3 Measuring direction forward, synchronous mode 2...

  • Page 12: Order Code Of Temposonics ® Rf5

    R-Series V SSI Temposonics ® Operation Manual 3.4 Order code of Temposonics ® optional a Sensor model f Connection type 5 Improved fl exible rod Connector 0 M16 male connector (7 pin) b Design 4 M12 male connector (8 pin) B Base unit (without fl ange &...
  • Page 13 R-Series V SSI Temposonics ® Operation Manual g System n Resolution 1 Standard 1 5 µm 2 10 µm h Output 3 50 µm S SSI 4 100 µm 5 20 µm i Function 6 2 µm 1 Position 7 0.1 µm* 2 Differential measurement (2 magnets and 1 output) 8 1 µm*...

  • Page 14: Order Code Of Temposonics ® Rfv

    R-Series V SSI Temposonics ® Operation Manual 3.5 Order code of Temposonics ® optional a Sensor model f Connection type V Flexible rod Connector 0 M16 male connector (7 pin) b Design 4 M12 male connector (8 pin) B Base unit (without fl ange & rod assembly) Angled cable outlet M Threaded fl ange M18×1.5-6g (without rod assembly)
  • Page 15 R-Series V SSI Temposonics ® Operation Manual g System n Resolution 1 Standard 1 5 µm 2 10 µm h Output 3 50 µm S SSI 4 100 µm 5 20 µm i Function 6 2 µm 1 Position 7 0.1 µm* 2 Differential measurement (2 magnets and 1 output) 8 1 µm*...

  • Page 16: Order Code Of Temposonics ® Rdv

    R-Series V SSI Temposonics ® Operation Manual 3.6 Order code of Temposonics ® optional a Design e Number of magnets V Detached sensor electronics “Classic” X 01…02 position(s) (1…2 magnet(s)) b Design f Connection type C Threaded fl ange M18×1.5-6g (A/F 46) Connector D Threaded fl ange ¾"-16 UNF-3A (A/F 46)
  • Page 17 R-Series V SSI Temposonics ® Operation Manual g System n Resolution 1 Standard 1 5 µm 2 10 µm h Output 3 50 µm S SSI 4 100 µm 5 20 µm i Function 6 2 µm 1 Position 7 0.1 µm* 2 Differential measurement (2 magnets and 1 output) 8 1 µm...

  • Page 18: Nameplate

    R-Series V SSI Temposonics ® Operation Manual 3.7 Nameplate Order code RH5MA0250M01D701S1012G8 Resolution, data length, format 1 µm, 24 bit, Gray Serial number & S/N: 70008887 01AUG2022 date of production Fig. 1: Example of nameplate of R-Series V RH5 sensor with SSI output 3.8 Approvals...

  • Page 19: Product Description

    • The sensor electronics housing, a rugged aluminum construction, Principle of operation and system construction contains the complete electronic interface with active signal The absolute, linear position sensors provided by Temposonics rely on conditioning. the company’s proprietary Temposonics magnetostrictive technology, •...

  • Page 20: Installation And Design Of Temposonics ® Rp5

    R-Series V SSI Temposonics ® Operation Manual 4.2 Installation and design of Temposonics ® RP5-M, example: Connection type D70 (connector outlet) Sensor electronics housing Null zone Stroke length Dead zone 48 (1.89) 11.7 25…6350 66/71* (0.46) (2.28) (1.1) (1…250) (2.6/2.8*) e.g. for M5 or #10 screws 35.6 (1.4)
  • Page 21 R-Series V SSI Temposonics ® Operation Manual Installation of RP5 Alternative:  The position sensor can be installed in any position. Normally, If only limited space is available, the profile sensor can be mounted the sensor is firmly installed and the position magnet is fastened also via the T-rail in the profile bottom using a T-slot nut M5 to the mobile machine part.

  • Page 22: Installation And Design Of Temposonics ® Rh5

    R-Series V SSI Temposonics ® Operation Manual 4.3 Installation and design of Temposonics ® RH5-M/S-A/F/V – RH5 with threaded fl   ange M18×1.5-6g or ¾"-16 UNF-3A, example: Connection type D70 (connector outlet) Sensor electronics housing Null zone Stroke length Dead zone 11.7 25…7620 63.5/66* (0.46) (2.68) (2.01) (1…300) (2.5/2.6*) Threaded flange »M«: M18×1.5-6g Threaded flange »S«: ¾"-16 UNF-3A (0.98)
  • Page 23 Stroke length 1576…5000 (62.05…196.9): 54 (2.13) dead zone (1.89) Stroke length 5001…7620 (196.9…300): 57 (2.24) dead zone Controlling design dimensions are in millimeters and measurements in ( ) are in inches Fig. 7: Temposonics RH5 with ring magnet, part 2 ® Installation of RH5 with threaded flange •...
  • Page 24 R-Series V SSI Temposonics ® Operation Manual Hydraulics sealing Notice for metric threaded fl   anges There are two ways to seal the flange contact surface (Fig. 10): Thread Z° 1. A sealing by using an O-ring (e.g. 22.4 × 2.65 mm (0.88 × 0.1 in.), ×P) 25.07 × 2.62 mm (0.99 × 0.1 in.)) in a cylinder end cap groove.

  • Page 25: Installation And Design Of Temposonics ® Rm5

    R-Series V SSI Temposonics ® Operation Manual 4.4 Installation and design of Temposonics ® RM5-M/S – RM5 with threaded fl   ange M18×1.5 or ¾"-16 UNF-3A, example: Connection type HXX/PXX/RXX/TXX (cable outlet) Cable length Sensor electronics housing Dead zone Null zone Stroke length 1…30 m 25…7615 63.5/66* (2.04) Ø 63 (1…99 ft.) (0.98) (6.7) (1…299.8) (2.5/2.6)*...
  • Page 26 R-Series V SSI Temposonics ® Operation Manual Sealing via O-ring in the flange undercut Fig. 15: Possibilities of sealing • Seat the flange contact surface completely on the cylinder mounting surface. • The cylinder manufacturer determines the pressure-resistant gasket (copper gasket, O-ring, etc.).

  • Page 27: Installation And Design Of Temposonics ® Rf5

    R-Series V SSI Temposonics ® Operation Manual 4.5 Installation and design of Temposonics ® RF5-B – RF5 base unit (without fl   ange & rod assembly), example: Connection type D70 (connector outlet) Null zone Stroke length Dead zone 150…20,000 see table (0.47) (2.28) (2.4) (6…787) Not flexible without rod assembly (1.18) Stroke length Tolerance of total length Dead zone Up to 7620 mm (300.00 in.)
  • Page 28 140 mm (5.51 in.) Note: Tolerance of total length has no influence on the stroke length. Controlling design dimensions are in millimeters and measurements in ( ) are in inches Fig. 18: Temposonics RF5, part 2 ® I 28 I...
  • Page 29 R-Series V SSI Temposonics ® Operation Manual Installation of RF5 Mounting an RF5 sensor Note the following information when mounting and handling an RF5 There are three ways to mount the RF5 sensor: sensor: 1. Installation of the RF5-B base unit in a support tube provided by 1.
  • Page 30 R-Series V SSI Temposonics ® Operation Manual 4. Ensure that the O-ring seal (part no. 562 003) is correctly • Mounted on the face of the piston, the position magnet travels over inserted in the groove on the sensor electronics housing before...
  • Page 31 R-Series V SSI Temposonics ® Operation Manual 3. RF5-B with threaded flange M18×1.5-6g (part no. 404 874) or  Notice for metric threaded fl   anges threaded flange ¾"-16 UNF-3A (part no. 404 875) Thread Z° Fix the sensor rod via threaded flange M18×1.5-6g or ¾"-16 UNF-3A. ×P) Note the fastening torque: +0.1 +0.4 ±1° • Threaded flange M18×1.5-6g (part no. 404 874):...

  • Page 32: Installation And Design Of Temposonics ® Rfv

    R-Series V SSI Temposonics ® Operation Manual 4.6 Installation and design of Temposonics ® RFV-B – RFV base unit (without fl   ange & rod assembly), example: Connection type D70 (connector outlet) Sensor electronics housing Null zone Stroke length Dead zone 11.7 150…20,000 see table (0.46) (2.28) (2.4) (6…787) (0.28) Ø 8 ±0.23 (Ø 0.31 ±0.01)
  • Page 33 140 mm (5.51 in.) Note: Tolerance of total length has no influence on the stroke length. Controlling design dimensions are in millimeters and measurements in ( ) are in inches Fig. 29: Temposonics RFV with ring magnet, part 2 ®...
  • Page 34 R-Series V SSI Temposonics ® Operation Manual Installation of RFV Mounting the RFV 1. RFV-B Note the following information when mounting and handling an RFV sensor: • Insert the flexible sensor rod in a support tube. 1. Always insert the flexible sensor rod in a support tube (e.g.
  • Page 35 R-Series V SSI Temposonics ® Operation Manual Installation of RFV with threaded flange »M«, »S« Hydraulics sealing when using an RFV sensor in a sensor rod HD/ HL/HP Fix the sensor rod via threaded flange M18×1.5-6g or ¾"-16 UNF-3A. Note the fastening torque shown in Fig. 33. Lightly oil the thread be- There are two ways to seal the flange contact surface (Fig.
  • Page 36 R-Series V SSI Temposonics ® Operation Manual Replacing an R-Series 2004 RF-C with an R-Series V RFV-B If you are replacing the R-Series 2004 RF-C base unit with the R-Series V RFV-B base unit, note the following points: • The R-Series 2004 RF-C base unit is attached to the system with two screws.

  • Page 37: Installation And Design Of Temposonics ® Rdv

    R-Series V SSI Temposonics ® Operation Manual 4.7 Installation and design of Temposonics ® RDV with bottom cable entry, example: BXX/EXX/GXX/LXX/UXX (angled cable outlet) 24.7 (0.97) (0.3) Ø 19 (Ø 0.75) Ø 26.2 (Ø 1.03) (1.89) 11.5 (0.45) (2.28) (1.77) (1.61) Recommendation: Use M6×45 (ISO 4762) screws Fastening torque: 6 Nm RDV with side cable entry, example: Connector D70 (connector outlet)
  • Page 38 RDV with side cable entry, example: Connector D84 (connector outlet) (0.51) (2.28) (1.77) RDV with side cable entry, example: HXX/PXX/RXX (straight cable outlet) (0.98) (2.28) (1.77) RDV with side cable entry, example: TXX (straight cable outlet) 30.4 (1.2) (2.28) (1.77) Controlling design dimensions are in millimeters and measurements in ( ) are in inches Fig. 38: Temposonics RDV sensor electronics housing, part 2 ® I 38 I...
  • Page 39 Cable length (side cable entry): 250/400/600 (9.8/15.7/23.6) Cable for Cable for 12.7 bottom cable entry side cable entry (0.18) (0.5) Controlling design dimensions are in millimeters and measurements in ( ) are in inches Fig. 39: Temposonics RDV flanges ® I 39 I...
  • Page 40 R-Series V SSI Temposonics ® Operation Manual Installation of a rod-style sensor in a fluid cylinder NOTICE The rod-style version has been developed for direct stroke measurement in a fluid cylinder. Mount the sensor via threaded flange or a hex nut. Note for installation respectively for replacement of RDV •...
  • Page 41 R-Series V SSI Temposonics ® Operation Manual 4.7.2 Installation of RDV with pressure fit flange Notice for metric threaded fl   anges Thread Z° Cylinder mounting ×P) Install the rod using the pressure fit flange. Seal it off by means of +0.1 +0.4 ±1° the O-ring and the back-up ring. Block the pressure fit flange using a RDV-C shoulder screw (Fig.
  • Page 42 R-Series V SSI Temposonics ® Operation Manual 4.7.3 Installation of RDV’s sensor electronics housing NOTICE The following section explains the connection of an RDV sensor with To fulfill the requirements of EMC standards for emission and bottom cable entry (Fig. 45) and side cable entry (Fig. 46) based on immunity the following points are necessary: RDV-S.

  • Page 43: Magnet Installation

    R-Series V SSI Temposonics ® Operation Manual 4.8 Magnet installation Concentric mounting of U-magnet Typical use of magnets Air gap Magnet Typical sensors Benefi   ts Ring magnets Rod model • Rotationally symmetrical Part no. 251 416-2: (RH5, RM5, RF5, magnetic fi eld 1.75 ±1 (0.07 ±0.04)
  • Page 44 R-Series V SSI Temposonics ® Operation Manual Rod sensors with stroke lengths ≥ 1 meter (3.3 ft.) RH5 with ring magnet/U-magnet Support horizontally installed sensors with a stroke length of 1 meter (3.3 ft.) and more mechanically at the rod end. Without using a support, Sensor electronics housing the sensor rod bends over and the rod and the position magnet may be Reference edge of mounting damaged.
  • Page 45 R-Series V SSI Temposonics ® Operation Manual RF5-B with ring magnet/U-magnet RFV-B with ring magnet/U-magnet Sensor electronics housing Sensor electronics housing Reference edge of mounting Reference edge of mounting End position End position Start position Start position See table See table 61 (2.4)
  • Page 46 R-Series V SSI Temposonics ® Operation Manual RFV-B with block magnet RDV-S with block magnet Reference edge of mounting Sensor electronics housing Start position End position Reference edge of mounting 21.4 (0.84) 63.5 (2.5) Start position End position 58.5 (2.3)

  • Page 47: Differential Measurement

    ≥ 75 (≥ 3) go below a minimal distance of 75 mm (3 in.) between the magnets for differential measurement. Contact Temposonics if you need a magnet distance, which is smaller than 75 mm (3 in.). RH5/RF5/RFV with ring magnets/U-magnets ≥...

  • Page 48: Alignment Of The Magnet With The Option "Internal Linearization

    A sensor with internal linearization is delivered with the magnet with which the sensor was aligned during production. In order to achieve the best possible result, Temposonics recommends to operate the sensor with the supplied magnet. For the internal linearization, the following magnets can be used: •...
  • Page 49 R-Series V SSI Temposonics ® Operation Manual For RDV SSI sensors with ring magnet/U-magnet applies: The internal linearization of the sensor is carried out under the following conditions: • Install the magnet so that the marking on the magnet faces the sensor flange. • Supply voltage +24 VDC ±0.5 •...

  • Page 50: Replacement Of Base Unit

    R-Series V SSI Temposonics ® Operation Manual 4.10 Replacement of base unit 3. Insert the new base unit. Install the ground lug on a screw. 4.10.1 Replacement of base unit on the RH5/RFV/RF5 model Tighten the screws. The base unit of the sensor model RH5 (RH5-B) is replaceable as shown in Fig.
  • Page 51 R-Series V SSI Temposonics ® Operation Manual 4.10.2 Replacement of base unit on the RM5 model 4. Disconnect the connector from the base unit inside the super shield housing. A base unit RM5-B is installed in the super shield housing of the RM5 (Fig.
  • Page 52 R-Series V SSI Temposonics ® Operation Manual 7. Insert the new base unit. 10. Carefully pull the excess cable out of the super shield Screw the base unit tight. housing. Tighten the pressure screw (marked gray) of the Secure the screws of the base unit before re-installing, cable gland until the sealing insert and pressure screw are at e.g.

  • Page 53: Electrical Connection

    R-Series V SSI Temposonics ® Operation Manual 4.11 Electrical connection Placement of installation and cabling have decisive influence on the sensor‘s electromagnetic compatibility (EMC). Hence correct installa- tion of this active electronic system and the EMC of the entire system must be ensured by using suitable metal connectors, shielded cables and grounding.

  • Page 54: Color Function

    R-Series V SSI Temposonics ® Operation Manual Signal + power supply M12 male connector Function (A-coded) Clock (+) Clock (−) Data (+) Data (−) Not connected Not connected View on sensor +12…30 VDC (±20 %) DC Ground (0 V) Fig. 81: Connector wiring D84...

  • Page 55: Frequently Ordered Accessories For Sensor Model Rp5

    R-Series V SSI Temposonics ® Operation Manual 4.12 Frequently ordered accessories for sensor model RP5 – Additional options available in our Accessories Catalog 551 444 Position magnets 15.2 57 (2.24) (0.6) (1.65) (1.69) (0.94) (1.69) (0.55) (0.55) 49 (1.93) (0.79) (0.79)

  • Page 56: Frequently Ordered Accessories For Sensor Model Rh5

    R-Series V SSI Temposonics ® Operation Manual 4.13 Frequently ordered accessories for sensor model RH5 – Additional options available in our Accessories Catalog 551444 Position magnets Ø 32.8 (Ø 1.29) Ø 4.3 Ø 32.8 Ø 30.5 Ø 25.4 (Ø 0.17) (Ø...

  • Page 57: Frequently Ordered Accessories For Sensor Model Rm5

    R-Series V SSI Temposonics ® Operation Manual 4.14 Frequently ordered accessories for sensor model RM5 – Additional options available in our Accessories Catalog 551444 Position magnets Ø 32.8 (Ø 1.29) Ø 4.3 Ø 32.8 Ø 30.5 Ø 25.4 (Ø 0.17) (Ø...

  • Page 58: Frequently Ordered Accessories For Sensor Model Rf5

    R-Series V SSI Temposonics ® Operation Manual 4.15 Frequently ordered accessories for sensor model RF5 – Additional options available in our Accessories Catalog 551444 Position magnets Ø 32.8 Ø 4.5 (Ø 0.18) Ø 60 Ø 63.5 (Ø 1.29) Ø 4.3 Ø...
  • Page 59 R-Series V SSI Temposonics ® Operation Manual Mounting accessories Sensor rod with threaded fl   ange  Sensor rod with threaded fl   ange  Sensor rod with threaded fl   ange  Profi   le with fl   ange with fl   at-face (M18×1.5-6g)  with fl   at-face (¾"-16 UNF-3A)  with raised-face (¾"-16 UNF-3A) HFP [length mm: XXXXX] M and O-ring and O-ring and O-ring HFP [length in.: XXXX.X] U...

  • Page 60: Frequently Ordered Accessories For Sensor Model Rfv

    R-Series V SSI Temposonics ® Operation Manual 4.16 Frequently ordered accessories for sensor model RFV – Additional options available in our Accessories Catalog 551 444 Position magnets Ø 32.8 Ø 4.5 (Ø 0.18) Ø 60 Ø 63.5 (Ø 1.29) Ø 30.5 Ø...
  • Page 61 R-Series V SSI Temposonics ® Operation Manual Mounting accessories Sensor rod with threaded fl   ange  Sensor rod with threaded fl   ange  Sensor rod with threaded fl   ange  Profi   le with fl   ange with fl   at-face (M18×1.5-6g)  with fl   at-face (¾"-16 UNF-3A)  with raised-face (¾"-16 UNF-3A) HFP [length mm: XXXXX] M and O-ring and O-ring and O-ring HFP [length in.: XXXX.X] U...

  • Page 62: Frequently Ordered Accessories For Sensor Model Rdv

    R-Series V SSI Temposonics ® Operation Manual 4.17 Frequently ordered accessories for sensor model RDV – Additional options available in our Accessories Catalog 551 444 Position magnets Ø 32.8 (Ø 1.29) Ø 4.3 Ø 25.4 Ø 32.8 Ø 17.4 (Ø 0.17) (Ø...
  • Page 63 R-Series V SSI Temposonics ® Operation Manual Mounting accessories 60 (2.36) 16 (0.63) Ø 3.2 (Ø 0.13) M3 fastening screws (6×) 3.2 (0.13) Fixing clip Part no. 561 481 Application: Used to secure sensor rods (Ø 10 mm (Ø 0.39 in.)) when...

  • Page 64: Frequently Ordered Accessories For Ssi Output

    R-Series V SSI Temposonics ® Operation Manual 4.18 Frequently ordered accessories for SSI output – Additional options available in our Accessories Catalog 551 444 Cable connectors* (2.24) (2.13) (2.36) (2.13) Ø 20.5 Ø 20 (Ø 0.81) (Ø 0.79) M16 female connector (7 pin), straight...

  • Page 65: Cable Sets

    Operating temperature: (fi xed installation) Operating temperature: −50…+150 °C −25…+80 °C (−13…+176 °F) Operating temperature: (−58…+302 °F) −30…+90 °C (−22…+194 °F) Programming tools TempoLink kit for Temposonics TempoGate smart assistant for ® ® ® R-Series V R-Series V Temposonics ®...

  • Page 66: Commissioning

    It is no longer possible to update the connected control system synchronously to a clock rate specified by position data in this cycle. the control system. The interface of Temposonics position sensors 3. The bit is applied at the following rising edge.

  • Page 67: Led Status

    Confi guration error Configuration Invalid configuration of Check the configuration of Storage error error the sensor the sensor. Internal error Contact Temposonics. Signal error Storage error Error in internal data Contact Temposonics. Position error storage Internal error Internal error of the Contact Temposonics.

  • Page 68: Programming And Configuration

    R-Series V SSI Temposonics ® Operation Manual 5.3 Programming and configuration 2. Connection to a sensor with cable outlet Connect the pig-tails of the sensor cable to the terminal clamps smart assistant to R-Series V 5.3.1 Connection of TempoLink of the adapter cable according to the connector wiring in Fig. 92 ®...
  • Page 69 R-Series V SSI Temposonics ® Operation Manual 5.3.2 Connection of TempoLink smart assistant to power supply ® Connect the barrel connector of the power supply to the connection point labeled “INPUT 24 VDC” on the TempoLink smart assistant ® Connection to (Fig.
  • Page 70 R-Series V SSI Temposonics ® Operation Manual 5.3.3 Connection of TempoLink smart assistant to smartphone, ® NOTICE tablet or computer • Only one device can be connected to the TempoLink smart ® assistant at a time in order to display the graphical user interface.
  • Page 71 R-Series V SSI Temposonics ® Operation Manual 5.3.5 Graphical user interface To change parameters or to reset the sensor to factory settings, the command mode must be started. In command mode, the sensor does Click the menu symbol in the top left to get to the main menu of the not output a position value.
  • Page 72 R-Series V SSI Temposonics ® Operation Manual Measuring Direction: Setting the measuring direction (see “Glossary” on page 88) for position measurement. • Forward • Reverse Measurement Function: Setting the function of the measurement. • Position • Velocity • Differential Synchronization Mode: Setting the type of synchronization for the position measurement (see “Glossary”...

  • Page 73: Maintenance And Troubleshooting

    Change the parameter and confirm it by clicking the “SUBMIT” button (Fig. 108). Repairs of the sensor may be performed only by Temposonics or Data Format: Setting the SSI coding for the data transmission. a repair facility explicitly authorized by Temposonics. For return see chapter “2.6 Return”...

  • Page 74: Technical Data

    R-Series V SSI Temposonics ® Operation Manual 8. Technical data 8.1 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...

  • Page 75: Electrical Connection

    R-Series V SSI Temposonics ® Operation Manual Electrical connection Connection type 1 × M16 male connector (7 pin), 1 × M12 male connector (8 pin) or cable outlet +12…30 VDC ±20 % (9.6…36 VDC); the RP5 sensors must be power supplied via an external Class 2 power...

  • Page 76: Technical Data Of Temposonics ® Rh5

    R-Series V SSI Temposonics ® Operation Manual 8.2 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...

  • Page 77: Mechanical Mounting

    R-Series V SSI Temposonics ® Operation Manual Mechanical mounting Mounting position Mounting instruction Please consult the technical drawings on page 22 page 23 Electrical connection Connection type 1 × M16 male connector (7 pin), 1 × M12 male connector (8 pin) or cable outlet Operating voltage +12…30 VDC ±20 % (9.6…36 VDC);...

  • Page 78: Technical Data Of Temposonics ® Rm5

    R-Series V SSI Temposonics ® Operation Manual 8.3 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...
  • Page 79 R-Series V SSI Temposonics ® Operation Manual Mechanical mounting Mounting position Mounting instruction Please consult the technical drawing on page 25 Electrical connection Connection type Cable outlet +12…30 VDC ±20 % (9.6…36 VDC); the RM5 sensors must be power supplied via an external Class 2 power...

  • Page 80: Technical Data Of Temposonics ® Rf5

    R-Series V SSI Temposonics ® Operation Manual 8.4 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...
  • Page 81 R-Series V SSI Temposonics ® Operation Manual Electrical connection Connection type 1 × M16 male connector (7 pin) or 1 × M12 male connector (8 pin) or cable outlet Operating voltage +12…30 VDC ±20 % (9.6…36 VDC); the RF5 sensors must be power supplied via an external Class 2...

  • Page 82: Rfv

    R-Series V SSI Temposonics ® Operation Manual 8.5 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...
  • Page 83 R-Series V SSI Temposonics ® Operation Manual Electrical connection Connection type 1 × M16 male connector (7 pin) or 1 × M12 male connector (8 pin) or cable outlet Operating voltage +12…30 VDC ±20 % (9.6…36 VDC); the RFV sensors must be power supplied via an external Class 2...

  • Page 84: Rdv

    R-Series V SSI Temposonics ® Operation Manual 8.6 Technical data of Temposonics ® Output Interface SSI (Synchronous Serial Interface) – differential signal in SSI standard (RS-485/RS-422) Data format Binary or gray Data length 8…32 Bit Data transmission rate 70 kBaud …1 MBaud, depending on cable length:...
  • Page 85 R-Series V SSI Temposonics ® Operation Manual Mechanical mounting Mounting position Mounting instruction Please consult the technical drawings on page page 38 page 39 Electrical connection Connection type 1 × M16 male connector (7 pin) oder 1 × M12 male connector (8 pin) or cable outlet +12…30 VDC ±20 % (9.6…36 VDC);...

  • Page 86: Appendix I - Safety Declaration

    Stroke length(s): The sensor has been in contact with the following materials: In the event of suspected penetration of substances into the sensor, Do not specify chemical formulas. consult Temposonics to determine measures to be taken before Please include safety data sheets of the substances, if applicable. shipment. Short description of malfunction:...

  • Page 87: Appendix Ii - Cylinder Port Details

    P O R T D E T A I L ( P D ) F O R R H 5 - S : NOTES: 1. Dimensions and tolerances based on ANSI Y14.5-1982. 2. Temposonics has extracted all pertinent information from MS33649 to generate this document. 3. PD must be square with surface B within 0.005 FIM across 2.250 dia minimum.

  • Page 88: Glossary

    R-Series V SSI Temposonics ® Operation Manual 11. Glossary Parity The parity bit is a check bit that is added to a bit string to detect Alarm transmission errors. There are even parity and odd parity. With even The alarm bit is set by the sensor if the sensor detects more...
  • Page 89 © 2025 Temposonics, LLC – all rights reserved. Temposonics, LLC and Temposonics GmbH & Co. KG are subsidiaries of Amphenol Corporation. Except for any third party marks for which attribution is provided herein, the company names and product names used in this document may be the registered trademarks or unregistered trademarks of Temposonics, LLC or...
