- Page 1 TWO BOARD RANCH RAIL GATE INSTALLATION GUIDE...
- Page 2 TWO BOARD RANCH RAIL GATE COMPONENTS ITEM DESCRIPTION NC PART Complete Two-Board Ranch Rail Gate 100324XX30400 Product Horizontal U-shape posts (40 1/2 inches) 300722XX0405 Vertical U-shape posts (26 5/16inches) 300722XX035 Square edge 1x6 boards (43 inches) 300341XX043 NC Top Caps...
-
Page 3: Before You Begin
BEFORE YOU BEGIN TOOLS REQUIRED • Before You Begin: Tools for Installing the Fence 1. Verify Underground Utilities Rubber mallet (not included, for securing • Use aids such as local building departments, angle brackets) utility companies, or utility location services to #4 Phillips screwdriver ... - Page 4 2.1 Install “L “Support Angle STEP 2: Install the Vertical U-Posts to the Bottom Horizontal U-Post 1. Position the Vertical U-Posts: Attach the two 35-inch vertical U- posts to the bottom horizontal U- post to create the gate frame. 2. Align and Slide the Angle Brackets: Slide the angle brackets into the U-channels of the vertical ...
- Page 5 2. Position the NC Spacers Place a 10 11/16-inch spacer inside each U-shaped post after sliding in the first board. 3. Secure the Spacers with Velcro Dots Attach four Velcro dots to each spacer, positioning them to ensure they touch the inside of the U-channel post.
- Page 6 STEP 4: Close the Gate by Installing the Top Horizontal U-Post 1. Attach Angle Brackets to the Top U-Post Attach two angle brackets to the top U-post. Install the joint connectors (Chicago screws) but do not fully tighten them. 2. Slide the Top U-Post into Place Carefully slide the top U-post into the frame, ensuring it fits above the last NC board.
- Page 7 STEP 6: Install the Post Cap s on All 4 Post Ends 1. Slide the Top Caps into Place The gate comes with four NC top caps. Slide a top cap onto each of the four post ends, aligning the groove of the cap with the post.
- Page 8 1. For Commercial or Heavy Usage Applications: NC Part number 300755XX094 (includes post cap) NC 5x5 Composite Commercial Grade Post (94 in. H x 5 in. W) For commercial settings or residential applications with heavy use, NC recommends the 5x5 Composite Commercial Grade Post. This post is specifically designed to handle the gate's weight and withstand the demands of high-traffic environments, providing a secure and stable installation.
- Page 9 In summary, for a post buried 24 inches, digging the hole 26-30 inches deep provides a secure foundation and ensures long-term durability. 24” Gate Alignment and Support 1. Recheck Alignment Ensure the posts are straight and level. 2. Test Post Stability Apply pressure to check that the posts are stable to prevent gate sagging. Prepare the Gate and Hardware.
