Summary of Contents for Blue Torrent TYPHOON 48
- Page 1 TYPHOON 48 INGROUND POOL PUMP INSTRUCTION MANUAL READ THIS MANUAL CAREFULLY BEFORE USING YOUR POOL PUMP 8258...
- Page 2 IMP BLUE TORRENT PUMP PARTS BREAKDOWN DESCRIPTION 1000 IMP 1500 IMP 750 IMP PART # MODEL # AC 23248 Lid Knobs AC 30341 Strainer Lid AC 30376 Strainer Lid Gasket AC 30333 Strainer Basket AC 23345 Strainer Housing AC 23558...
-
Page 3: Important Safety Instructions
5 feet of the swimming pool. All local points should be bonded with #8AWG (8.4mm2) wire. To installer and/or operator of the Blue Torrent swimming pool pump: the NOTE manufacturer’s warranty will be void if the pump is improperly installed... -
Page 4: Pump Installation
PUMP INSTALLATION 1. When connecting plumbing fittings to the pumps threaded ports, it is recommended that thread seal tape (Teflon tape) be used. If the suction (intake) connection is not sealed correctly the pump will not prime properly and will pump only small volumes of water or no water at all. -
Page 5: Pump Location
PUMP LOCATION 1. Locate the pump on a level surface as close to the pool as practical. Consult local codes for minimum distances between pool and pump if applicable. 2. The connection plumbing (hose or rigid pipe) should be direct and as free from turns and bends as possible. -
Page 6: Troubleshooting Guide
TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Pump will not Prime Suction Air Leak Make sure see thru lid and gasket are clean, lubed and tightened. Tighten all hoses and pipes on the suction side of the pump. Be sure water level in the swimming pool is high enough to flow through skimmer. - Page 7 STANDARD WIRING FOR 220V — See Motor Label for Details — If you are connecting your Blue Torrent Pump to a 220V power source follow these simple directions. Remove the rear housing to expose the electric connection plate Your New Blue Torrent Pump is pre-wired for 220V operation...
- Page 8 STANDARD WIRING FOR 110V — See Motor Label for Details — If you are connecting your Blue Torrent pump to a 110V power source follow these simple directions. Remove the rear housing cover to expose the electric connection plate Move the white wire (not your power cord white) —the short white wire inside the motor housing- from the current location to the clip pin located in the center of the connection plate.
