GAST LUBRICATED 1067, 2067 and 2567
SERIES ROTARY VANE VACUUM PUMPS
O
Thank you for purchasing this Gast product. It is manufactured to the highest standards
using quality materials. Please follow all recommended maintenance, operational
and safety instructions and you will receive years of trouble free service.
PLEASE READ THIS MANUAL COMPLETELY BEFORE INSTALLING AND USING
Product Use Criteria:
• Operate at 32ºF - 104ºF (0ºC - 40ºC).
• Protect unit from dirt & moisture.
• Protect all surrounding items from hot exhaust air.
This exhaust air can become very hot.
• Product is not a consumer product and is for
commercial applications only.
• Do not pump flammable or explosive gases or use
in an atmosphere that contains such gases.
• Corrosive gases and particulate material will
damage unit. Water vapor, oil-based contaminants
or other liquids must be filtered out.
• Consult your Gast Distributor/Representative
before using at high altitudes.
• Use Gast #AD220 or a detergent SAE#10 automotive
engine oil for lubricating.
®Registered Trademark/™Trademark of Gast Manufacturing Inc., Copyright ©
& COMPRESSORS
& M
PERATION
AINTENANCE
WARNING
THIS MOTOR. SAVE THIS MANUAL FOR FUTURE REFERENCE AND
KEEP IN THE VICINITY OF THE MOTOR.
M
ANUAL
www.gastmfg.com
Gast Manufacturing Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1067 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Gast 1067 Series

  • Page 1 & M PERATION AINTENANCE ANUAL Thank you for purchasing this Gast product. It is manufactured to the highest standards using quality materials. Please follow all recommended maintenance, operational and safety instructions and you will receive years of trouble free service. WARNING PLEASE READ THIS MANUAL COMPLETELY BEFORE INSTALLING AND USING THIS MOTOR.
  • Page 2: Installation

    Consult a Only pump air, never allow this pump to be used Gast Representative for additional filter recommendations. with any other gasses, fluids, particles, solids, Install relief valves and gauges at the inlet or outlet, or both, COMBUSTIBLE SUBSTANCES or any substance mixed with air.
  • Page 3: Operation

    Electrical Connection OPERATION DIAGRAM A WARNING Grounded Plug Grounding Pin 120-volt grounded connectors Injury Hazard shown. 220/ 240-volt grounded Install proper safety guards as needed. Pumps with Grounded Outlet connectors will differ in shape. glass jars need safety guards to protect against breaking glass.
  • Page 4: Shutdown Procedures

    Vanes will stick when dirty and may cause pump to be noisy or inefficient. Use only Gast recommended Flushing Solvent or other non-petroleum based flushing solvent. Do Not use kerosene or ANY other combustible solvent to flush product.
  • Page 5 5. Clean all surfaces with Gast recommended Flushing solvent and dry well. Pump Re-assembly 6. Apply a light coat of Gast recommended Oil Part #AD220 (an equivalent 10 wt. high detergent oil can alsoo be used) to vanes. 7. Re-install vanes, noting proper direction of beveled edge (refer to exploded view) 8.
  • Page 6 EXPLODED PRODUCT VIEW 1 1 065 SERIES Note: Parts list on next page...
  • Page 7: Parts & Ordering Information

    PARTS & ORDERING INFORMATION DESCRIPTION VACUUM VACUUM VACUUM PUMP COMPRESSOR PUMP COMPRESSOR PUMP COMPRESSOR 1067-V1 1067-P2 2067-V1 2067-P2 2567-V1 2567-P2 BODY AH345 AH345 AH191 AH191 AH355 AH355 ROTOR ASSEMBLY AH428 AH428 AH192 AH192 AH192 AH192 3 Δ VANE AH429 AH429 AA750D AA750D AH750D...
  • Page 8: Warranty

    Service Center (unless specifically agreed upon in writing signed by both parties or specified in writing as part of a Gast OEM Quotation). Buyer is responsible for freight charges both to and from Gast in all cases.
