LOADER
MX
Fitting instructions
Please read these fitting instructions carefully before assembing the
MX loader
EN 374393 AA - 0723
Translation of the original manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T400 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MX T400 Series

  • Page 1 LOADER Fitting instructions Please read these fitting instructions carefully before assembing the MX loader EN 374393 AA - 0723 Translation of the original manual...
  • Page 3: Table Of Contents

    2. HANDLING 2.1 MX loaders packaged on a pallet 2.2 Handling the MX loader 3. LOADER PREPARATION 3.1 T400 series, U500 series, A100 series loaders 4. SAFETY STICKERS 5. LOADER HITCHING 5.1 Pre-hitching checks 5.2 T400 series, U500 series, A100 series loaders 5.3 TX400, F300 series and COMPACT loaders...
  • Page 5: Safety Rules

    — Breaking lead seals will void any liability on the part of MX for all its equipment. — Any assembly of the MX loader not in accordance with the recommendations of the MX price list in force at the purchase date voids the MX guarantee for the entire unit supplied.
  • Page 6: Handling

    2. Handling MX loaders packaged on a pallet T400 series, A100 series Ensure all parts of the loader are firmly bound together to remove it from the pallet (See loader unpacking instructions). TX400 series, T400 series, A100 series Subject to modification...
  • Page 7 U500 series Ensure all parts of the loader are firmly bound together to remove it from the pallet (See loader unpacking instructions). U500 series Subject to modification...
  • Page 8: Handling The Mx Loader

    Handling the MX loader Use anchorage points (except U500 series). Handling U500 series loaders Subject to modification...
  • Page 9: Loader Preparation

    3. Loader preparation T400 series, U500 series, A100 series loaders 3.1.1 Standard release handle kit (T400 and U500 series) — Mount left and right release handles. IMPORTANT: Check that the safety latches are in the hitching position (locking indicators in the red zone).
  • Page 10 3.1.4 Bracket preparation — Remove paint as shown opposite. 3.1.5 Mounting the roller kit (depending on the bracket model) — T400 and U500 series loaders Mount the rollers on the interior faces of the bracket arms (except special cases as detailed in the bracket mounting instructions).
  • Page 11: Safety Stickers

    4. Safety stickers Safety stickers are affixed to loaders. Ensure that these stickers are clean and legible; replace them if they become damaged. If replacing a sticker, clean the surface used for the sticker with isopropyl alcohol and affix the sticker using a special tool. Symbol Meaning Familiarise yourself with the safety instructions in the user manual before using or working on the loader. Follow the loader hitching and unhitching procedure given in the user manual. Use the anchoring points when handling the loader. Handling above people is prohibited.
  • Page 12 4.1.2 T400 series loaders 4.1.3 A100 series loaders 4.1.4 F300 series loaders Subject to modification...
  • Page 13 4.1.5 COMPACT loaders Subject to modification...
  • Page 14 4.1.6 U500 series loaders Safety stickers are affixed to the loaders. Ensure that these stickers are clean and legible; replace them if they become damaged. If replacing a sticker, clean the surface used for the sticker with isopropyl alcohol and affix the sticker using a special tool. DANGER: Failure to follow these rules may result in serious injury or death. Symbol Meaning Read the safety rules and operating instructions in the user manual before using the product. Maintain a minimum safety distance from the high-voltage cables. Subject to modification...
  • Page 15 Symbol Meaning Drive with the loader in the low position. Climbing on the implement is prohibited. Standing beneath the load is prohibited. Use an implement suitable for the work to be carried out and use it in accordance with the manufacturer’s recommendations.
  • Page 16: Loader Hitching

    If there is insufficient clearance, adjust the front mudguards accordingly. (See instructions for mounting the bracket). T400 series, U500 series, A100 series loaders 5.2.1 Check on left/right frames Check that the locking indicators on the left and right frames are in the red zone, and that there is nothing that may hamper the loader connection.
  • Page 17 5.2.4 Locking and hitching the loader — T400 series, U500 series loaders: Check that the pins are engaged in the bracket heads. The indicators are in the green zone (automatic engagement of the safety latches).
  • Page 18: Tx400, F300 Series And Compact Loaders

    Raise the front axle of the tractor and check, with maximum clearance (oscillation and maximum steering angle), that no part of the frame and the MX loader can come into contact with the tyres, mudguards and their housing, or any other part of the tractor.
  • Page 19: Putting The Loader Into Operation

    6. Putting the loader into operation Connecting the hydraulic lines. Slow pressurisation of the hydraulic unit. Fully actuate each function several times to evacuate as much air as possible from the circuits. — Lifting — Dumping — 3rd function — 4th function —...
  • Page 20: Washing

    8. Washing When using a pressure washer, do not stand too close to the loader and do not spray directly onto electrical components, linings, filler apertures, stickers, etc. 9. Tightening torque: Check the tightness of the bracket after 10 and 50 hours' work, then every 100 hours or every time the tractor's engine oil is changed (bracket released).
  • Page 24 M-extend France SAS 19, rue de Rennes B.P. 83221 FR-35690 ACIGNÉ Email : contact@m-x.eu Web : www.m-x.eu...
