Summary of Contents for EVIQO EVIPOWER
- Page 2 eviqo.io...
- Page 4 You will need to reconfigure the device and pair it again with the EVIQO app. 3. Your phone must be very close to the EV charger, please allow the EVIQO app 10-60 seconds to find a new device. Once done, follow the next steps in the app.
- Page 5 I set the Schedule but it didn’t start when it was supposed to. Why? Check Wifi connection. Please also check the time zone in the EVIQO app. The charger picks the time zone based on the IP address of the wifi router it’s connected to.
- Page 6 Dip switch is a hardware maximum current output limiter. The current slider located on the main page of the EVIQO app is limited with the output set on the dip switch. The slider in the mobile app has 1A step.
- Page 7 ©2025 EVIQO TECHNOLOGIES LIMITED. All rights reserved. This material is protected by copyright laws in the United States and other countries. It may not be modified, reproduced, or distributed without the prior express written consent of EVIQO TECHNOLOGIES LIMITED. The trademarks and service marks "EVIQO" and "EVIPOWER" are registered trademarks of EVIQO TECHNOLOGIES LIMITED in the United States and other countries and cannot be used without the prior written consent of EVIQO TECHNOLOGIES LIMITED.
-
Page 8: Table Of Contents
YOUR VERSION 6. WIRE THE CIRCUIT 7. PLAN THE MOUNTING LOCATION 8. MOUNTING 9. CONFIGURING YOUR DEVICE 10. LIGHT CODES 11. RESET AND HARD REBOOT BUTTON 12. Charging port open / release button (NACS) 12. LIMITED WARRANTY 13. COMPLIANCE eviqo.io... -
Page 9: Important Safety Instructions
It's recommended to install this device in a sufficiently ventilated area and preferably avoid installing it in areas with extreme direct sunlight. ● WARNING: In case of flooding, do not operate EVIQO charger while it or your EV is submerged in water. ● WARNING: If EVIQO charger was submerged in water due to flooding, make sure a qualified electrician inspect it before energizing or using it again. -
Page 10: Installation Requirements
NEMA 14-50 receptacle and wiring (plug-in installation). WARNING: Disconnect electrical power to install the charging station. WARNING: Be sure to preview this Installation Guide before installing the EVIQO Smart EV Charger. WARNING: Your EVIQO charger must be grounded to ensure safety. -
Page 11: Product Introduction And Data Sheet
EVIQO customer service. ● CAUTION: Please use the charger properly. Do not hit or press hard on the enclosure. If it is damaged, please contact a professional technician or EVIQO TECHNOLOGIES. ● CAUTION: Take necessary precautions with electronic medical implants. ●... -
Page 12: Basic Dimensions
2.2 Basic Dimensions eviqo.io... - Page 13 2.3 Specifications of EVIQO Smart EV Charger — EVIPOWER248J J1772 connector model (40A Model Number plug-in or 48A hardwire); — EVIPOWER248N J3400 connector model (40A plug-in or 48A hardwire). 208-240 V AC Rated Input Voltage Rated Output Current 16A / 32A / 40A (plug-in max) / 48A (hardwire max) 37”...
-
Page 14: Verify Contents
3. Verify Contents Check the list to ensure you have this Installation Guide and all the parts listed below: Note: If you are missing any of these parts, please contact support@eviqo.io eviqo.io... - Page 15 Holster masonry, brick or concrete walls for the Holster wall-mounted bracket installation. Allen Wrench For tightening Anti-Theft Button Head Screws on the sides of EVIQO Smart EV Charger. Anti-Theft Button Head For securing the EVIQO EV Charger and Screws the Holster to their Mounting Brackets.
-
Page 16: Gather Tools
4. Gather Tools For comfortable installation of the EVIQO Smart EV Charger and depending on the type of installation (plug-in or hardwire), you might need: 1) NEMA 14-50P 240V outlet or electrical materials for hardwire installation, depending on your specific case (consult with the licensed installer). -
Page 17: Plan The Installation Type Based On Your Version
(three hours or more) to more than 80% of their maximum rated capacity. EVIQO 40A plug-in version is equipped with NEMA 14-50 input power plug and is set for 40 Amps of max output load (Number “2” on the Amperage Dip Switch located inside the device) by default. - Page 18 It is small and gray in color. Amperage Dip Switch To decrease the default Max Output Load of EVIQO Smart EV Charger to 32 Amps - choose “1” on the Amperage Dip Switch. For 16 Amps - choose “0”, respectively.
-
Page 19: Wire The Circuit
Install the outlet with the ground prong facing up. Plug in the Charger. For a hardwired installation of the 40A plug-in version of EVIQO Smart EV Charger, remove the original input power cable with NEMA 14-50 plug first. To remove the faceplate —... -
Page 20: Plan The Mounting Location
EV Charger. Note the distance to the breaker panel and/or the junction box. The hardwire version of EVIQO Smart EV Charger comes with a 39” (around 1m) 3-wire whip with liquid tight connector and conduit. If you hardwire a 40A plug-in version of EVIQO Charger - plan your mounting location based on your custom wiring. -
Page 21: Mounting
E. Ground connection for hardwire installation: follow the National Electrical Code and all local applicable codes. In case of Ground Fault - please consult a licensed electrician. F. If you decide to install the EVIQO Smart EV Charger outdoors, this requires using an outdoor-rated, weather-resistant NEMA 14-50 outlet / hardwired installation. - Page 22 EVIQO Smart EV Charger onto the wall. For wood studs and drywalls: use the Phillips Pan Head Screws provided to fix the wall-mounted bracket for the EVIQO Smart EV Charger onto the wall. Make sure the surface is sufficiently thick to hold the EV Charger...
-
Page 23: Final Preparation
Q-indicator will get solid green, indicating it is ready to charge. By default the EVIQO Smart EV Charger is set for Plug & Charge mode – just plug in the connector to your car and the charging session will start automatically. -
Page 24: Configuring Your Device
To re-enter configuration mode, perform a hard reboot (see Question 4 on page 4 of this Installation Guide). This will clear the device's configuration. Note: To download the EVIQO mobile app, please use the QR codes. EVIQO APP GUIDE: EVIQO YouTube Videos:... - Page 25 Usage Details page of the EVIQO app. Press on the charts to see the stats for a specific day. Leverage the Timeline feature (press “...” in the top right corner of the main page) to gain insights into your charging habits and effectively manage costs.
-
Page 26: Light Codes
Plans. This feature simplifies the scheduling process and helps you optimize your charging sessions. The EVIQO app offers reminders to plug in before scheduled sessions, provides push notifications with session stats upon completion, and prevents conflicting schedules that overlap. -
Page 27: Errors And Warning Messages
Voltmeter Fault Meter fault time b) If the fault persists, contact EVIQO technical support. a) Unplug the J1772/J3400 connector and reboot the charger. b) Make sure the CP (Control Pilot) line is fixed in the right place. - Page 28 Unplug the J1772/J3400 connector and reboot the charger Flashing red 8 Relay failure during if the problem persists after the Relay Fault times charging unplugging. 3 seconds interval b) Avoid prolonged simulator or loading machine usage. eviqo.io...
-
Page 29: Reset And Hard Reboot Button
You will hear a beep sound. Please wait 1-2 minutes for the unit to reset to factory settings. You will need to reconfigure the device and pair it again with the EVIQO app. ATTENTION: To prevent accidental resets that could disrupt charging, accidental clicking on the reset button of less than 1 second does nothing. -
Page 30: Charging Port Open / Release Button (Nacs)
Limited Warranty for EVIPOWER Smart EV Charger by EVIQO. This Limited Warranty (“Warranty”) is applicable to the original purchaser of a new EVIPOWER Smart EV Charger by EVIQO ("EV Charger") for residential use in the USA and Canada. The Warranty is non-transferable and exclusively valid for the purchaser. - Page 31 In cases where the EV Charger is determined by EVIQO to be out-of-warranty or ineligible for warranty service, it will be returned to you. However, if you approve, EVIQO can provide repair or replacement services at their standard charges, which will be at your expense.
- Page 32 If, upon reviewing your request, it is determined by EVIQO that the defect appears to be covered by your valid Warranty, and your Warranty is still in effect, EVIQO will issue you an RMA number and provide you with the address to return the defective EV Charger.
-
Page 33: Compliance
14. Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2BG8P-EVIPOWER248J for J1772 connector model (both 40A and 48A);... -
Page 34: Installation Notes
Installation notes eviqo.io... - Page 36 eviqo.io...
