Coleman REVOLUTION II G37801 Assembly Manual page 32

ASSEMBLY INSTRUCTIONS
15
B.
If not immediately visible, the electrode wires BE can be found behind the control panel.
Tip: Firmly grasp the wires between your thumb and index finger. Insert the wire into
the appropriate terminal until a positive connection is made.
BE
Small x 2
EE
BE
DN
Large x 2
EE
30
Electrode Set, Main Burner |
Small Wire
Ignition Wire | Large Wire
Ground Wire | Small Wire
DN
