- Page 1 MODERN SEMI-PRIVACY HORIZONTAL FULL SIZE FENCE INSTALLATION GUIDE (4/25)
- Page 2 VERTICAL FULL SIZE FENCE COMPONENTS DESCRIPTION NC PART Product Composite Modern Horizontal Semi-Privacy Full Size Fence (3.5’ x 6’) 100301XX60600 U POST - POST, 2.5" X 2.5" X 94.5" COMPOSITE U-CHANNEL MODERN 300722XX094 ROUTING COMPOSITE U CHANNEL MODERN ROUTING RV POST 2.5X2.5X64 300722RV064 T&G Board 1x6-63.25"-FULL-PANEL...
-
Page 3: Before You Begin
BEFORE YOU BEGIN TOOLS REQUIRED Tools for Preparing the Fence and Post Burial Before You Begin: Tape Measure 1. Verify Underground Utilities • Use aids such as local building departments, Post Hole Digger & Shovel • utility companies, or utility location services to Post Bubble Level (for ensuring posts are •... -
Page 4: Post Assembly
2.1 Install “L “Support Angle Post Assembly 1. Each panel of requires two (2) U-Channel Posts with assembly installed (Board stop and base cable assembly), one post at each end. 2. The U-Channel Posts for each adjacent panel must be fastened together bore the fence is assembled. -
Page 5: Post Install
Post Install 1. Dig 12” diameter holes 24” deep in all post hole locations marked in previous steps. 2. Verify proper hole depth by placing the U-Channel post assembly in the hole and lining up the depth stick with the ground to achieve the desired height, 2” or 3.5” above ground level. 3. - Page 6 Fence Board 1. After concrete has set it is time to move into fence board installation 2. The Hollow Tongue and Groove Boards come pre-cut to the proper post spacing. 3. Install fence boards about halfway up by repeating the above step, pressing each groove onto the other previous board’s tongue.
- Page 7 2. Insert the 64” U-channel post between the existing posts. This post is secured at both ends using Chicago screws 3. Insert the T&G BOARDS...
- Page 8 Top Cap Install 4. Insert Top Cable 5. Attach the two spacers to the ends of the upper U-channel using the male zinc- plated steel Phillips flat head screws." 6. Place the upper U-Channel in the top of the boards. For any further information or questions please visit www.naturescomposites.com or call us at (877) 810-4029 ...
-
Page 9: Top Cap Installation
Top Cap Installation 1. Install the Top Cap Slide the Top Cap into the routed space at the top of the U-channel posts. 2. Secure the Top Cap Fasten the Top Cap using the provided 1-3/4 inch composite screws with a Torx T20 Bit and power tool. For any further information or questions please visit www.naturescomposites.com or call us at (877) 810-4029 ...
