BMS7702
Tools Needed for Installation
Vista
Storage Shed
™
ASSEMBLY INSTRUCTIONS
7/16"
(11.4 mm)
INCLUDED IN KIT
Easy Bolt Easy Driver
010210410
KEEP THESE INSTRUCTIONS. You will need Quality Control Number shown below to register your product.
Quality Control Number:
© 2018 Suncast Corporation, Batavia, IL
0361449D

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vista BMS7702 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Suncast Vista BMS7702

Summary of Contents for Suncast Vista BMS7702

  • Page 1 Storage Shed ™ ASSEMBLY INSTRUCTIONS 7/16” (11.4 mm) INCLUDED IN KIT Easy Bolt Easy Driver 010210410 KEEP THESE INSTRUCTIONS. You will need Quality Control Number shown below to register your product. Quality Control Number: © 2018 Suncast Corporation, Batavia, IL 0361449D...
  • Page 2 • This kit contains parts with metal edges. Please be careful when handling. Suncast Products and Replacement Parts To purchase Suncast replacement parts and learn about other Suncast products, visit us online or call. www.suncast.com 24 hours a day, 7 days a week, 365 days a year.
  • Page 3 Note: This product contains parts that are used in different orientations to construct the shed. Please take note of the orientation of the parts shown throughout this instruction manual. Failure to follow instructions could result in damage to parts. Suncast is not responsible for replacing parts lost or damaged due to incorrect assembly.
  • Page 4 Parts - BMS7702 Walls and Floors IMPORTANT OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT. COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.
  • Page 5 Parts - BMS7702 Doors IMPORTANT OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT. COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.
  • Page 6 Parts - BMS7702 Headers IMPORTANT OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT. COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.
  • Page 7 Parts - BMS7702 Roof Truss IMPORTANT OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT. COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.
  • Page 8 Parts - BMS7702 Roof IMPORTANT OPEN ALL BOXES FIRST AND NEATLY LAYOUT PARTS. SMALL PARTS MAY BE CONTAINED IN EACH BOX. PLEASE REFERENCE THE PARTS LIST WITHIN THIS MANUAL TO VERIFY ALL PARTS ARE PRESENT. COMPLETE SITE PREPARATION AND FOUNDATION CONSTRUCTION BEFORE UNPACKING ALL PARTS.
  • Page 9 Hardware - BMS7702 0480340 – Hardware bag 0480374 – Hardware bag .25 - 20 x 1" Hex bolt 0480375 – Hardware bag .25" x 2" Hex bolt .25" x 2" Hex bolt 0MP000002 – Metal hinge plate .625" Screw .25" Locking nut .25"...
  • Page 10 Door Handle Kit - Parts - BMS7702 0463795 – Door handle kit 0463797 – Door latch kit 0102479 Door handle 0463812 – Door Latch Assembly 0MP000020 – Left latch plate Hardware 0480370 – Hardware bag 0480439 – Hardware bag .25" Washer #10 x 1"...
  • Page 11 Note: Site preparation is required for this shed. Placing the shed on a constructed foundation is required. Without a constructed foundation, settling will probably occur, causing distortion and damage to the shed. Suncast is not responsible for replacing parts damaged or property lost due to incorrect assembly. Warranty requires foundation.
  • Page 12 Site Preparation and Platform Construction (continued) Materials NOT supplied with BM7702 Shed Kit Wood platform critical spacing 15.500 13.250 7.25 30.000 85.250 11.375 30.000 6.63 84.750 • Check all critical spacing measurements. Wood platform materials list Item Size 37.25" x 84.75" x .75" 48"...
  • Page 13 Door Pre-Assembly Peel film from both sides of left door window (N). Place gasket (P) and left door window (N) into left door (J) channel. Secure with thirteen screws (NN), starting at Separate the two window gaskets (P) and peel off corners.
  • Page 14 Header Pre-Assembly Place vent screen (V) in front header (G). Secure through Slide roof ridge beam bracket (U) under tabs on back of header with 11 screws (QQ). inside peak of front header (G) and secure with two DO NOT over tighten screws. screws (NN).
  • Page 15 Roof and Truss Pre-Assembly Attach truss bracket (Z) to end of one truss leg (Y) with 1" hex bolt (KK) and locking nut (LL). Repeat for second truss leg (Y). x2 x2 x2 x2 Attach two truss cross beams (CC) to two truss legs Place side adaptor bracket (BB) at end of left truss leg (Y) using two hex bolts (JJ) and two locking nuts (LL).
  • Page 16 Skylight and Wall Pre-Assembly x8 x8 x4 x4 Place Illumivent™ cover (GG) onto bottom (HH). Secure Place Illumivent™ assembly (GG, HH, FF) onto right from underside with four screws (NN). Place gasket (FF) roof panel (M). Secure from underside with eight screws into Illumivent™...
  • Page 17 Shed Assembly/Walls Push front floor (A) and rear floor (T) panels together and Align tab on bottom right side of left front corner (B) with secure with six screws (NN). slot on front floor (A). Lower panel into slot and lock in place by sliding panel toward outside of floor.
  • Page 18 Shed Assembly/Walls Shed Assembly/Walls (continued) (continued) Tip left front corner (B) outward slightly and bend corner Tip left front corner (B) back to vertical position and hinge. align lower tabs on right side with slots in floor. Note: You will hear a snap when tab is fully engaged. Before proceeding, make sure corner is square (top view) where it meets the floor and that panel is flush...
  • Page 19 Shed Assembly/Walls (continued) Align tabs on bottom of side panel (N) with slots along front and rear floors. Lower panel into slots and lock in place by sliding panel toward front corner. Note: Use a rubber mallet to “push” side panel (N) into locked position.
  • Page 20 Shed Assembly/Walls (continued) Hardware Needed Repeat Steps 16-21 for remaining panels.
  • Page 21 Shed Assembly/Headers and Truss Place front header (G) over door opening and fit two protruding support legs into pockets molded in front corners. Secure front header using two screws (NN) in each front corner. x8 x8 Slide truss assembly into place. Secure with four Place rear header (H) over back walls and fit four screws (NN) in each side adaptor bracket.
  • Page 22 Shed Assembly/Headers and Truss (continued) x2 x2 Raise ridge beam (S) up and into rear roof ridge beam Attach truss strap (DD) to side adaptor bracket (BB) and bracket. Secure with one 2" hex bolt (JJ) and one truss leg (Y) with two screws (NN). locking nut (LL).
  • Page 23 Shed Assembly/Roof Place the front roof peak (Q) onto a right roof panel (M). Before proceeding, locate and identify the six slots on Secure with five rubber washers (UU) and five sealing interior side of left roof panels (L). screws (TT). Repeat for rear roof peak (W) and remaining right roof panel (M).
  • Page 24 Shed Assembly/Roof (continued) x3 x3 Before proceeding, locate and identify six front header Lay left roof (L) directly over three tabs on left side of tabs and six rear header tabs. front header (G). With left roof slots seated over/on header tabs, check alignment in all three spots.
  • Page 25 Shed Assembly/Roof (continued) End view x3 x3 Repeat steps 30-32 for remaining left roof panel (L). Lay right roof (M) with front roof peak (Q) directly over three tabs on right side of front header (G). With right roof slots seated over/on header tabs, check alignment in all three spots.
  • Page 26 Shed Assembly/Roof (continued) End view x6 x10 Push down the right roof panels with roof peaks from Repeat steps 34-36 for remaining right roof panel (M) outside. From inside shed, secure roof peaks to left roof and rear roof peak (W). panels together using 10 rubber sealing washers (UU) and 10 sealing screws (TT).
  • Page 27 Shed Assembly/Roof (continued) Raise roof support (AA) into position against roof. Slide Secure roof support (AA) to roof using three screws (NN). roof support (AA) into front header. Secure roof support to Raise second roof support (AA) to top of roof panel. (Shown in next step) underside of truss leg with one screw (NN).
  • Page 28 Shed Assembly/Doors Stand right door (K) upright with three hinge mounts facing right. Slide one metal hinge plate (II) up onto each hinge mount. Rotate hinges to outside of door. Secure each metal hinge plate with one screw (OO) and With metal hinge plates in open position, slide one hinge one locking nut (PP).
  • Page 29 Shed Assembly/Doors (continued) Insert two screws (CCC) into right latch plate (XX) and Insert screws (CCC) into left latch plate (WW) and through through right door. While holding plate in place on exterior left door. While holding plate in place on exterior of door, of door, secure each screw with two washers (AAA) and secure each screw with two washers (AAA) and two two locking nuts (BBB).
  • Page 30 Shed Assembly/Doors (continued) 5/16" (12.7 cm) Max. 3/4" (7.6 cm) 5/16" 1 1/2" Max. (12.7 cm) Attach a 5/16" lock (not provided) to door latch to Push lower D-ring (O) down to engage with hole in floor. properly secure shed. Turn D-ring to right for locked position.

  • Page 31: Warranty

    2345 or visit www.Suncast.com. SUNCAST® will repair or replace only the parts that failed under the terms of the warranty. In some cases, the replacement parts may not be identical, but they shall be of equal or greater performance than the original part.
