Summary of Contents for Blue Torrent DIRT DEMON DD 100
- Page 1 DIRT DEMON AUTOMATIC POOL CLEANER Congratulations on purchasing a Dirt Demon Automatic Pool Cleaner. You have made an excellent choice. MODEL DD 100 10543...
- Page 2 DD 100 DIRT DEMON AUTOMATIC POOL CLEANER — PARTS PART # MODEL # DESCRIPTION DD 100AA DD 100 Body DD 102 Dive Float DD 108 Seal Pleated DD S2501 Foot Pad DD 107 Bumper Strap DD EYEBALL Eyeball Diverter DD CONE Cone DD WEIGHTS Hose Weights...
- Page 3 STEP 1 STEP 1 ATTACH THE SEAL To install the seal locate the word “UP”. Face it up towards the body of the cleaner. Gently stretch the seal over the foot pad of the cleaner until it sets itself into the groove as illustrated in figure 2.
- Page 4 STEP 4 STEP 4 ASSEMBLE THE HOSE Your cleaner hose comes in 3’ sections which must be connected together. The hoses are connected by inserting the male cuff of one section of hose into the female cuff of another. Twist the sections of hose together until you establish a snug fit (See figure 5).
-
Page 5: Installation
Once fully assembled, your Automatic Pool Cleaner should look like this..INSTALLATION INSTALLATION Your automatic pool cleaner is designed to work in a wide variety of swimming pools. There are items that may or may not be needed to be installed for your cleaner to function properly. - Page 6 HOSE BALANCE (OPTIONAL) HOSE BALANCE (OPTIONAL) You may also need to attach hose weights to neutralize the hose’s buoyancy in the water. For aboveground pools with the flat bottoms, typically one weight is needed. It should be placed on the first section of hose, between 4 to 12 inches away from the body’s swivel head.
- Page 7 If debris is still lodged inside the cleaner, you must remove the flapper. To do this you must take out the four red plugs in the foot pad. These are found on the bottom of the cleaner. They can be removed using a flat head screwdriver. Underneath there will be four screws.
-
Page 8: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING SOLUTION POSSIBLE CAUSE PROBLEM 1. Vacuum moves too • Filter is dirty. • Backwash or clean slow or not at all element. • Skimmer or pump strainer baskets are clogged with • Empty baskets out. debris. • Turn cleaner over and •... -
Page 9: Year Limited Warranty
• Customer must retain the original sales invoice as proof of purchase along • Commercial facilities are not covered by warranty Please return any and all defective items to your local authorized Blue Torrent dealer for inspection. The customer is responsible for all shipping charges to and from the nearest Factory Warranty Center.
