ELECTRONIC LEAK DETECTOR
ALWAYS CONNECT CABLES PRIOR TO POWERING ON THE INSTRUMENT
1. LEAK DETECTOR FUNCTION
The Tinker & Rasor Model ELD Leak Detector is an all-purpose electrical inspection
instrument that maintains a given inspection voltage despite the electrical load on the
circuit. It is recommended for use on non-conductive waterproof membranes as well as
on flat surfaces when such surfaces are coated with a highly electrical resistance
material, and when the surface beneath the coating is electrically conductive. The Model
ELD works equally well on damp or dry surfaces and is especially desirable where humid
conditions prevail.
The purpose of this instrument manual is to inform the user on the operation of this
instrument and is not meant as an instruction guide to leak detection in general. It is
recommended that only knowledgeable and trained operators use this equipment. We
suggest ASTM International (www.ASTM.org) for this type of training.
2. INSTRUCTIONS FOR UNPACKING & INSPECTION
1) Open the shipping carton and make note of the various accessories.
Includes:
NOTE: Additional accessories may ship in separate packaging.
2) INSPECTION should be made upon receipt. If damage has occurred during
shipment, file a claim with the carrier immediately.
3) If it is necessary to contact your supplier or the manufacturer concerning
damaged or missing items, be sure to include the serial number, purchase
order number, and invoice number of the instrument in question.
Web: www.tinker-rasor.com
CORROSION MITIGATION INSTRUMENTATION
2828 FM 758, NEW BRAUNFELS, TX 78130 TEL: (830) 253-5621
P
RODUCT
MODEL ELD
(1) Rechargable Instrument w/ Extra Battery
(1) Powerpak w/ Cable
(1) Battery Charger w/ Charging Adapter
(1) Screwdriver
(1) Ground Cable w/clamp (150')
(1) Wand Handle (18")
(2) Extension Wands (18")
(1) Equipment Belt (54")
(1) 24" Wire Brush
(1) 4" Wire Brush
(1) 8" Fan Brush
(1) Backpack Carrying Case w/ Foam Insert
(1) Certificate of Calibration
I
NSTRUCTIONS
E-mail: Info@tinker-rasor.com
– 1 –
