Zoom H5studio Quicktour page 7

After settings are complete, the Home Screen will open.
■ Home Screen
Status icon
Turn
Menu Bar (FILE LIST / INPUT / OUTPUT / REC / DISPLAY / SD CARD / USB / SYSTEM)
Press and hold
guide sound.
(Elapsed/remaining recording times)
to show the Menu Bar at the top of the screen.
when the Home Screen is open to immediately turn on/off the
Counter
7
Remaining battery indicator
Waveform display
• XY mic
• INPUT 1
• INPUT 2
Level meters
• XY mic
• INPUT 1
• INPUT 2
• Stereo mix
