IN-PLANT USE HOLIDAY DETECTOR
1.
HOLIDAY DETECTOR FUNCTION
The Tinker & Rasor Model AP/AC In-Plant Holiday Detector is an all-purpose electrical
inspection instrument which maintains a given inspection voltage in spite of the
electrical load on the circuit. It is recommended for use on any pipe diameter as well
as on flat surfaces when such surfaces are coated with a highly electrical resistance
material, and when the surface beneath the coating is electrically conductive. The
detector works equally well on damp or dry surfaces, and is especially desirable where
humid conditions prevail. The instrument can be delivered for operation on either 110v
or 220v AC power.
2.
INSTRUCTIONS FOR UNPACKING & INSPECTION
A.
Open the shipping carton and make note of the various accessories.
B.
INSPECTION should be made upon receipt. If damage has occurred during
shipment, file a claim with the carrier immediately.
C.
If it is necessary to contact your supplier or the manufacturer concerning
damaged or missing items, be sure to include the serial number, purchase order
number, and invoice number of the instrument in question.
3.
CHECK-OUT INSTRUCTIONS
Remove all accessories from the shipping carton.
•
Make sure that the detector is turned OFF.
•
Connect high voltage cable and ground cable to detector (insert and twist
•
clockwise). Never connect or disconnect the cables when the instrument is
turned on.
•
Attach probe handle to voltage cable.
•
Attach electrode to the voltage probe assembly and apply to the structure to be
inspected. The electrode should always make intimate contact with the surface
under inspection.
Plug AC power cord into 110v power supply (220v on specially configured
•
instruments). See label on outside of case for type.
