Summary of Contents for Britax B-SCENE
- Page 1 B-SCENE™ Stroller User Guide IMPORTANT: To ensure your child is as safe as possible, read all instructions thoroughly before using this stroller. Store this manual for future reference.
-
Page 3: Table Of Contents
B-SCENE™.Stroller.Configurations. . . . . . . . . . . . . . . . . . . . . -
Page 4: Warnings
Britax. They may cause the stroller to become unstable. • Only use Britax approved child restraints or car seats with this stroller without the use of the Infant Car Seat Adapter Frame. • Do not allow children to climb on or play with the stroller. - Page 5 • Always set the parking brake when stroller is not moving. • Only use accessories and replacement parts approved by Britax Child Safety, Inc. • Do not lift the stroller by the arm bar of the seat when the seat is occupied.
-
Page 6: Features
Features Canopy Handle. Height. Adjuster Arm.Bar Harness Frame. Release. Lever Buckle Seat.Locking.Latch Chassis.Socket Release.Lever Leg.Rest Chassis. Front. Lock Wheel. Release On.right.side. of.frame Rear.Wheels Swivel. Under-Seat. Lock Storage. Rear.Wheel. Basket Release.Button Front.Wheel • Actual product may vary from images. -
Page 7: In.the.box
In the Box Front.Wheel Seat Rear.Wheels Arm.Bar Stroller.Frame Britax.Infant.Car. seat.Adapters Rain.Cover... -
Page 8: Assembly
Assembly Unfolding • Lift chassis lock lever and open the frame • Lift handle until frame locks into upright position as shown Front Wheel • Slide mounting pin into the housing on the frame until it locks into place NOTE: Always make sure the front and rear wheels are locked into place and that the brake functions properly before each use... -
Page 9: Rear Wheels
Assembly Rear Wheels NOTE: Left and right wheels are marked with an L or R and are from the perspective of standing behind the stroller • Hold in the release button in the center of the wheel and slide the mounting pin into the housing on the rear axle Arm Bar •... -
Page 10: Removing Front Wheel
Assembly Removing Front Wheel • To remove, pull the wheel release lever on the front hub until the wheel assembly releases Removing Rear Wheels • Press and hold the release button in the center of the wheel and pull away from the wheel housing... -
Page 11: Attaching The Canopy
Assembly Attaching the Canopy • Line up the bracket on the canopy stay with the canopy mount on the frame of the seat • Slide the bracket onto the canopy mount until it locks into place • Attach the six hook and loop fasteners to the back of the seat... -
Page 12: Operating.instructions
Operating Instructions Parking Brake • Step on the brake pedal until the indicator window changes color NOTE: Red indicates the brake is engaged and green indicates the brake is off Attaching the Seat • Insert the seat locking latches into both chassis sockets •... -
Page 13: Detaching The Seat
Operating Instructions • Pull up on the seat to ensure that it is locked into place correctly Detaching the Seat IMPORTANT: Always remove child before detaching the seat • Lift both release levers on each seat locking latch at the same time •... -
Page 14: Folding
Operating Instructions Folding IMPORTANT: Always apply brake and remove children before folding the stroller • Pull up both frame release levers located just below the stroller handle, and press the stroller handle down • Continue folding until the chassis lock engages TIP: You may need to compress the frame to engage the chassis lock Swivel Wheels... -
Page 15: Leg Rest
Operating Instructions Leg Rest • Depress buttons on both sides of the leg rest hinge and hold while raising or lowering the leg rest to the desired position Recline • Lift and hold the recline lever on the back of the seat and hold while raising or lowering the seat back to the desired position... -
Page 16: Securing.your.child
Securing Your Child • Release the harness by depressing the button in the center of the buckle while pulling the two top tongues away from the buckle assembly • Sit child in seat and unzip the seat back to access the harness height adjuster TIP: You may need to loosen the harness to adjust the harness height... - Page 17 Securing Your Child • Buckle the harness by pressing the tongues on the harness straps into the buckle assembly NOTE: Ensure the straps are not twisted as they may become uncomfortable for the child • Tighten or loosen the harness straps by sliding the harness adjusters Buckle tongues separate for added safety.
-
Page 18: Infant.car.seat.mode
Infant Car Seat Mode Attaching Britax Infant Car Seat Adapters • Slide each of the adapters under the infant car seat handle and into the shell until they click into place NOTE: There is a left and right adapter and orientation should be as shown •... -
Page 19: Attaching A Britax Infant Car Seat
Infant Car Seat Mode Attaching a Britax Infant Car Seat • Lock the parking brake • Align the adapters and insert into both chassis sockets • Push down until a click is heard • Pull up on the seat to ensure... -
Page 20: Removing A Britax Infant Car Seat
WARNING • The infant car seat adapters are ONLY compatible with Britax infant car seats and ONLY models from 2009 or newer • Attempting to fit them into another infant car seat can damage the car seat or cause the car seat to fall •... -
Page 21: Accessories
Accessories Rain Cover • Extend the canopy and lay the rain cover over the canopy until the recline lever lines up with the slot on the back of the rain cover • Slide the elastic strap under the foot rest to the bottom of the seat •... -
Page 22: Other.available.accessories
Other Available Accessories Bassinet Infant Car Seat Adapter Frame Makes the stroller compatible Turns the B-SCENE™ Stroller with major manufacturer’s into a bassinet style stroller infant car seats Child Cup Holders UV/Mosquito Cover Easy storage for drinks and Protects your child from sun... -
Page 23: B-Scene™.Stroller.configurations
Other Available Accessories Boot Cover Extra protection from the cold for your child B-SCENE™ Stroller Configurations... - Page 24 B-SCENE™ Stroller Configurations • Bassinet and Infant Car Seat sold seperately...
-
Page 25: Care.and.maintenance
Care and Maintenance Parking.Brake. • Periodically check that the parking brake works properly and locks both wheels securely . • Clean out any dirt or debris that may prevent the brake from working . Frame. • Wipe the frame with a damp cloth and mild soap . Use clean, dry cloth or towel to wipe away excess water and soap . -
Page 26: Warranty
. The use of non-Britax Child Safety, Inc . accessories is not approved by Britax . The use of unapproved accessories could cause this product to become damaged or dangerous . Their use automatically voids the Britax warranty . - Page 28 Visit.our.website.at.www .Britax .com.for.more.information . Britax Child Safety, Inc. Tel. : 1-888-427-4829 13501 South Ridge Drive Charlotte, NC 28273 www.Britax.com A Britax Childcare Group Limited company...
