P. O. B
6890 S
OX
AN
HIGH VOLTAGE HOLIDAY DETECTOR
1. HOLIDAY DETECTOR FUNCTION
The Tinker & Rasor Model APS Holiday Detector is an all-purpose electrical inspection
instrument which maintains a given inspection voltage in spite of the electrical load on
the circuit. It is recommended for use on any pipe diameter as well as on flat surfaces
when such surfaces are coated with a highly electrical resistance material, and when
the surface beneath the coating is electrically conductive. The detector works equally
well on damp or dry surfaces, and is especially desirable where humid conditions
prevail.
2. INSTRUCTIONS FOR UNPACKING & INSPECTION
1) Open the shipping carton and make note of the various accessories.
Includes:
NOTE: Additional accessories may ship in separate packaging.
2) INSPECTION should be made upon receipt. If damage has occurred during
shipment, file a claim with the carrier immediately.
3) If it is necessary to contact your supplier or the manufacturer concerning
damaged or missing items, be sure to include the serial number, purchase
order number, and invoice number of the instrument in question.
* Instrument ships with electrode of choice. Electrode may be Full Circle Spring Electrode (up to 16" pipe diameter),
Half Circle Spring Electrode (up to 8" pipe diameter) or Silicone Rubber Electrode (up to 8" pipe diameter).
Wire Brush Electrodes, larger size electrodes and additional electrodes available at additional cost.
3. CHECK-OUT INSTRUCTIONS
•
Remove all accessories from the shipping carton.
Web: www.tinker-rasor.com
CORROSION MITIGATION INSTRUMENTATION
B
, C
92412
ERNARDINO
A
P
RODUCT
MODEL APS
(STICK UNIT)
(1) Instrument
(2) Battery
(1) Battery Case
(1) Battery Charger (110v or 220v)
(1) Screwdriver
(1) Ground Cable (20')
(1) Wand Handle (18")
(1) Compax Connector (for use with Full Circle Spring Electrodes)
(1) Paddle, silicone-rubber, 4"
(1) Carrying case
(1) Electrode of Choice*
T
: (909) 890-0700
EL
I
NSTRUCTIONS
E-mail: Info@tinker-rasor.com
– 1 –
F
: (909) 890-0736
AX
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tinker & Rasor APS
Summary of Contents for Tinker & Rasor APS
- Page 1 (STICK UNIT) 1. HOLIDAY DETECTOR FUNCTION The Tinker & Rasor Model APS Holiday Detector is an all-purpose electrical inspection instrument which maintains a given inspection voltage in spite of the electrical load on the circuit. It is recommended for use on any pipe diameter as well as on flat surfaces when such surfaces are coated with a highly electrical resistance material, and when the surface beneath the coating is electrically conductive.
- Page 2 The electrode should always make intimate contact with the surface under inspection. • The Model APS Holiday Detector is now ready to turn on. • Turn the instrument ON by holding the safety switch handle firmly against the instrument handle.
- Page 3 The Model APS comes with two (2) batteries. The battery should be charged after each use. The Model APS will indicate when the battery voltage is low, by a flashing or flickering of the Green Power LED, instead of providing a steady glow.
- Page 4 RODUCT NSTRUCTIONS The battery charger included with the Model APS Holiday Detector operates on a 110v AC power source. 220v AC power source battery charges are available at additional charge. Check the packing list or invoice of your order to verify which battery charger was included with your Model APS.
