Firmware: 240618-GD
Article number: BEG32060
Manual AHD video
Package:
1. Power cable: 1x
2. JbyJ cable: 1x
3. Dua fakra lcd cable: 1x
4. Multi AV cable: 1x
5. Remote: 1x
6. IR eye 4P: 1x
7. Toggle button: 1x
8. Interface module: 1x
9. Manual: 1x
Installationsanleitung MBUX Interface Sprinter NTG7
interface Mercedes
Designed for Mercedes with NTG7
TLT-031 V1.0
12.11.2024
Advertisement
Table of Contents
Related Manuals for Brigade BEG32060
Summary of Contents for Brigade BEG32060
- Page 1 ____________________________________________________________________________________________ Firmware: 240618-GD Article number: BEG32060 interface Mercedes Manual AHD video Designed for Mercedes with NTG7 Package: 1. Power cable: 1x 2. JbyJ cable: 1x 3. Dua fakra lcd cable: 1x 4. Multi AV cable: 1x 5. Remote: 1x 6. IR eye 4P: 1x 7.
-
Page 2: Table Of Contents
____________________________________________________________________________________________ Content 1: IMPORTANT INFORMATION ............................. 2 2: INSTALLATION & SAFETY INSTRUCTIONS ......................... 3 3: SCOPE OF DELIVERY ..............................3 4: COMPATIBILITY ................................. 4 4.2 Requirement ..............................5 5: WIRE DIAGRAM ................................ 6 5.1 Pin connection vehicle ............................6 5.2 Pin connection interface ............................ 6 5.3 Dipswitches ................................ -
Page 3: 1: Important Information
____________________________________________________________________________________________ 1: IMPORTANT INFORMATION Installation must be done by a qualified personnel. Installation of the interface is entirely at your own risk. We accept no liability for damage to the vehicle or personal injury. If the manual is not well enforced and / or the interface is incorrectly connected, the guarantee claim as well the operating permission becomes invalid. -
Page 4: 2: Installation & Safety Instructions
____________________________________________________________________________________________ 2: INSTALLATION & SAFETY INSTRUCTIONS Installation must be done by a qualified personnel. Do not install this interface by yourself. For safe and reliable installation, consult a dealer having special knowledge. o Use the device only at a +12 & +24 volt vehicle electrical system. Make sure to have a proper ground. o The device should not be set up in direct proximity of heat sources (e. -
Page 5: 3: Scope Of Delivery
____________________________________________________________________________________________ 3: SCOPE OF DELIVERY Scope of delivery Package: 1. Power cable: 1x 2. JbyJ cable: 1x 3. Dua fakra lcd cable: 1x 4. Multi AV cable: 1x 5. Remote: 1x 6. IR eye 4P: 1x 7. Toggle button: 1x 8. -
Page 6: Requirement
____________________________________________________________________________________________ 4.2 Requirement AUDIO OUTPUT The interface inserts ONLY video signals into the infotainment. It is essential to have an Aux-in, when using audio from an external AV source. CVBS NTSC_PAL_AHD720_AHD1080 SCREEN Interface is compatible with NTG7 10.2inch / 12.8inch FRONT CAMERA The front camera input will automatically switch after leaving the reverse gear. -
Page 7: 5: Wire Diagram
____________________________________________________________________________________________ 5: WIRE DIAGRAM 5.1 Pin connection vehicle SIGNAL COLOR WIRE POSITION CAR Ignition 12V or 24V Fuse box SIGNAL COLOR WIRE POSITION CAR – 26 pins connector CAN-HIGH Purple/white Back of radio – pin 7 White/yellow CAN-LOW Purple Back of radio – pin 20 Yellow Ground Brown... - Page 8 ____________________________________________________________________________________________ 5.2 Pin connection interface Power cable Color/pin Label Function Permanent power (fuse 3A) Ground GEAR-H CAN-HIGH - GEAR GEAR-L CAN-LOW – GEAR JOG-H CAN-HIGH – JOG JOG-L CAN-LOW – JOG No function No function No function ACC detection wire AV cable (HAVCAB0073 K) Color Label...
-
Page 9: Dipswitches
____________________________________________________________________________________________ 5.3 Dipswitches Dipswitch UP: Dipswitch DOWN: DIPSWITCH S/W (8 ) Function Selection MONITOR OFF = 10.2ich (B-class & Sprinter) ON = 12.8inch (C-class W206 & S-class W223) FRONT CAM - SKIP OFF = FRONT CAM input activated ON = Skip FRONT CAM input REAR INPUT OFF = Skip REAR CAM input ON = REAR CAM input activated... -
Page 10: Led
____________________________________________________________________________________________ 5.4 LED Check the status LED on the interface: Led color Description interface receive power via power connector Interface receive a video signal on the selected input 5.5 Remote Connect the IR wire with the interface box input “KEY/IR”: (always install IR wire so you can always service/reset the interface) POWER •... - Page 11 ____________________________________________________________________________________________ Interface Reset Press and hold arrow right button for 5 seconds Entering OSD Press MENU button when interface is activated menu OSD: Factory Press and hold arrow left button for 5 seconds mode: Select the rear camera mode and press and hold the remote PIP button to activate/deactivate the splitscreen function.
-
Page 12: Overview
____________________________________________________________________________________________ 5.6 Overview Installationsanleitung MBUX Interface Sprinter NTG7 TLT-031 V1.0 12.11.2024... -
Page 13: 6: Installation
____________________________________________________________________________________________ 6: INSTALLATION 6.1 De-installation Attention; do not install the interface when the ignition is ON. (Based on Sprinter) 1: Remove the two air intakes from Mercedes with the special Mercedes tool. 2: After removing the two air intakes, you see two torx screws. Remove the two torx screws. 3: Remove the plastic screen covers. -
Page 15: Lcd Connector
____________________________________________________________________________________________ 6.2 LCD connector 1: Remove the original LCD cable (pink or green) from the original MBUX head-unit. Pink LCD cable Green LCD cable 2: Connect the original LVDS cable with the interface Y-cable and the other side with the MBUX head-unit. 3: Connect the Y-cable single fakra (which is connected with OEM LCD cable) with “LVDS OUT”... -
Page 16: Power Cable
____________________________________________________________________________________________ 6.3 Power cable 1: Disconnect the OEM power cable from the backside of the head-unit 2: Connect the OEM cable to the supplied interface JbyJ cable (HAJBJCA0016). 3: Connect the supplied male jbyj cable (HAJBJCA0016) to the backside of the head-unit. 4: Connect supplied JbyJ cable (HAJBJCA0016) to the supplied power cable (HPOWER0324) and the other end with the interface input “POWER/CAN”. -
Page 17: Rear Camera
____________________________________________________________________________________________ 6.4 Rear camera Take the following steps when connecting an aftermarket rear camera: 1: Connect the rear camera RCA plug with the interface RCA plug on the multi cable “R-CAM” (HAVCAB0073 K). 2: Put dipswitch in the position (DOWN). REAR DET (grey wire) When the interface does not respond on reverse CAN-BUS (happens with manual gear box), connect the grey “Rear Detection”... -
Page 18: Front Camera
____________________________________________________________________________________________ 6.5 Front camera Do the following steps when installing front camera 1: Connect the camera RCA plug with the interface RCA plug on the multi cable “F-CAM” (HAVCAB0073 K). 2: Put dipswitch in the position (UP). 3: It is possible to adjust the time delay of the front camera via the OSD menu: Select the Time delay via the OSD menu: a) Put dipswitch 6 in OFF position (to activate front camera input) b) Press the OK button ((to activate front camera input) -
Page 19: Left And Right Camera
____________________________________________________________________________________________ 6.6 Left and Right camera Do the following steps when installing left camera 1: Connect the camera RCA plug with the interface RCA plug on the multi cable “LET-CAM” and/or RGT-CAM (HAVCAB0073 K). 2: Select the OSD setting: a) Put dipswitch 6 in OFF position (to activate front camera input) b) Press the OK button ((to activate front camera input) c) Press and hold arrow left button (to activate factory OSD mode) d) Go to “VEHICLE OPTION”... - Page 20 ____________________________________________________________________________________________ 3: Interface switch by CAN or you can connect the LEFT or RIGHT indicator wire*. Color Label Function LEFT +12V / +24V LEFT trigger wire Color Label Function RIGHT +12V / +24V LEFT trigger wire *Make sure the SIDE FUNC setting is: CAM (L) or CAM (R) or ALL Power output wire When the left camera input is selected, below wire send out a 12/24V signal.
-
Page 21: Mode Button
____________________________________________________________________________________________ 7: ACTIVATION 7.1 Activation Video-interface: There are different ways to activate the interface. MODE BUTTON Press switch to toggle between different inputs. REMOTE Press “OK” button to toggle between different inputs. OEM BUTTON Installationsanleitung MBUX Interface Sprinter NTG7 TLT-031 V1.0 12.11.2024... -
Page 22: Hdmi Input
____________________________________________________________________________________________ Installationsanleitung MBUX Interface Sprinter NTG7 TLT-031 V1.0 12.11.2024... -
Page 23: Picture In Picture
____________________________________________________________________________________________ 7.2 Picture in Picture Use the PiP function on the remote control to change the camera picture. Select the rear camera mode and press and hold the remote PIP button to activate/deactivate the splitscreen function. OPTION 1 OPTION 2 OPTION 3 OPTION 4 Installationsanleitung MBUX Interface Sprinter NTG7... -
Page 24: 8: Osd Settings
____________________________________________________________________________________________ 8: OSD SETTINGS 8.1 FACTORY-MODE Press and hold arrow left button to activate OSD menu. The interface OSD menu has the following chapters: DISPLAY COLOR Menu VERHICLE OPTION Menu SETUP SYSTEM Menu PARKING ASSISTANCE Menu INFORMATION menu DISPLAY COLOR Display Color Vehicle Option Brightness:... - Page 25 ____________________________________________________________________________________________ VEHICLE OPTION Display Color Car Model: BENZ Vehicle Option Rear Detect: CAN Setup System Auto Fcam: OFF Setup Utility Parking Assistance Information CAR MODEL : select the right car model for CAN communication BENZ REAR DETECT : detection rear camera input LAMP: detecting the rear view camera via “Grey Rear”...
-
Page 26: Setup System
____________________________________________________________________________________________ SETUP SYSTEM Display Color System Rest: NO Vehicle Option Side Cam Detect: CAM-ALL Setup System Setup Utility Parking Assistance Information SYSTEM REST : put back factory settings YES: reset will be activated NO: no reset SIDE CAM DETECT: Activation side camera input LEFT: Left camera input activated RIGHT: Right camera input activated CAM ALL: Left &... -
Page 27: Setup Utility
____________________________________________________________________________________________ SETUP UTILITY Display Color Fcam Format: NTSC Vehicle Option HD1 MODEL : touch setting HDMI input Rcam Format: NTSC NONE – skip HDMI input (DEFAULT) Setup System Auto Detect: ON SUNE10 Setup Utility UART2USB Left cam Format: NTSC SE-TV Parking Assistance Right cam Format: NTSC QROIX-HD... -
Page 28: Parking Assistance
____________________________________________________________________________________________ PARKING ASSISTANCE Display Color Vehicle Option Guide H-Offset : 20 Setup System Guide V-Offset : 20 Setup Utility Guide Display : NONE Parking Assistance Guide Option : WIDE2 Information GUIDE H-OFFSET: adjusting the horizontal guide lines (left/right) 1 - 40 (DEFAULT = 20) GUIDE V-OFFSET: adjusting the vertical guide lines (up/down) 1 - 40 (DEFAULT = 20) GUIDE DISPLAY: select your IPAS view... -
Page 29: 9: Warranty
____________________________________________________________________________________________ 9: WARRANTY The product is designed for automotive use and his environment. The warranty of the product is one year. No warranty: • not break the labels attached on the board. • Damaged of the interface • Own reparations •...
