original operating instructions
electric dumper MD-500EK
Model: MD-500EK
Both the model number and the serial number can be found on the rating plate on the
electric dumper. You should keep both numbers safe for future reference. This manual
explains the functions and applications of the machine.
Before commissioning, read the operating instructions and observe the safety and warning
instructions!
Serial number: ______________________________
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lumag MD-500EK
Summary of Contents for Lumag MD-500EK
- Page 1 Translated from German to English - www.onlinedoctranslator.com original operating instructions electric dumper MD-500EK Model: MD-500EK Serial number: ______________________________ Both the model number and the serial number can be found on the rating plate on the electric dumper. You should keep both numbers safe for future reference. This manual explains the functions and applications of the machine.
-
Page 2: Table Of Contents
CONTENTS CONTENTS 1. GENERAL 1.1 INFORMATION ON OPERATING INSTRUCTIONS 1.2 LIMITATION OF LIABILITY 1.3 COPYRIGHT 2. SCOPE OF DELIVERY 3. INTENDED USE 4. TECHNICAL DATA 5. ENVIRONMENT 6. SYMBOLS 6.1 MACHINE 6.2 BATTERIES 7. SAFETY 7.1 WARNINGS 7.2 BATTERIES/CHARGER 7.3 OPERATIONAL SAFETY 7.4 SAFETY IN USE AND CARE OF THE MACHINE 7.5 SERVICE SECURITY... -
Page 3: General
GENERAL 1. GENERAL 1.2 LIMITATION OF LIABILITY We have endeavoured to provide as comprehensive INFORMATION ABOUT information as possible on accident prevention during OPERATING INSTRUCTIONS operation, but cannot be held responsible for any lack of completeness of the danger points listed and This operating manual provides important - sources should be held accountable. -
Page 4: Scope Of Delivery
SCOPE OF DELIVERY / INTENDED USE 2. SCOPE OF DELIVERY strong driving force on inclines. The machine is equipped as standard with two drive wheels, a swing axle with two wheels and a tipping trough. After unpacking, check the contents of the box/ Unlocking and tipping are done electrically. -
Page 5: Technical Data
TECHNICAL DATA / ENVIRONMENT / SYMBOLS 4. TECHNICAL DATA 6. SYMBOLS Model MD-500EK MACHINE 1000 watts Performance Symbols are attached to the machine. These nominal voltage 48 volts DC 12V, 32Ah, 4 pieces represent important information about the product drive / battery rechargeable or instructions for use. -
Page 6: Batteries
Security work area enough BATTERIES In the Danger, regard. open space disorder Danger of tripping! Batteries/cells are heavy! Make sure result in accidents. they are installed safely! explosion fire hazard, short circuits avoid! Danger! Keep bystanders away. Metal parts of the battery cell are always live, so do not place foreign objects or tools on the battery. -
Page 7: Safety
Security 7. SAFETY BATTERIES/CHARGER This section provides a comprehensive overview of Careful handling and use of batteries all important safety aspects for optimal protection and chargers of the operator as well as for safe and trouble-free operation. Batteries and chargers are not toys and must not be allowed to fall into the hands of children. -
Page 8: Operational Safety
Security Make sure the machine is turned off before should first-time users itself Salesperson from the inserting batteries. Inserting batteries into a to familiarise yourself with the characteristics of the machine that is turned on may result in accidents. motor-driven machine, its intended use and the necessary safety devices. - Page 9 Security Do not use the machine for purposes for which it is and cannot tip, roll, slip or fall during operation. not intended (see “Intended use”). Keep hands, feet, loose clothing and body jewelry The effectiveness of the controls must not be away from moving or rotating machine parts.
-
Page 10: Safety In Use And Care Of The Machine
Split described in this manual. All other work must be This may cause a short circuit. carried out by a specialist workshop or LUMAG service workshop. Do not immerse the machine, power cord or connectors in water or other liquids. Keep the handles dry, clean and free of foreign objects. -
Page 11: Residual Risks And Protective Measures
Security Never transport people, children, pets or livestock booth. with the machine. shocks, falls, vibrations Careless handling of the machine can cause Never transport dangerous objects or materials damage to the battery and result in serious injuries. with the machine. →... -
Page 12: Behavior In An Emergency
PART NAME, FUNCTION 8. PART NAME, BEHAVIOR IN AN EMERGENCY function If an accident occurs, initiate the necessary first aid measures and request qualified medical assistance as quickly as possible. When requesting assistance, please provide the following information: where it happened - what happened - how many injured - what type of injury - waiting for response safety lever backup... - Page 13 PART NAME, FUNCTION capacity display on the left handlebar battery let them brake direction switch (5) on the left The capacity indicator shows the remaining voltage of the batteries. When fully charged, this shows 52.0V. When the remaining voltage is 45.0V, the batteries must be charged.
- Page 14 PART NAME, FUNCTION dump switch (7) - control element on the control panel Open the rubber cap The trough can be tilted electrically. charger with the socket Tilt the trough, turn the switch to the left to “UP” and hold. by means of Bring the trough into its original position, turn the switch to the right to “DOWN”...
-
Page 15: Transport, Installation
TRANSPORT, INSTALLATION / OPERATION 9. TRANSPORT, INSTALLATION 10. OPERATION If the machine has to be transported over a long 10.1 COMMISSIONING distance, it can be loaded onto a truck or other suitable transport vehicle. The machine must not be Before operating the machine, please read this loaded. -
Page 16: Turn On And Drive
Operation 10.2 TURN ON AND DRIVE The batteries are located under the control panel. If only the battery capacity indicator shows 45V, 1. The switch (6) is in the “OFF” position, charge the batteries before using the machine again. See ..CHARGING THE BATTERIES (10.6). 2. -
Page 17: Brake System
Operation 10.4 TURN OFF To turn off the machine, turn the switch counterclockwise to OFF. 10.5 LOADING AND UNLOADING THE TIPPER Loaded When loading, ensure that the machine is stable and that the goods to be transported are securely anchored. Distribute the goods to be transported evenly in the trough. -
Page 18: Charging The Batteries
Operation 10.6 CHARGING BATTERIES Before and during charging, be sure to switch off the drive and set the main switch (6) to the "off" position! To charge the batteries, the plug must be connected to a 230V/50Hz AC power supply. Explosive gas mixtures are created when charging the batteries. -
Page 19: Batteries
OPERATION / CONTROLS 11. CHECKS A NOTICE The charging time depends on the discharge level Regular inspections are essential if the machine is of the batteries. However, a battery that is not to remain a reliable work tool. deeply discharged should be charged within 12 hours (max.). -
Page 20: Electromagnetic Brake
Never drive with a defective brake!In this case, carried out by qualified electricians! please contact your dealer or manufacturer. Never work without protective devices. Only use original LuMAG spare parts. 11.6 TIRES 12.1 BATTERIES/CHARGER Check the wheels, tire pressure and tire condition Fully charge the batteries before using the at regular intervals. -
Page 21: Transmission
°C. Store the batteries out of direct sunlight. Use commercially available multi-purpose oil to If the batteries are no longer functional, please lightly oil all moving parts. contact an authorized dealer or the LUMAG service team. 12.4 LUBRICATION POINTS Use suitable protective gloves when disposing of defective batteries. -
Page 22: Maintenance & Storage
MAINTENANCE / STORAGE 13. STORAGE 80 operating hours - must be lubricated by the operator using a grease gun (not included). This offers a longer service life and the best possible If the machine is not used for a long period of mobility of the wheel suspension. -
Page 23: Troubleshooting
TROUBLESHOOTING 14. TROUBLESHOOTING cause remedy Disturbance Key switch not switched on Turn on Machine does not run or does parking brake active release the parking brake not deliver enough power charging batteries batteries almost empty batteries empty charging batteries Check that the cable is firmly seated, Loose electrical connections or No capacity display on the tighten if necessary, replace damaged... -
Page 24: Warranty / Guarantee / Customer Service
Warranty work is carried out exclusively by our temperature or weather influences, as well as LUMAG service workshop. Defects that occur within defects resulting from negligent assembly, faulty the warranty period due to material or... -
Page 25: Ec Declaration Of Conformity
Fax: 0049 / (0)8571 / 92 556-19 that the product Designation: electric dumper Type designation: MD-500EK meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk reduction... -
Page 26: Components Of The Machine
COMPONENTS OF THE MACHINE 17. COMPONENTS OF THE MACHINE / General view... -
Page 27: Electrical Control
ELECTRICAL CONTROL 18. Electrical control... - Page 28 LuMAG GmbH Rudolf-Diesel-Straße 1a D-84375 Kirchdorf am Inn Telephone: +49 (0)85 71 / 92 556 - 0 Fax: +49 (0)85 71 / 92 556 - 19 www.lumag-maschinen.de Status: 01/2024 - MD500EK_V4...
