Product manual
ABB-Welcome IP
H8236-. IP touch 7
H8237-. IP touch 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP touch 7 H8236 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ABB IP touch 7 H8236 Series

  • Page 1 2TMD042400D0014 │ 08.10.2024 Product manual ABB-Welcome IP H8236-. IP touch 7 H8237-. IP touch 10...
  • Page 2: Table Of Contents

    Used symbols ..........................7 Target group / Qualifications of personnel ................... 8 Safety instructions ........................9 Intended use ............................10 Environment ............................12 ABB devices ..........................12 Product description ..........................13 Device type ..........................13 Control elements........................14 Terminal description ......................... 15 Technical data ............................
  • Page 3 Table of contents 8.3.4 Network settings ........................78 8.3.5 MyBuildings settings ......................84 8.3.6 Paring the panel with APP..................... 86 8.3.7 Time and date settings ......................89 8.3.8 Changing advanced setting password..................90 8.3.9 Resetting advanced setting password ..................92 8.3.10 Configuring unlock password ....................
  • Page 4 Table of contents Call Guard Unit ........................193 Surveillance ........................... 194 9.5.1 Accessing video surveillance ....................194 9.5.2 Surveillance from outdoor stations ..................195 9.5.3 Surveillance from IP camera ....................196 Releasing the lock ......................... 197 Turn on a light........................198 Call the elevator ........................199 Configuring the voice ......................
  • Page 5 Table of contents 11.7 Password rule ........................266 Notice .............................. 267 Product manual 2TMD042400D0014 │5...
  • Page 6: Notes On The Instruction Manual

    Please keep this manual in a safe place. If you pass the device on, also pass on this manual along with it. ABB accepts no liability for any failure to observe the instructions in this manual. Product manual 2TMD042400D0014...
  • Page 7: Safety

    Safety Safety Warning Electric voltage! Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. – Disconnect the mains power supply prior to installation and/or disassembly! –...
  • Page 8: Target Group / Qualifications Of Personnel

    Safety Target group / Qualifications of personnel Installation, commissioning and maintenance of the device must only be carried out by trained and properly qualified electrical installers. The electrical installers must have read and understood the manual and follow the instructions provided.
  • Page 9: Safety Instructions

    Safety Safety instructions Warning Electric voltage! Risk of death and fire due to electrical voltage of 230 V. Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death.
  • Page 10: Intended Use

    Intended use Intended use This device is a central control panel of the ABB-Welcome IP system and operates exclusively with components from this system. The device must only be installed in dry indoor rooms. WiFi installation Note If the device supports WiFi function, please make sure the device has good WiFi signal reception before installation.
  • Page 11 Do not remove SD card or reboot indoor station while recording or copying ■ images onto the SD card, otherwise this SD card may fail to preform when recording or playing images. ABB is no responsible for the performance of an SDHC card. ■ IP-Camera Note The indoor station supports IP-Camera with onvif protocol (Profile S).
  • Page 12: Environment

    ABB devices All packaging materials and devices from ABB bear the markings and test seals for proper disposal. Always dispose of the packing materials and electric devices and their components via an authorized collection facility or disposal company.
  • Page 13: Product Description

    Product description Product description Device type Size (DxHxW) Article Order number Product name Colour number Unit: mm H8236-4B 2TMA130050B0065 IP touch Black 199 x 150 x 17 7",DES+KNX+f@h+APP,L AN+WiFi,T-loop H8236-4W 2TMA130050W0065 IP touch White 199 x 150 x 17 7",DES+KNX+f@h+APP,L AN+WiFi,T-loop H8236-5B 2TMA130050B0067...
  • Page 14: Control Elements

    Product description Control elements IP touch 7 Function Touch screen IP touch 10 Function Touch screen Product manual 2TMD042400D0014 │14...
  • Page 15: Terminal Description

    Product description Terminal description IP touch 7 Function Power input connector Power input connector (DC-JACK input) Doorbell connector LAN1 (PoE) Micro USB Upgrade connector Extension module connector Microphone Dismantling switch Micro SD card connector Speaker LAN2 Alarm connector RS485 connector, 12 V output, emergency port (SOS, GAS, fire) Relay output IP touch 7 (LAN+LAN) Product manual 2TMD042400D0014...
  • Page 16 Product description IP touch 10 Function Power input connector Power input connector (DC-JACK input) Doorbell connector LAN1 (PoE) Micro USB Upgrade connector Interface module connector Microphone Dismantling switch Micro SD card connector Speaker LAN2 Alarm connector RS485 connector, 12 V output (12 V output is not available when PoE powered) Relay output IP touch 10 (LAN+LAN) Product manual 2TMD042400D0014...
  • Page 17: Technical Data

    Technical data Technical data IP touch 7 ⎓ Designation Value ⎓ Rating voltage 24 V ⎓ Operating voltage range 20-27 V ⎓ 27 V , 250 mA ⎓ Rating current 24 V , 280 mA ⎓ 27 V , 390 mA Rating current 24 V , 440 mA...
  • Page 18 Technical data IP touch 10 ⎓ Designation Value ⎓ Rating voltage 24 V ⎓ Operating voltage range 20-27 V ⎓ 27 V , 390 mA ⎓ Rating current 24 V , 440 mA ⎓ 27 V , 520 mA Rating current 24 V , 600 mA Display size...
  • Page 19: Mounting/Installation

    Mounting/Installation Mounting/Installation Warning Electric voltage! Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. – Disconnect the mains power supply prior to installation and/or disassembly! –...
  • Page 20: Product Dimensions

    Mounting/Installation Product dimensions Uint: mm 250.8 198.5 149.8 IP touch 7 IP touch 10 Installation height 1.50 m (4.9 feet) Product manual 2TMD042400D0014 │20...
  • Page 21: Surface-Mounted Installation

    Mounting/Installation Surface-mounted installation IP touch 7 This installation method is not suitable for IP touch 7 (LAN+LAN). (unit: mm) 170.8 131.4 120.7 120.7 NEMA Global VDE&BS&CN 83.3 83.3 79.2 NEMA NEMA&Italy Swiss 198 5 . 149 8 . SM box Product manual 2TMD042400D0014 │21...
  • Page 22 Mounting/Installation IP touch 10 This installation method is not suitable for IP touch 10 (LAN+LAN). IP Touch 10 can be used with the surface-mounted box of IP Touch 10. (unit: mm) 120.7 120.7 Global VDE&BS&CN NEMA 83.3 83.3 79.2 NEMA&Italy Swiss NEMA 250 8 .
  • Page 23 Mounting/Installation IP Touch 10 can also be used with the surface-mounted box of IP Touch 7. 170.8 131.4 120.7 120.7 Global VDE&BS&CN NEMA 83.3 83.3 79.2 NEMA&Italy Swiss NEMA SM box of IP Touch 7 Product manual 2TMD042400D0014 │23...
  • Page 24: Flush-Mounted Installation

    Mounting/Installation Flush-mounted installation With pre-installation box (unit: mm) 250 8 . 192 mm 144 mm 54 mm 29.4 Hole size of the pre-installation box Product manual 2TMD042400D0014 │24...
  • Page 25: Cavity Wall Installation

    Mounting/Installation Cavity wall installation (unit: mm) 250 8 . 186.5 186.5 Ø9x4 32.1 Hole size of flush-mounted box Product manual 2TMD042400D0014 │25...
  • Page 26: Desktop Installation

    Mounting/Installation Desktop installation This installation method is not suitable for IP touch (LAN+LAN). Product manual 2TMD042400D0014 │26...
  • Page 27: Dismantling

    Mounting/Installation Dismantling Replacing the end strip 4 screws need to be removed. Product manual 2TMD042400D0014 │27...
  • Page 28: Commissioning

    Commissioning Commissioning Operating modes 8.1.1 Door Entry System only This mode applies to the Door Entry System alone. On the "System Configuration" screen during the "Wizard Setup", Enable the "Door Entry Welcome IP" check box. ■ Disable the "Home Automation" check box. ■...
  • Page 29: Knx Only Mode

    Commissioning 8.1.2 KNX only mode This mode applies to the KNX system alone. On the "System Configuration" screen during the "Wizard Setup", Disable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "KNX" single choice. ■...
  • Page 30: Free@Home Only Mode

    Commissioning 8.1.3 free@home only mode This mode applies to the free@home system alone. On the "System Configuration" screen during the "Wizard Setup", Disable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "free@home" single choice. ■...
  • Page 31: Door Entry System With Knx

    Commissioning 8.1.4 Door Entry System with KNX This mode applies to the Door Entry System & the free@home system. On the "System Configuration" screen during the "Wizard Setup", Enable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■...
  • Page 32: Door Entry System With Free@Home

    Commissioning 8.1.5 Door Entry System with free@home This mode applies to the Door Entry System & the free@home system. On the "System Configuration" screen during the "Wizard Setup", Enable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■...
  • Page 33: Setup Wizard - Door Entry System Only

    Commissioning Setup wizard - Door Entry System only 8.2.1 Configuration without SmartAP Please follow the steps below: [1] On the "Setup wizard" screen, select the language from the drop-down list. [2] Select the region from the drop-down list. [3] Tick the check box to accept the licences. Or tap "Click to read" to view the details of the licence.
  • Page 34 Commissioning [5] On the "Configuration Mode" screen, select the system mode. For more details, see chapter 8.1 “Operating modes“ on page 28. ■ [6] Tap "Continue". Product manual 2TMD042400D0014 │34...
  • Page 35 Commissioning [7] On the "Configuration Mode" screen, select "Panel set-up for single family house", tap " " to see the system topology, system recommended capacity, and you can download the product manual by scanning the QR code on the right. [8] Tap "Continue".
  • Page 36 Commissioning [9] On the "Panel Addressing" screen, select "Master mode". Only one Indoor Station can be set to "Master mode" in the same apartment. [10] Enter the block number, the floor number and the apartment number. The "Panel number" is preset as "01"...
  • Page 37 [12] On the "IP Addressing" screen, tap "Edit" to access the corresponding screen. Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the address type, it can set to "DHCP", "Customizable address" or "ABB Legacy". If ■ "ABB Legacy" is selected, IP address will be "10.0.x.x".
  • Page 38 Commissioning [14] On the "Trusted Devices" screen, check the system recommended capacity again. [15] Tap "Continue". [16] Check the system topology. [17] Tap "Continue" to start searching the devices in the single-family house. On the "Trusted Devices" screen, you can also tap "Do it later" to skip this setting if your ■...
  • Page 39 Commissioning [18] All the related devices are displayed on the list. [19] Tap "Continue". [20] Tap "Continue". Product manual 2TMD042400D0014 │39...
  • Page 40 Commissioning [21] Tap "Trust all". [22] All the related devices will be displayed on the screen. [23] Tap "Continue". Product manual 2TMD042400D0014 │40...
  • Page 41 Commissioning [24] On the "Time & date" screen, you can carry out this setting at this time or tap "Continue" to skip this setting for the moment. For more details, see chapter 8.3.7 “Time and date settings“ on page 89. ■...
  • Page 42 Commissioning [26] There are 5 screens to guide you how to use the panel. [27] Tap "Skip" if you are already familiar with the panel. Note After configuring the Master IS, the 2nd OS and the IPA will both complete their configuration.
  • Page 43: Configuration Via Smartap

    Commissioning 8.2.2 Configuration via SmartAP Please follow the steps below: [1] On the "Setup wizard" screen, select the language from the drop-down list. [2] Select the region from the drop-down list. [3] Tick the check box to accept the licences. Or tap "Click to read" to view the details of the licence.
  • Page 44 Commissioning [5] On the "Configuration Mode" screen, select the system mode. For more details, see chapter 8.1 “Operating modes“ on page 28. ■ [6] Tap "Continue". Product manual 2TMD042400D0014 │44...
  • Page 45 Commissioning [7] Select "Via Smart Access Point", tap " " to see more details. [8] Tap "Continue". [9] On the "Panel Addressing" screen, select the mode for the panel. It can be set to "Master mode" or "Subsidiary mode". Only one panel can be set to "Master mode" in the same apartment.
  • Page 46 Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the address type, it can set to "DHCP", "Customizable address" or "ABB Legacy". If ■ "ABB Legacy" is selected, IP address will be "10.0.x.x".
  • Page 47 Commissioning [15] On the "Time & date" screen, you can carry out this setting at this time or tap "Continue" to skip this setting for the moment. For more details, see chapter 8.3.7 “Time and date settings“ on page 89. ■...
  • Page 48: Configuration Via Smartap & App

    Commissioning 8.2.3 Configuration via SmartAP & APP Please follow the steps below: [1] On the "Setup wizard" screen, select the language from the drop-down list. [2] Select the region from the drop-down list. [3] Tick the check box to accept the licences. Or tap "Click to read" to view the details of the licence.
  • Page 49 Commissioning [5] On the "Configuration Mode" screen, select the system mode. For more details, see chapter 8.1 “Operating modes“ on page 28. ■ [6] Tap "Continue". Product manual 2TMD042400D0014 │49...
  • Page 50 Commissioning [7] Select "Via Smart Access Point with Welcome APP’s scanning", tap " " to see more details. [8] Tap "Continue". [9] On the "Panel Addressing" screen, select the mode for the panel. It can be set to "Master mode" or "Subsidiary mode". Only one panel can be set to "Master mode" in the same apartment.
  • Page 51 Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the address type, it can set to "DHCP", "Customizable address" or "ABB Legacy". If ■ "ABB Legacy" is selected, IP address will be "10.0.x.x".
  • Page 52 Commissioning [14] On the "Configuration via Welcome APP’s Scanning Process" screen, tap "APP download" if you have not yet downloaded the APP. [15] Scan the designated QR code by using your mobile to download the APP, then tap "Continue". Product manual 2TMD042400D0014 │52...
  • Page 53 Commissioning [16] Create a building structure on the APP. For more details, see chapter 8.2.4 “Creating a building structure on APP“ on page 55. ■ [17] Use the APP to scan the QR code on the designated panels. For more details, see chapter 8.2.5 “Scanning the QR code on the panel“ on page 59. ■...
  • Page 54 Commissioning [19] On the "Time & date" screen, you can carry out this setting at this time or tap "Continue" to skip this setting for the moment. For more details, see chapter 8.3.7 “Time and date settings“ on page 89. ■...
  • Page 55: Creating A Building Structure On App

    Commissioning 8.2.4 Creating a building structure on APP Please follow the steps below: [1] On the home screen of the APP, tap “ ”. [2] Tap “Configuration mode”. [3] Tap “OK” to access configuration mode. [4] On the “Projects” screen, tap “ ”.
  • Page 56 Commissioning [9] On the designated project screen, tap “ ”. [10] On the “Add building” screen, enter the building name. [11] Enter the building number. [12] Tap “Add” to create a new building. Repeat step 9~12 to create multiple buildings. [13] Tap the designated building.
  • Page 57 Commissioning [18] On the designated floor screen, tap “ ” to add a room. [19] Enter the alias name for the designated room. [20] Tap “Add” to create a new room. [21] On the designated floor screen, swipe a room name to the right. [22] Tap “...
  • Page 58 Commissioning [23] Enter the duplicate number. [24] Tap “Duplicate”. [25] Enter the alias name for each room now or do it later. [26] Tap “Duplicate”. [27] On the designated floor screen, swipe the designated room name to the right. [28] Tap “ ”...
  • Page 59: Scanning The Qr Code On The Panel

    Commissioning 8.2.5 Scanning the QR code on the panel Please follow the steps below: [1] On the designated floor screen, tap the designated room. [2] On the designated room screen, tap “ ”. [3] On the “Add device” screen, scan the QR code displayed on the panel. Product manual 2TMD042400D0014 │59...
  • Page 60 Commissioning [4] On the “Device” screen, serial number of the device will be displayed. [5] Check the location. [6] Check the device type. [7] Tap “Add” to add a new device. [8] The result is displayed on the screen if success. Repeat step 1~7 to add multiple devices.
  • Page 61: Importing A Building Structure Via App

    Commissioning 8.2.6 Importing a building structure via App SmartAP can import the building created in the App. ■ You can import one building once or several buildings as a batch. ■ Preconditions The APP must be on the same network as SmartAP. ■...
  • Page 62 Commissioning Importing process Please follow the steps below: [1] On the home screen of the SmartAP, click " ". [2] A pop-up window will appear, please keep the window open and do not click " √ ". [3] On the "Projects" screen of the APP, swipe the designated project name to the right. [4] Tap "...
  • Page 63 Commissioning [9] On the configuration screen of SmartAP, the project name will be displayed on the screen. [10] Click " √ ". [11] Click "Confirm". Product manual 2TMD042400D0014 │63...
  • Page 64 Commissioning [12] The import result will be displayed. [13] Click " √ " to complete the import process. Product manual 2TMD042400D0014 │64...
  • Page 65: System Settings

    Commissioning System settings 8.3.1 Accessing the "Settings" screen On the dashboard, tap " " to access the "Settings" screen. Product manual 2TMD042400D0014 │65...
  • Page 66: Display Settings

    Commissioning 8.3.2 Display settings Accessing the "Display" screen On the "Settings" screen, tap "Display" to access the corresponding screen. Adjusting the brightness Please follow the steps below: [1] On the "Display" screen, tap "Settings". [2] Go to the "Brightness" section, drag the scroll bar to adjust the brightness. Product manual 2TMD042400D0014 │66...
  • Page 67 Commissioning Configuring the "Display mode" Please follow the steps below: [1] On the "Display" screen, tap "Settings". [2] In the "Display mode" section, select the display mode from the drop-down list. It can be set to "Dark theme" (default) or "Light theme". If the display mode is set to "Light theme", the UI will be displayed as follows: Product manual 2TMD042400D0014 │67...
  • Page 68 Commissioning Configuring the unit of temperature Please follow the steps below: [1] On the "Display" screen, tap "Settings". [2] Go to the "Temperature" section, select the unit from the drop-down list. It can be set to "Celsius" (default) or "Fahrenheit". On the status bar, the value of room temperature will be displayed in the status bar if the ■...
  • Page 69 Commissioning Configuring the unit of wind Please follow the steps below: [1] On the "Display" screen, tap "Settings". [2] Go to the "Wind" section, select the unit from the drop-down list. It can be set to "Bft" (default) , "m/s", "km/h", "mph" or "kn". On the Dashboard, the unit of wind will be displayed on the screen.
  • Page 70 Commissioning Adjusting the control element Please follow the steps below: [1] On the "Display" screen, tap "Settings". [2] Go to the "Appearance Control Element" section, tick/untick to enable/disable the function. If the function is enabled, the control will be displayed on the dashboard as follow: ■...
  • Page 71 Commissioning If the function is disabled, the control will be displayed on the dashboard as follow: ■ Product manual 2TMD042400D0014 │71...
  • Page 72 Commissioning Configuring the screensaver Please follow the steps below: [1] On the "Display" screen, tap "Screensaver". [2] Go to the "Screen saver mode" section, select the screen saver mode from the drop-down list. It can be set to "Clock" (default) "Slide show", "Images from card” or "Weather online". [3] Go to the "Start screen saver after"...
  • Page 73 Commissioning If "Clock" is selected, there will be a clock displaying the current time at a random location ■ on the screen. If "Slide show" is selected, there will be 3 built-in images playing in a loop according to the ■...
  • Page 74 Commissioning If "Image from card" is selected, there will be the images on the SD card playing in a loop ■ according to the "Slide interval" setting (default: 10 seconds). – "Slide translation effect" can be set to "Fade" or "Push from right". –...
  • Page 75: Sound Settings

    Commissioning 8.3.3 Sound settings Accessing the "Sound" screen On the "Settings" screen, tap "Sound" to access the corresponding screen. Adjusting the ringtone volume Please follow the steps below: [1] On the "Sound" screen, go to the "Ringtone volume" section, drag the scroll bar to adjust the ringtone volume.
  • Page 76 Commissioning Configuring the repeat ringtone Please follow the steps below: [1] On the "Sound" screen, tick/untick the check box to enable/disable the function. Enable (default) = rings repeated ringtone within 30 seconds ■ Disable = rings only once ■ Identifying the incoming call devices through the ringtones Please follow the steps below: [1] On the "Sound"...
  • Page 77 Commissioning Configuring the "Click sound" Please follow the steps below: [1] On the "Sound" screen, go to the "Click sound" section, tick/untick the check box to enable/disable the function. Enable (default) = plays a sound when the screen is touched. ■...
  • Page 78: Network Settings

    Commissioning 8.3.4 Network settings This chapter applies to "Private network" only. Accessing the "Network settings" screen Please follow the steps below: On the "Settings" screen, tap "Network Connections" to access the corresponding screen. Product manual 2TMD042400D0014 │78...
  • Page 79 Commissioning WiFi settings If "Private network" is set to "WiFi" during "Setup Wizard" or during "Advanced settings", you can configure WiFi settings here. Please follow the steps below: [1] On the "Network connections" screen, tap "Private Network". [2] Tick the check box to enable WiFi function. [3] Select the designated WiFi from the available list or tap "Connect manually"...
  • Page 80 Commissioning [4] Enter the WiFi password. [5] "DHCP" is enabled by default. You can untick the check box and enter the IP address manually. [6] Tap "Connect". [7] "√" will be displayed if successful. Product manual 2TMD042400D0014 │80...
  • Page 81 Commissioning [8] If you want to remove the WiFi name, swipe to the left then tap " ". Product manual 2TMD042400D0014 │81...
  • Page 82 Commissioning LAN settings If "Private network" is set to "LAN" during "Setup Wizard" or during "Advanced settings", you can configure LAN settings here. Please follow the steps below: [1] On the "Network connections" screen, tap "Private Network". [2] "DHCP" is the default value. You can disable it and enter the static address manually. Product manual 2TMD042400D0014 │82...
  • Page 83 Commissioning Cloud connections If "Private network" is disabled, then there is no private network menu here and the "Network Connections menu will be changed to "Cloud connections". Product manual 2TMD042400D0014 │83...
  • Page 84: Mybuildings Settings

    Commissioning 8.3.5 MyBuildings settings Please follow the steps below: [1] On the "Network connections" screen, tap "MyBuildings portal". [2] Tap "Log in". [3] Enter the account, the password and the alias name. [4] Tap "Log in". Product manual 2TMD042400D0014 │84...
  • Page 85 Commissioning [5] The account name will be displayed if successful. [6] Tap "Log out" to disconnect from the myBuildings portal. The weather data will be displayed on the dashboard after the panel is logged into the myBuildings portal. Note The latitude and the longitude also need to be set to obtain the correct weather data.
  • Page 86: Paring The Panel With App

    Commissioning 8.3.6 Paring the panel with APP Preconditions You have logged in to the APP with the designated myBuildings account. ■ The APP and the panel are on the same network. ■ Please follow the steps below: [1] On the "Network connections" or "Cloud connections" screen, tap "Mobile APP". [2] Tap "+".
  • Page 87 Commissioning [4] On the APP home screen, tap " ". [5] Tap "Pair Devices". [6] Tap "IP Gateway/Touch Panel". Tap " ". [7] Tap "IP Touch 7 & 10". [8] Tap "Start Scanning". Product manual 2TMD042400D0014 │87...
  • Page 88 Commissioning [9] Tap "OK" to give the APP permission to use the camera. [10] Tap "Add panel to MyBuildings portal" to sync the APP’s MyBuildings account to the panel. [11] At the same time as adding the myBuildings portal, the APP will pair the panel. [12] On the panel screen, tick the designated check boxes to grant the rights for the APP.
  • Page 89: Time And Date Settings

    Commissioning 8.3.7 Time and date settings On the "Settings" screen, tap "Time & Date" to access the corresponding screen. Description Time server setting Select the time server from the drop-down list. – Default server = obtain the time data from the preset NTP servers. –...
  • Page 90: Changing Advanced Setting Password

    Commissioning 8.3.8 Changing advanced setting password Please follow the steps below: [1] On the "Settings" screen, tap "Access Management". [2] Tap "Secured Areas". [3] Tap "Advanced settings". [4] Tap "Change pincode". [5] Enter the existing password (original password is "345678"). [6] Tap "Save".
  • Page 91 Commissioning [7] Enter the new password. [8] Tap "Save". [9] Enter the new password again. [10] Tap "Save". Product manual 2TMD042400D0014 │91...
  • Page 92: Resetting Advanced Setting Password

    Commissioning 8.3.9 Resetting advanced setting password Please follow the steps below: [1] Within 3 minutes when the panel is powered on, on the "Settings" screen, tap "Access Management". [2] Tap "Secured Areas". [3] Tap "Advanced settings". [4] Tap "Reset Advanced Settings Pincode". [5] Tap "Yes".
  • Page 93: Configuring Unlock Password

    Commissioning 8.3.10 Configuring unlock password 1. Enabling the unlock password This unlock password will be used as a private password to release the lock on the designated Outdoor Station. Please follow the steps below: [1] On the "Settings" screen, tap "Access Management". [2] Tap "Outdoor Station".
  • Page 94 Commissioning 2. Changing the unlock password Please follow the steps below: [1] On the "Settings" screen, tap "Access Management". [2] Tap "Outdoor Station". [3] Tap "Change pincode". [4] Enter the existing unlock password. [5] Tap "OK". Product manual 2TMD042400D0014 │94...
  • Page 95 Commissioning [6] Enter the new unlock password. [7] Tap "OK". [8] Repeat the unlock password. [9] Tap "OK". 3. Resetting the unlock password The unlock password will be cleared when the "Resetting user settings" function is carried out. Product manual 2TMD042400D0014 │95...
  • Page 96: Language Setting

    Commissioning 8.3.11 Language setting Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Language". [3] Select the language from the drop-down list. Product manual 2TMD042400D0014 │96...
  • Page 97: Automatic Snapshot Setting

    Commissioning 8.3.12 Automatic snapshot setting Please follow the steps below: [1] On the "Settings" screen, tap "User settings". [2] Tap "Door Communication". [3] Tick the check box to enable the function. The panel will take 3 snapshots automatically in the 3rd, 5th, 7th second during an incoming call when this function is enabled.
  • Page 98: Missed Call Setting

    Commissioning 8.3.13 Missed call setting Please follow the steps below: [1] On the "Settings" screen, tap "User settings". [2] Tap "Door Communication". [3] Tick the check box to enable the function. When the function is enabled, will be displayed on the status bar to indicate the missed calls.
  • Page 99: Call Forwarding Settings

    Commissioning 8.3.14 Call forwarding settings The Forwarding call feature allows the call destinated to one Indoor Station to be redirected to a determined alternative Indoor Station, directly, in specific time slots, or in case of missing answer within a selected time. Creating a call forwarding Please follow the steps below: [1] On the "Settings"...
  • Page 100 Commissioning [5] Select the forwarding type. It can be set to "Direct Forwarding" or "No Answer". If "No Answer" is selected, you need to set "Duration", it can be set to "15","20" or "25". The ■ call will be forwarded after the duration time specified. If "Direct Forwarding"...
  • Page 101 Commissioning Removing a call forwarding Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Door Communication". [3] Find the designated call forwarding item. [4] Swipe the item to the left. [5] Tap " " to remove it. Product manual 2TMD042400D0014 │101...
  • Page 102 Commissioning Disabling the "Call Forwarding" function Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Door Communication". [3] Untick the check box to disable the function. Product manual 2TMD042400D0014 │102...
  • Page 103: Linking Call Setting

    Commissioning 8.3.15 Linking call setting People with hearing impairments cannot hear the ringing tone of an incoming call. It is recommended to link the call with a light connected to an IP Actuator. The designated light will turn on during an incoming call when this setting is enabled. Preconditions The relay lock of the IP Actuator should be set to "Unlock".
  • Page 104 Commissioning Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Door Communication". [3] Tick the check box to enable the function. [4] Select "Private IP Actuator -xx - Subsidiary" in this case. Product manual 2TMD042400D0014 │104...
  • Page 105: Call Forwarding Settings

    Commissioning 8.3.16 Call forwarding settings The Forwarding call feature allows the call destinated to one Indoor Station to be redirected to a determined alternative Indoor Station, directly, in specific time slots, or in case of missing answer within a selected time. Creating a call forwarding Please follow the steps below: [1] On the "Settings"...
  • Page 106 Commissioning [5] Select the forwarding type. It can be set to "Direct Forwarding" or "No Answer". If "No Answer" is selected, you need to set "Duration", it can be set to "15","20" or "25". The ■ call will be forwarded after the duration time specified. If "Direct Forwarding"...
  • Page 107 Commissioning Removing a call forwarding Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Door Communication". [3] Find the designated call forwarding item. [4] Swipe the item to the left. [5] Tap " " to remove it. Product manual 2TMD042400D0014 │107...
  • Page 108 Commissioning Disabling the "Call Forwarding" function Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Door Communication". [3] Untick the check box to disable the function. Product manual 2TMD042400D0014 │108...
  • Page 109: Resetting User Settings

    Commissioning 8.3.17 Resetting user settings Please follow the steps below: [1] On the "Settings" screen, tap "User Settings". [2] Tap "Reset User Settings". [3] Tap "Reset user settings". [4] On the pop-up warning window, tap "Yes". Product manual 2TMD042400D0014 │109...
  • Page 110 Commissioning The following settings will be restored to the default settings: Display settings ■ Sound settings ■ Unlock password ■ History records ■ The following settings will remain unchanged: WiFi settings ■ APP settings ■ MyBuildings settings ■ Longitude and Latitude settings ■...
  • Page 111: Configuring Outdoor Station Cameras

    Commissioning 8.3.18 Configuring Outdoor Station cameras Preconditions This panel and the designated Outdoor Station should be in the same building. ■ The designated Outdoor Station and this panel should have the same authentication. ■ 1. Add Outdoor Station cameras Please follow the steps below: [1] On the "Settings"...
  • Page 112 Commissioning [4] Tap the designated Outdoor Station on the list. [5] Tap "Add selected" or tap "Add all" to add the cameras. [6] Tap the relevant camera. [7] Surveillance will be initiated in a small window for 120 seconds. [8] Tap " "...
  • Page 113 Commissioning 2. Removing an Outdoor Station camera Please follow the steps below: [1] On the "Settings" screen, tap " Video Surveillance". [2] Tap "Outdoor Station Cameras". [3] Swipe the designate Outdoor Station to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │113...
  • Page 114: Configuring Private Cameras

    Commissioning 8.3.19 Configuring private cameras Preconditions The designated private cameras and the panel should be on the same network. ■ The panel only supports IP cameras with the Onvif protocol (Profile S, resolution format ■ H264 only). Topology Master Subsidiary Subsidiary Private camera Router...
  • Page 115 Commissioning 1. Adding private cameras Please follow the steps below: [1] On the "Settings" screen, tap "Video Surveillance". [2] Tap "IP private cameras". [3] Tap " ". [4] Tap "Automatic search". Product manual 2TMD042400D0014 │115...
  • Page 116 Commissioning [5] Tap the designated camera. [6] Tap "Add selected". [7] Enter the account and password for the camera. [8] Tap "Connect Camera". Product manual 2TMD042400D0014 │116...
  • Page 117 Commissioning [9] Tap "Continue". [10] Tap the relevant camera. [11] Surveillance will be initiated in a small window for 120 seconds. [12] Tap " " to take a snapshot. [13] The snapshot will be displayed on the screen. This snapshot will be the cover when the camera is added to the dashboard.
  • Page 118 Commissioning [15] Tick the check box to enable the function. You need to set "Outdoor Station cameras" before implementing this setting. For more details, see chapter 8.3.18 “Configuring Outdoor Station cameras“ on page 111. If this function is enabled, the Outdoor Station will display the image of private camera ■...
  • Page 119 Commissioning 2. Removing private cameras Please follow the steps below: [1] On the "Settings" screen, tap "Video Surveillance". [2] Tap "IP private cameras". [3] Swipe the designate camera to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │119...
  • Page 120: Configuring Public Cameras

    Commissioning 8.3.20 Configuring public cameras Preconditions The designated public cameras and the panel have been signed on the SmartAP. ■ The designated panel and SmartAP should be on the same network. ■ The panel only supports IP cameras with the Onvif protocol (Profile S, resolution format ■...
  • Page 121 Commissioning 1. Adding public cameras Please follow the steps below: [1] On the "Settings" screen, tap "Video Surveillance". [2] Tap "IP Public Cameras". [3] Tap " ". Product manual 2TMD042400D0014 │121...
  • Page 122 Commissioning [4] Tap the designated camera on the list. [5] Tap "Add selected" or tap "Add all" to add the cameras. [6] Tap the designated camera. [7] Surveillance will be initiated in a small window and last for 120 seconds. [8] Tap "...
  • Page 123 Commissioning [11] Tick the check box to enable the function. "Outdoor Station Cameras" needs to be set before this setting. For more details, see chapter 8.3.18 “Configuring Outdoor Station cameras“ on page 111. If this function is enabled, the Outdoor Station will display the image of public camera during ■...
  • Page 124 Commissioning 2. Removing public cameras Please follow the steps below: [1] On the "Settings" screen, tap "Video Surveillance". [2] Tap "IP Public Cameras". [3] Swipe the relevant camera to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │124...
  • Page 125: Configuring Intercom List

    Commissioning 8.3.21 Configuring intercom list Adding an intercom Please follow the steps below: [1] On the "Settings" screen, tap "Intercom List". [2] Tap "Intercom List". [3] Tap " ". [4] Select the device type. It can be set to "Intercom (external) ", "Intercom (Internal) " or "Guard Unit".
  • Page 126 Commissioning [8] Tap the relevant intercom. [9] Tap "Edit details" to edit the settings. [10] The intercom will be added to the dashboard automatically. Tap " " to remove it from the dashboard. Product manual 2TMD042400D0014 │126...
  • Page 127 Commissioning Removing an intercom Please follow the steps below: [1] On the "Settings" screen, tap "Intercom List". [2] Tap "Intercom List". [3] Swipe the relevant intercom to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │127...
  • Page 128: Configuring Program Buttons

    Commissioning 8.3.22 Configuring program buttons Adding a program button Please follow the steps below: [1] On the "Settings" screen, tap "Program Button". [2] Tap "Program Button". [3] Tap " ". [4] Select the type from the drop-down list. It can be set to "Lock" or "Light". [5] Select the associated device from the devices list.
  • Page 129 Commissioning [8] Tap the designated program button. [9] Tap "Edit details" to edit the settings. [10] The program button will be added to the dashboard automatically. Tap " " to remove it from the dashboard. [11] If "Actuator in APP" is enabled, this IP Actuator will be displayed on the APP screen. Only one IP Actuator can have this function enabled.
  • Page 130 Commissioning Removing a program button Please follow the steps below: [1] On the "Settings" screen, tap "Program Button". [2] Tap "Program Button". [3] Swipe the relevant program button to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │130...
  • Page 131 Commissioning Adding program buttons to the door communication screen Please follow the steps below: [1] On the "Settings" screen, tap "Program button". [2] Tap "Door Communication Screen". [3] Select the designated program button. [4] Edit the control list displayed on door communication screen: Tap "→"...
  • Page 132 Commissioning [5] Select the designated program button. [6] Adjust the order of the program buttons on the control list: Tap "↑" to move up the program button. ■ Tap " ↓" to move down the program button. ■ The designated program buttons will be display according to the control list on the door ■...
  • Page 133: Software Update

    Commissioning 8.3.23 Software update Update the firmware via the website Please ensure that the panel can connect to the internet. Please follow the steps below: [1] On the "Settings" screen, tap "Software Update". [2] The current software version will be displayed on the screen. [3] Tick the check box to enable the download function.
  • Page 134 Commissioning Product manual 2TMD042400D0014 │134...
  • Page 135 Commissioning [8] It will take a little while to download the new software. [9] Tick the check box to accept the licence. [10] Tap "OK". If you don’t want to update the firmware, tap "x" to exit. ■ Product manual 2TMD042400D0014 │135...
  • Page 136 Commissioning [11] "Installation successful!" will be displayed on the screen if successful. [12] Tap "Close window". Product manual 2TMD042400D0014 │136...
  • Page 137 Commissioning Update the firmware via SD card Please ensure that the firmware update file has been stored in the SD card and the SD card has been inserted into the panel. Please follow the steps below: [1] On the "Settings" screen, tap "Software Update". [2] The current software version will be displayed on the screen.
  • Page 138 Commissioning [8] It will take a little while to prepare the installation. [9] "Installation successful!" will be displayed on the screen if successful. [10] Tap "Close window". Product manual 2TMD042400D0014 │138...
  • Page 139: Rebooting The Panel

    Commissioning 8.3.24 Rebooting the panel Please follow the steps below: [1] On the "Settings" screen, tap "Software Update". [2] Go to the "Reboot this panel" section, tap "Reboot panel". [3] Tap "Reboot". Product manual 2TMD042400D0014 │139...
  • Page 140: About

    Commissioning 8.3.25 About Viewing the status of the network Please follow the steps below: [1] On the "Settings" screen, tap "About". [2] Tap "Network". [3] "Building Network" data and "Private Network" data will be displayed on the screen. Product manual 2TMD042400D0014 │140...
  • Page 141 Commissioning Viewing the status of MyBuildings portal Please follow the steps below: [1] On the "Settings" screen, tap "About". [2] Tap "Network". [3] "MyBuildings Portal" data will be displayed on the screen. Product manual 2TMD042400D0014 │141...
  • Page 142 Commissioning Viewing the basic information Please follow the steps below: [1] On the "Settings" screen, tap "About". [2] Tap "Common". [3] The following basic information will be displayed on the screen. Physical address ■ Master mode ■ Operating mode ■ Community network address &...
  • Page 143 Commissioning Obtaining the product manual Please follow the steps below: [1] On the "Settings" screen, tap "About". [2] Tap "QR Codes". [3] Scan the QR code on the left to access the website of this panel. [4] Click "Downloads". Product manual 2TMD042400D0014 │143...
  • Page 144 Commissioning [5] Click "Manual". [6] Find the designated product manual. [7] Click " " to download the PDF file. Product manual 2TMD042400D0014 │144...
  • Page 145 Commissioning Accessing the help centre Please follow the steps below: [1] On the "Settings" screen, tap "About". [2] Tap "QR Codes". [3] Scan the QR code on the right to access the website for the help centre. Product manual 2TMD042400D0014 │145...
  • Page 146: Advanced Settings

    Commissioning Advanced settings 8.4.1 Accessing the "Advanced settings" screen Please follow the steps below: [1] On the "Settings" screen, tap "Advanced Settings". [2] Enter the advanced password (The system default advanced password is 345678). The user must change this when accessing the advanced settings for the first time. Product manual 2TMD042400D0014 │146...
  • Page 147: Configuring The Physical Address

    Commissioning 8.4.2 Configuring the physical address Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Select the device mode from the drop-down list. It can be set to "Master mode" or "Subsidiary mode". Only one panel can be set to "Master mode" in the same apartment. ■...
  • Page 148: Configuring The Ip Address

    " .to configure the IP Address. Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the network type, it can set to "DHCP", "Customizable address" or "ABB Legacy". ■ If "ABB Legacy" is selected, IP address will be "10.0.x.x".
  • Page 149: Configuring The Trusted Devices

    Commissioning 8.4.4 Configuring the trusted devices This function applies to single family house application. The master panel will create a certification and assign the certificates to other devices on the same home networks (e.g. 2nd outdoor station, private IP actuator and subsidiary indoor station).
  • Page 150 Commissioning Enabling the trusted function Please follow the steps below: [1] On the "Advanced Settings" screen, ensure "Enable trusted devices function" is enabled. The function will be enabled if you select "Configuration without SmartAP" in the wizard setup. [2] "Trusted devices" will be displayed. Product manual 2TMD042400D0014 │150...
  • Page 151 Commissioning Adding devices via automatic search Please follow the steps below: [1] On the "Trusted Devices" screen, tap " ". [2] Select "Automatic search". [3] The devices on the same home network will be displayed on the list. [4] Tap "Continue". Product manual 2TMD042400D0014 │151...
  • Page 152 Commissioning [5] All the devices will be displayed on the screen. [6] If the new devices found in the automatic searching contain the 2nd OS or the Private IP Actuator, you need to tap "Trust all devices" to trust these devices. [7] In the pop-up window, tap "Trust All".
  • Page 153 Commissioning [8] The trusted devices will be displayed in the pop-up window. [9] Tap "x" to close the window. [10] will be displayed on the right to indicate the 2nd Outdoor Station or IP Actuator. Product manual 2TMD042400D0014 │153...
  • Page 154 Commissioning Adding the device manually Please follow the steps below: [1] On the "Trusted Devices" screen, tap " ". [2] Select "Entry manually". [3] Select the device type from the drop-down list. It can be set to "2nd OS", "Private IP actuator"...
  • Page 155 Commissioning [7] The designated device has been added to the list. [8] If the new device belongs to the 2nd OS or the Private IP Actuator, you need to tap "Trust all devices" to trust this device. [9] In the pop-up window, tap "Trust All". Product manual 2TMD042400D0014 │155...
  • Page 156 Commissioning [10] The trusted devices will be displayed in the pop-up window. [11] Tap "x" to close the window. [12] will be displayed on the right to indicate the 2nd Outdoor Station or IP Actuator. Product manual 2TMD042400D0014 │156...
  • Page 157 Commissioning Removing the trusted device Please follow the steps below: [1] On the "Trusted Devices" screen, swipe the relevant device to the left. [2] Tap " " to remove the device. Product manual 2TMD042400D0014 │157...
  • Page 158: Configuring The "Manual Snapshot" Function

    Commissioning 8.4.5 Configuring the "Manual snapshot" function If this function is enabled, you can take snapshots during door communication. Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Go to the "Options" section, tick the check box to enable the function. [3] Tap "Save".
  • Page 159: Configuring The "Manual Video Recording" Function

    Commissioning 8.4.6 Configuring the "Manual video recording" function If this function is enabled, you can record a video during door communication. Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Go to the "Options" section, tick the check box to enable the function. [3] Tap "Save".
  • Page 160: Configuring The "Auto Unlock" Function

    Commissioning 8.4.7 Configuring the "Auto unlock" function If this function is enabled, the panel will release the lock on the Outdoor Station automatically after 5 seconds during an incoming call. This function can only be set on the "Master mode" panel. Please follow the steps below: [1] On the "Advanced Settings"...
  • Page 161 Commissioning [4] On the "Settings" screen, tap "User Settings". [5] Tap "Door Communication". [6] Tick the check box to enable the function. [7] Select the unlock mode. Automatically unlock = automatically unlock at any time, skip the subsequent steps. ■ Auto-unlock programmable timer = automatically unlock at the specific time, continue from ■...
  • Page 162 Commissioning [9] Set "Start Time" and "End Time". [10] Select the designated days. Tap the designated day to select it or invert the selection. ■ Tap "Weekdays" to select 5 working days together. ■ Tap "Weekend" to select "Saturday" and "Sunday" together. ■...
  • Page 163: Configuring The "Delete Call History" Function

    Commissioning 8.4.8 Configuring the "Delete call history" function Call history records cannot be removed by default. Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Go to the "Options" section, tick the check box to enable the function. [3] Tap "Save".
  • Page 164 Commissioning [4] On the dashboard, tap the "Events" module. [5] On the "Notification Center" screen, swipe the relevant record to the left. [6] Tap " " to remove the record. [7] Tap "Delete all" to remove all the history records. Product manual 2TMD042400D0014 │164...
  • Page 165: Configuring The Address Of Default Guard Unit

    Commissioning 8.4.9 Configuring the address of default Guard Unit Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Go to the "Default Guard Unit" section, enter the address (1...32). An SoS message will be sent to the default Guard Unit, SmartAP or APP if possible when it is triggered.
  • Page 166: Restoring To Factory Default

    Commissioning 8.4.10 Restoring to factory default Please follow the steps below: [1] On the "Advanced Settings" screen, tap "Panel". [2] Go to the "Reset Panel Option" section, tap "Reset to factory setting". [3] Tap "Yes". Product manual 2TMD042400D0014 │166...
  • Page 167: Configuring The Outdoor Station

    Commissioning Configuring the Outdoor Station The IP pushbutton Outdoor Station and mini Outdoor Station can be configured via this panel. Please see the product manual of the related Outdoor Station for more details. Product manual 2TMD042400D0014 │167...
  • Page 168: Configuring The Ip Actuator

    Commissioning Configuring the IP Actuator IP Actuator can be configured via this panel. Please see the product manual of IP Actuator for more details. Product manual 2TMD042400D0014 │168...
  • Page 169: Operation

    Operation Operation Dashboard 9.1.1 Dashboard overview Description There are 2 screens available for use, the second screen is empty by default. Some main functional modules are fixed at the top of the first screen. Events; this indicates if there is a new event, for instance, you are receiving a call, or you ■...
  • Page 170: Accessing The Editing Status

    Operation 9.1.2 Accessing the editing status On the dashboard, tap “ ” to access the editing mode. Product manual 2TMD042400D0014 │170...
  • Page 171: Creating A Control For The Camera

    Operation 9.1.3 Creating a control for the camera Precondition Please configure a camera before this operation. [1] Configuring Outdoor Station cameras. For more details, see chapter 8.3.18 “Configuring Outdoor Station cameras“ on page 111. ■ [2] Configuring private cameras. For more details, see chapter 8.3.19 “Configuring private cameras“ on page 114. ■...
  • Page 172 Operation [2] Select "Camera" from the drop-down list. [3] Select the device type from the drop-down list. It can be set to "Outdoor Station Camera", "Public Camera" or "Private Camera". [4] Tap "Next". [5] Select the designated device from the drop-down list. [6] Enter the alias name of the device.
  • Page 173 Operation [9] Tap "x". [10] The control will be displayed on the dashboard. Product manual 2TMD042400D0014 │173...
  • Page 174: Creating A Control For The Intercom

    Operation 9.1.4 Creating a control for the intercom Precondition Please configure an intercom before this operation. For more details, see chapter 8.3.21 “Configuring intercom list“ on page 125. ■ Please follow the steps below: [1] Ensure the dashboard is in editing mode, tap a blank area of dashboard, then tap " + " to add a control.
  • Page 175 Operation [2] Select "Intercom" from the drop-down list. [3] Select the intercom type from the drop-down list. It can be set to "Intercom (external)", "Intercom (internal)" or "Guard Unit". [4] Tap "Next". [5] Select the designated device from the drop-down list. [6] Enter the alias name of the device.
  • Page 176 Operation [9] Tap "x". [10] The control will be displayed on the dashboard. Product manual 2TMD042400D0014 │176...
  • Page 177: Creating A Control For The Light

    Operation 9.1.5 Creating a control for the light Precondition Please configure a program button to turn on a light before this operation. For more details, see chapter 8.3.22 “Configuring program buttons“ on page 128. ■ Please follow the steps below: [1] Ensure the dashboard is in editing mode, tap a blank area of dashboard, then tap "...
  • Page 178 Operation [2] Select "Light" from the drop-down list. [3] Tap "Next". [4] Select the designated device from the drop-down list. [5] Enter the alias name of the device. [6] Select the size of the frame. It can be set to "1 slot", "2 slots" or "4 slots". [7] Tap "Save &...
  • Page 179 Operation [8] Tap "x". [9] The control will be displayed on the dashboard. Product manual 2TMD042400D0014 │179...
  • Page 180: Creating A Control For The Door Lock

    Operation 9.1.6 Creating a control for the door lock Precondition Please configure a program button to unlock before this operation. For more details, see chapter 8.3.22 “Configuring program buttons“ on page 128. ■ Please follow the steps below: [1] Ensure the dashboard is in editing mode, tap a blank area of dashboard, then tap " + " to add a control.
  • Page 181 Operation [2] Select "Door Unlock" from the drop-down list. [3] Tap "Next". [4] Select the designated Outdoor Station from the drop-down list. [5] Enter the alias name of the device. [6] Select the size of the frame. It can be set to "1 slot", "2 slots" or "4 slots". [7] Tap "Save &...
  • Page 182 Operation [8] Tap "x". [9] The control will be displayed on the dashboard. Product manual 2TMD042400D0014 │182...
  • Page 183: Creating A Control For The Elevator

    Operation 9.1.7 Creating a control for the elevator Please follow the steps below: [1] Ensure the dashboard is in editing mode, tap a blank area of dashboard, then tap " + " to add a control. [2] Select "Elevator" from the drop-down list. [3] Tap "Next".
  • Page 184 Operation [4] Enter the alias name of the device. [5] Select the size of the frame. It can be set to "1 slot", "2 slots" or "4 slots". [6] Tap "Save & close". [7] Tap "x". Product manual 2TMD042400D0014 │184...
  • Page 185 Operation [8] The control will be displayed on the dashboard. Product manual 2TMD042400D0014 │185...
  • Page 186: Editing The Control

    Operation 9.1.8 Editing the control Ensure the dashboard is in editing mode. Tap the arrow icon (e.g. " ") to move the control in the specified direction. ■ Tap " " to change the settings of the control. ■ Tap " "...
  • Page 187: Incoming Call

    Operation Incoming call 9.2.1 Call from Outdoor Stations 1. During an incoming call Function " Incoming" indicates an incoming call (maximum 30 seconds). Display the device name. Display the image Display the image of the calling Outdoor Station by default. ■...
  • Page 188 Operation 2. During communication Function " Communication" indicates a communication process (maximum 120 seconds). Display the device name. Display the image Display the image of the calling Outdoor Station by default. ■ If a camera has been assigned to the calling Outdoor Station, the image from the camera will ■...
  • Page 189: Call From Guard Units Or Indoor Stations

    Operation 9.2.2 Call from Guard Units or Indoor Stations 1. During an incoming call Function " Incoming" indicates an incoming call. Display the device name. Display " " to indicate no image can be displayed on the screen. The countdown (9…1) will be displayed in the last 9 s. Tap "...
  • Page 190 Operation 2. During communication Function " Communication" indicates a communication process. Display the device name. Display " " to indicate no image can be displayed on the screen. The countdown (9…1) will be displayed in the last 9 s. Tap " "...
  • Page 191: Call From Doorbell

    Operation 9.2.3 Call from doorbell When the doorbell is pressed, this device will display " " for 5 seconds on the status bar. If the doorbell is associated with the camera, the panel will display the image from the camera automatically.
  • Page 192: Intercom

    Operation Intercom Please follow the steps below: [1] Adding a control for the intercom to the dashboard. For mode details, see chapter 9.1.4 “Creating a control for the intercom“ on page 174. ■ [2] On the dashboard, tap the designated intercom to initiate a call. Product manual 2TMD042400D0014 │192...
  • Page 193: Call Guard Unit

    Operation Call Guard Unit Please follow the steps below: [1] Configuring the address of the default Guard Unit. For more details,.see chapter 8.4.9 “Configuring the address of default Guard Unit“ on ■ page 165. [2] Adding a control for the Guard Unit to the dashboard. For more details,.see chapter 9.1.4 “Creating a control for the intercom“...
  • Page 194: Surveillance

    Operation Surveillance 9.5.1 Accessing video surveillance Please follow the steps below: [1] Adding a control for the designated Outdoor Station or the IP camera to the dashboard. For more details, see chapter 9.1.3 “Creating a control for the camera“ on page 171. ■...
  • Page 195: Surveillance From Outdoor Stations

    Operation 9.5.2 Surveillance from outdoor stations Description " Video Surveillance" indicates surveillance (120 seconds). Display the device name. Display the image Display the image of the relevant Outdoor Station. ■ If a camera has been assigned to the calling Outdoor Station, the image from the camera ■...
  • Page 196: Surveillance From Ip Camera

    Operation 9.5.3 Surveillance from IP camera Function " Video Surveillance" indicates a surveillance process (120 seconds). Display the device name. Display the image of the relevant camera. The countdown (9…1) will be displayed in the last 9 s. Tap "<"or ">" to display the images from other Outdoor Station or the cameras. Tap "...
  • Page 197: Releasing The Lock

    Operation Releasing the lock Please follow the steps below: [1] Adding a control for the relevant lock to the dashboard. For more details, see chapter 9.1.6 “Creating a control for the door lock“ on page 180. ■ [2] On the dashboard, tap the designated door lock to release it. [3] "...
  • Page 198: Turn On A Light

    Operation Turn on a light Please follow the steps below: [1] Adding a control for the designated light to the dashboard. For more details, see chapter 9.1.5 “Creating a control for the light“ on page 177. ■ [2] On the dashboard, tap the designated light to turn on it. [3] "...
  • Page 199: Call The Elevator

    Operation Call the elevator Please follow the steps below: [1] Adding a control for the designated elevator to the dashboard. For more details, see chapter 9.1.7 “Creating a control for the elevator“ on page 183. ■ [2] On the dashboard, tap the designated elevator to activate it. [3] Tap the direction icon e.g.
  • Page 200 Operation [4] " " will be displayed on the dashboard to indicate the process. Product manual 2TMD042400D0014 │200...
  • Page 201: Configuring The Voice

    Operation Configuring the voice 9.9.1 Adjusting the voice volume Please follow the steps below: [1] On the dashboard, tap the voice icon " ". [2] In the pop-up window, drag the scroll bar to adjust the voice volume. Product manual 2TMD042400D0014 │201...
  • Page 202: Configuring The "Mute" Function

    Operation 9.9.2 Configuring the "Mute" function Please follow the steps below: [1] On the dashboard, tap the voice icon " ". [2] On the pop-up window, select the mute type. It can be set to "2 hours", "Today" or "Always". [3] Select the relevant objects.
  • Page 203: Sending An Alarm Request

    Operation 9.10 Sending an alarm request If you are in distress, something has happened at home, or if you live with an old or sick person at home and they need some support, they can send an alarm request. An automatic message will be sent to the accounts that are shared between the family and APP.
  • Page 204: History

    Operation 9.11 History Accessing the "Call History" screen On the dashboard, tap "Events" to access the "Call history" screen. " " indicates there are missed calls. Product manual 2TMD042400D0014 │204...
  • Page 205: Viewing The Call Records

    Operation Viewing the call records On the "Call History" screen, Description " " indicates that the record contains a video. " " indicates a missed call. " " indicates the SOS record " " indicates an intercom " " indicates an unlock "...
  • Page 206: Clean Screen

    Operation 9.12 Clean screen Please follow the steps below: [1] On the "Settings", "Display" screen, tap "Settings". [2] Tap "Activate display cleaning mode". [3] The countdown (30…1) is displayed on the screen. Any operations on the screen will be invalid. This panel will exit "Cleaning mode" if an incoming call is received. Product manual 2TMD042400D0014 │206...
  • Page 207: Home Automation

    Home automation Home automation 10.1 KNX settings 10.1.1 Precondition You need to enable the "KNX" function during the Setup Wizard before use. Product manual 2TMD042400D0014 │207...
  • Page 208: Setup Wizard - Knx Only

    Home automation 10.1.2 Setup Wizard - KNX only Please follow the steps below: [1] On the "Setup wizard" screen, select the language from the drop-down list. [2] Select the region from the drop-down list. [3] Tick the check box to accept the licenses. Or tap "Click to read" to view the details of the license.
  • Page 209 Home automation [5] On the "System Configuration" screen during the "Wizard Setup", Disable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "KNX" single choice. ■ [6] Tap "Continue". Product manual 2TMD042400D0014 │209...
  • Page 210 Home automation [7] On the "IP Addressing" screen, tap "Edit" to access the corresponding screen. Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the address type, it can set to "DHCP" or "Customizable address". ■...
  • Page 211 Home automation [9] Select the network type. It can be set to "KNX IP Interface" or "KNX IP Router". Enter the IP address. ■ [10] Tick/untick the check box to enable/disable the function. This function must be enabled if an IPS with encryption function is used. ■...
  • Page 212 Home automation [13] On the "Time & date" screen, you can carry out this setting at this time or tap "Continue" to skip this setting for the moment. For more details, see chapter 8.3.7 “Time and date settings“ on page 89. ■...
  • Page 213: Setup Wizard - Door Entry System With Knx

    Home automation 10.1.3 Setup Wizard - Door Entry System with KNX Please follow the steps below: [1] On the "Setup wizard" screen, select the language from the drop-down list. [2] Select the region from the drop-down list. [3] Tick the check box to accept the licenses. Or tap "Click to read" to view the details of the license.
  • Page 214 Home automation [5] On the "System Configuration" screen during the "Wizard Setup", Enable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "KNX" single choice. ■ [6] Tap "Continue". Other settings please refer to the following chapters for more details. For more details about "Door Entry System", see chapter 8.2 “Setup wizard - Door Entry ■...
  • Page 215: Viewing The Information

    Home automation 10.1.4 Viewing the information Please follow the steps below: [1] On the dashboard, tap "Dashboard". [2] Tap " ". [3] Tap "About". [4] Tap "KNX". [5] The basic KNX information will be displayed: Device name ■ IP address of KNX interface ■...
  • Page 216 Home automation [6] Tap "Common". [7] Check the operating mode. Product manual 2TMD042400D0014 │216...
  • Page 217: Configuring The System Code

    Home automation 10.1.5 Configuring the system code If the function "Enable system settings for end customer" is set to "With code" via the ETS tool, you need to enter the system code when accessing the "Settings" screen. The original system code is "0000". ■...
  • Page 218 Home automation You can change the system code on the "Settings" screen. Please follow the steps below: [1] On the "Settings" screen, tap "Access Management". [2] Tap "Secured Areas". [3] Tap "System". [4] Tap "Change pincode". [5] Enter the new password (original password is "0000"). [6] Tap "Save”.
  • Page 219: Configuring The Pin Codes

    Home automation 10.1.6 Configuring the pin codes If the function "PIN-Codes can be changed by end customer" is enabled via the ETS tool, you need to enter the pin code to view the device screen. The original pin code level 1 is "1111". ■...
  • Page 220 Home automation You can change the pin code on the "Settings" screen. Please follow the steps below: [1] On the "Settings" screen, tap "Access Management". [2] Tap "Secured Areas". [3] Tap "System". [4] Tap "Change pincode". [5] Enter the new password (original password is "0000"). [6] Tap "Save".
  • Page 221: Configuring Program Buttons

    Home automation 10.1.7 Configuring program buttons Adding program buttons Please follow the steps below: [1] On the "Settings" screen, tap "Program Button". [2] Tap "Program Button". [3] The program buttons configured via ETS tool will be displayed. [4] Tap the designated program button to change the name. [5] Tap "...
  • Page 222 Home automation [6] If "Actuator in APP" is enabled, this IP Actuator will be displayed on the APP screen. Only one IP Actuator can enable this function. [7] If "Link lock to KNX" is enabled, the IP Actuator or the Outdoor Station will release the lock or turn on a light when a KNX control happens.
  • Page 223 Home automation Removing a program button Please follow the steps below: [1] On the "Settings" screen, tap "Program Button". [2] Tap "Program Button". [3] Swipe the relevant program button to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │223...
  • Page 224 Home automation Adding program buttons to the door communication screen Please follow the steps below: [1] On the "Settings" screen, tap "Program button". [2] Tap "Door Communication Screen". [3] Select the designated program button. [4] Edit the control list displayed on door communication screen: Tap "→"...
  • Page 225 Home automation [5] Select the designated program button. [6] Adjust the order of the program buttons on the control list: Tap "↑" to move up the program button. ■ Tap " ↓" to move down the program button. ■ The designated program buttons will be display according to the control list on the door ■...
  • Page 226: Configuring The Advanced Settings

    Home automation 10.1.8 Configuring the advanced settings Please follow the steps below: [1] On the "Settings" screen, tap "Advanced Settings", enter the advanced password (The system default advanced password is 345678) to access the "Advanced Settings" screen. [2] On the "Advanced Settings" screen, tap "Building Automation". [3] Select the network type.
  • Page 227: Configuring The Home Automation Devices

    Home automation 10.1.9 Configuring the home automation devices There are 2 ways to configure the home automation devices. Option 1: Read the .pid file from SD card on the panel Please ensure that the .pid file has been stored on the SD card and this SD card has been inserted into the panel.
  • Page 228 Home automation [6] "Reading SD card" will be displayed. [7] KNX devices have been configured on the panel successfully. Product manual 2TMD042400D0014 │228...
  • Page 229 Home automation Option 2: ETS tools download the .pid file to the panel Please see the ETS product manual. Product manual 2TMD042400D0014 │229...
  • Page 230: 10.1.10 Viewing The Home Automation Devices

    Home automation 10.1.10 Viewing the home automation devices You can swipe the screen to left or right to view the home automation devices. Or click " ", followed by "Category", then click the device type to view the home automation devices.
  • Page 231: 10.1.11 Configuring The Knx Timers

    Home automation 10.1.11 Configuring the KNX timers You can use the "KNX timer" function to control the KNX devices automatically during the designated period. Access the "KNX timer" screen Please follow the steps below: [1] On the dashboard, tap " ".
  • Page 232 Home automation Predefined timers Please follow the steps below: [1] On the "Timers overview" screen, tap "Predefined timers". [2] The predefined timer via ETS tool will be displayed. Tap " " to enable or disable the timer of the device. ■...
  • Page 233 Home automation [5] Swipe the timer to the left to display more operations. Tap " " to enable or disable each timer. ■ Tap " " to duplicate a new timer. ■ Tap " " to remove the timer. ■ Product manual 2TMD042400D0014 │233...
  • Page 234 Home automation Individual timers Please follow the steps below: [1] On the "Timers overview" screen, tap "Individual timers". [2] Tap " " to add a new timer. [3] Find the designated device, tap " ". Product manual 2TMD042400D0014 │234...
  • Page 235 Home automation [4] Tap the icon to control the device. [5] Tap " ". [6] Set the time for the timer. [7] Set the effective days for the timer. [8] Set the effective period. It can be set to "Always", "Only in vacation" or "Not in vacation". [9] Tap "...
  • Page 236 Home automation [10] The timer will be displayed. [11] Tap " " to add a new timer. A maximum of 10 timers can be set. ■ [12] Swipe the timer to the left to display more operations. Tap " " to enable or disable each timer. ■...
  • Page 237 Home automation Presence simulation You need to record a set of operations before use. Please follow the steps below: [1] On the "Timers overview" screen, tap "Presence simulation". [2] Tap " " to activate the presence simulation. [3] Tap " "...
  • Page 238 Home automation Vacation setting Please follow the steps below: [1] On the "Timers overview" screen, tap "Vacation". [2] Set the start time and end time for the vacation. [3] Tick or untick the check box to enable or disable the function. Product manual 2TMD042400D0014 │238...
  • Page 239: 10.1.12 Notification

    Home automation 10.1.12 Notification Please follow the steps below: [1] On the dashboard, tap "Events". [2] On the "Notification Center" screen, tap "Notification". [3] The notification will be displayed, click the notification to view the details. [4] Swipe the notification to the left. [5] Tap "...
  • Page 240 Home automation [6] Tap "Archive". [7] The notification s are displayed. There are 3 types of notifications. Information ■ Warning ■ Alarm ■ [8] Swipe the alarm to the left. [9] Tap " " to remove the alarm. [10] Tap "Copy to SD card" to copy the notifications to the SD card. [11] Tap "Delete all"...
  • Page 241: 10.1.13 Commissioning The Home Automation Devices Via Ets Tool

    Home automation 10.1.13 Commissioning the home automation devices via ETS tool For commissioning the KNX devices, please see the ETS product manual at the following link: https://search.abb.com/library/Download.aspx?DocumentID=2CKA001473B5022&LanguageCo de=en&DocumentPartId=&Action=Launch. Product manual 2TMD042400D0014 │241...
  • Page 242: Free@Home Settings

    Home automation 10.2 free@home settings 10.2.1 Precondition Pos: 183 /CNDEX/08 C om missionin g/Glo bal IP/IP t ouc h/Prec onditi on - fre e@h ome settin gs_H 8236 @ 1 20\ mod _161 404 617 218 4_1 5.doc x @ 1 428 303 @ @ 1 You need to enable the "free@home"...
  • Page 243: Setup Wizard - Free@Home Only

    Home automation 10.2.2 Setup Wizard - free@home only Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 Please follow the steps below: [1] On the "Setup wizard"...
  • Page 244 Home automation [5] On the "System Configuration" screen during the "Wizard Setup", Disable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "free@home" single choice. ■ [6] Tap "Continue". Product manual 2TMD042400D0014 │244...
  • Page 245 Home automation [7] On the "IP Addressing" screen, tap "Edit" to access the corresponding screen. Select the connection type, it can be set to "LAN" or "WiFi". ■ Select the address type, it can set to "DHCP" or "Customizable address". ■...
  • Page 246 Home automation [9] The panel will search for the SysAP in the same network. [10] Select the designated SysAP. Tap "Connect". If there is no existing SysAP, you can tap "Continue without connection" to continue from ■ step 14. [11] The validation code will be displayed. Please check this code on the designated SysAP if the two codes match.
  • Page 247 Home automation [12] The "Successfully connected to SysAP" will be displayed when the designated SysAP click "Confirm" to ensure the correct connection. [13] Tap "x" to close the current window. [14] On the "Time & date" screen, you can carry out this setting at this time or tap "Continue" to skip this setting for the moment.
  • Page 248 Home automation [15] There are 5 screens to guide you on how to use the panel. [16] Tap "Skip" if you are already familiar with the panel. Product manual 2TMD042400D0014 │248...
  • Page 249: Setup Wizard - Door Entry System With Free@Home

    Home automation 10.2.3 Setup Wizard - Door Entry System with free@home Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 Please follow the steps below: [1] On the "Setup wizard"...
  • Page 250 Home automation [5] On the "System Configuration" screen during the "Wizard Setup", Enable the "Door Entry Welcome IP" check box. ■ Enable the "Home Automation" check box. ■ Enable the "free@home" single choice. ■ [6] Tap "Continue". Other settings please refer to the following chapters for more details. For more details about "Door Entry System", see chapter 8.2 “Setup wizard - Door Entry ■...
  • Page 251: Viewing The Information

    Home automation 10.2.4 Viewing the information Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 Please follow the steps below: [1] On the dashboard, tap "Dashboard".
  • Page 252 Home automation [6] Tap "Common". [7] Check the operating mode. Product manual 2TMD042400D0014 │252...
  • Page 253: Configuring Program Buttons

    Home automation 10.2.5 Configuring program buttons Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 Adding program buttons Please follow the steps below: [1] On the "Settings"...
  • Page 254 Home automation Removing a program button Please follow the steps below: [1] On the "Settings" screen, tap "Program Button". [2] Tap "Program Button". [3] Swipe the relevant program button to the left. [4] Tap " " to remove it. Product manual 2TMD042400D0014 │254...
  • Page 255 Home automation Adding program buttons to the door communication screen Please follow the steps below: [1] On the "Settings" screen, tap "Program button". [2] Tap "Door Communication Screen". [3] Select the designated program button. [4] Edit the control list displayed on door communication screen: Tap "→"...
  • Page 256 Home automation [5] Select the designated program button. [6] Adjust the order of the program buttons on the control list: Tap "↑" to move up the program button. ■ Tap " ↓" to move down the program button. ■ The designated program buttons will be display according to the control list on the door ■...
  • Page 257: Configuring The Advanced Settings

    Home automation 10.2.6 Configuring the advanced settings Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 You can also pair the panel with free@home SysAP on the "Advanced settings". Please follow the steps below: [1] On the "Advanced settings"...
  • Page 258 Home automation [4] The validation code will be displayed. Please check this code on the designated SysAP if the two codes match. [5] The "xxx (connected)" will be displayed when the designated SysAP click "Confirm" to ensure the correct connection. Product manual 2TMD042400D0014 │258...
  • Page 259: Viewing The Home Automation Devices

    Home automation 10.2.7 Viewing the home automation devices Pos: 182 /CNDEX/01 H eadin g/1. 1.1 H eadi ng/He adin g_Prec ondi tion @ 12 0\m od_1 612 755 204 569 _15. docx @ 14 221 87 @ 3 @ 1 You can swipe the screen to left or right to view the home automation devices.
  • Page 260 Home automation Or click " ", followed by "Room", then select the location to view the home automation devices. Product manual 2TMD042400D0014 │260...
  • Page 261: Alarm Record

    Home automation 10.2.8 Alarm record Please follow the steps below: [1] On the dashboard, tap "Events". [2] On the "Notification Center" screen, tap "Alert Message". [3] The alarm records will be displayed, click the alarm record to view the details. [4] Swipe the alarm record to the left.
  • Page 262 Home automation [7] On the "Notification Center" screen, tap "Others". [8] The notifications about the connection will be displayed, click the notification to view the details. [9] Swipe the notification to the left. [10] Tap " " to remove the notification. [11] Tap "...
  • Page 263: Commissioning The Home Automation Devices Via Sysap

    Home automation 10.2.9 Commissioning the home automation devices via SysAP For commissioning the free@home devices, please see the product manual of SysAP via the following link: https://search.abb.com/library/Download.aspx?DocumentID=2CKA001473B9726&LanguageCo de=en&DocumentPartId=&Action=Launch. Product manual 2TMD042400D0014 │263...
  • Page 264: Cyber Security

    H8236 product, the network, its system and interfaces against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. ABB Ltd and its affiliates are not liable for damages and/or losses related to such security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information.
  • Page 265: Performance And Service

    Cyber security 11.2 Performance and service Network performance Type Value Ethernet 36 Mbps (53,568 packets/s) 17 Mbps (25,296 packets/s) ICMP 14 Mbps (20,832 packets/s) 22 Mbps (32,736 packets/sec) Port and service Port Service Purpose 5060 To be used by sip client. 5061 To be used by sip server 5070...
  • Page 266: Deployment Guideline

    Malware prevention solution The device H8236 is not susceptible to malware, because custom code cannot be executed on the system. The only way to update the software is via firmware upgrades. Only firmware signed by ABB can be accepted. 11.7 Password rule The user needs to change the engineering password when entering the engineering settings for the first time.
  • Page 267 We reserve the right to at all times make technical changes as well as changes to the contents of this document without prior notice. The detailed specifications agreed to at the time of ordering apply to all orders. ABB accepts no responsibility for possible errors or incompleteness in this document.
  • Page 268 Contact us Notice We reserve the right to at all times ABB Xiamen Smart Technology Co., Ltd. make technical changes as well as No. 881, FangShanXiEr Road, Xiang’An Industrial changes to the contents of this Area, Torch Hi-Tech Industrial Development document without prior notice.

Table of Contents
