Hasselblad HC MACRO 4-120-II - DATASHEET V2 Datasheet

HASSELBLAD HC Macro 4/120-II

General lens data:

Focal length
Equivalent focal length with 36x48 format
Equivalent 35mm focal length
Aperture range
Angle of view diag/hor/vert 645 format
Length/diameter
Weight
Filter diameter

Close focus range data:

Minimum distance object to film
Maximum image scale
Corresponding area of coverage
Corresponding exposure reduction

Compatibility

When the HC Macro 120-II is used together with the H1,7X converter, the autofocus function of the camera is disabled.

Lens design

9 elements in 9 groups

Focus type

Front focusing

Entrance pupil position

149 mm in front of the image plane
(at infinite focus setting)
The entrance pupil position is the correct position of
the axis of rotation when making a panorama image
by combining individual images of a scene.
Mtf
At infinity setting
Modulation Transfer as a function of image
height at infinite focus setting.
Sagittal slit orientation drawn with continu-
ous line and tangential with dashed. White
light. Spatial frequencies 10, 20 and 40
lp/mm.
118.7 mm
135.0 mm
73.5 mm
4 - 45
33°/26°/21°
166 mm/96 mm
1410 g
67 mm
0.39 m
1:1
56 x 41.5 mm
1.3 f-stop
LENSES
