Tribesigns LITTLE TREE HOGA-F2155 Assembly Instructions Manual

Console table
Hide thumbs

Advertisement

Quick Links

Download this manual
DESIGNED FOR LIFE
Assembly Instructions
Model No.
Little Tree by Tribesigns
Console Table
HOGA-
F2155
www.tribesigns.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the LITTLE TREE HOGA-F2155 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tribesigns LITTLE TREE HOGA-F2155

Summary of Contents for Tribesigns LITTLE TREE HOGA-F2155

  • Page 1 DESIGNED FOR LIFE Assembly Instructions Model No. Little Tree by Tribesigns Console Table HOGA- F2155 www.tribesigns.com...
  • Page 2 DESIGNED FOR LIFE DESIGNED FOR LIFE Contact Us We're here to help you. support@tribesigns.com 1-424-220-6888 Contact us anytime except 12:00 AM to 8:00 AM EST. Your satisfaction is our top priority. If you encounter any issues with this product, such as missing or damaged parts, we're here to help.
  • Page 3 DESIGNED FOR LIFE We recommend using hand tools for assembly. AVOID SCRATCHES In order to avoid scratching, this furniture should be assembled on a soft surface, such as a rug. P-02...
  • Page 4 DESIGNED FOR LIFE DESIGNED FOR LIFE Caution Make sure all parts are included. Most board parts are labeled or stamped on the raw edge. Contact us for a free replacement if you encounter any damaged or missing parts. P-03...
  • Page 5 DESIGNED FOR LIFE Parts List 4 pcs 2 pcs 2 pcs 1 pc 1 pc 2 pcs 1 pc 1 pc 1 pc 2 pcs 2 pcs 2 pcs 3 pcs 2 pcs 1 pc 1 pc 1 pc 2 pcs 1 pc 1 pc 1 pc...
  • Page 6 DESIGNED FOR LIFE Parts List 1 pc 1 pc 1 pc 1 pc 1 pc 1 pc 2 pcs 1 pc 1 pc 1 pc 1 pc 1 pc P-05...
  • Page 7 DESIGNED FOR LIFE Hardware List Ø8x30mm Ø10x40mm Ø10x30mm M8x75mm M6X35MM 102 pcs 7 pcs 8 pcs 1 pc 4 pcs 4 pcs Screwdriver Ø7x38mm 4 pcs 4 pcs 1 pc 8 pcs 6 pcs 1 pc 14X12X10MM Ø3.5x14mm Ø3.5x25mm Ø3.5x35mm Ø4x22mm 38 pcs 4 pcs...
  • Page 8 DESIGNED FOR LIFE Installation of Cams and Pins Read each step carefully before starting. Each step of instruction should be performed in the correct order. If these steps are not followed in sequence, assembly difficulties may occur. No gap Step1 Step2 Step3 Step4...
  • Page 9 DESIGNED FOR LIFE M6x35mm 16 pcs 4 pcs Step 1 Step 2 Step 3 Step 4 Ø15x12mm 16 pcs P-08...
  • Page 10 DESIGNED FOR LIFE M6x35mm 8 pcs Step 1 Step 2 Step 3 Step 4 Ø15x12mm 8 pcs Step 1 Step 2 Step 3 P-09...
  • Page 11 DESIGNED FOR LIFE Ø8x30mm M6x35mm Step 1 Step 2 Step 3 Step 4 6 pcs 2 pcs Ø3.5x14mm M6x35mm 8 pcs 12 pcs 3 sets Step 1 Step 2 Step 3 Step 4 P-10...
  • Page 12 DESIGNED FOR LIFE Step 1 Step 2 Step 3 Ø15x12mm 4 pcs P-11...
  • Page 13 DESIGNED FOR LIFE Ø15x12mm 4 pcs Step 1 Step 2 Step 3 M6x35mm Ø8x30mm 6 pcs 2 pcs P-12...
  • Page 14 DESIGNED FOR LIFE Ø15x12mm 6 pcs Step 1 Step 2 Step 3 Ø15x12mm 6 pcs Step 1 Step 2 Step 3 P-13...
  • Page 15 DESIGNED FOR LIFE M6x35mm 16 pcs Ø3.5x14mm 1 sets 4 pcs P-14...
  • Page 16 DESIGNED FOR LIFE Ø3.5x14mm 1 sets 4 pcs Ø3.5x14mm 2 sets 8 pcs P-15...
  • Page 17 DESIGNED FOR LIFE Ø15x12mm 8 pcs P-16...
  • Page 18 DESIGNED FOR LIFE Ø4x22mm Ø3.5x35mm 2 pcs 2 pcs 8 pcs Ø15x12mm 4 pcs P-17...
  • Page 19 DESIGNED FOR LIFE P-18...
  • Page 20 DESIGNED FOR LIFE Ø4x22mm Ø3.5x35mm 1 pc 4 pcs 1 pc Ø15x12mm 4 pcs P-19...
  • Page 21 DESIGNED FOR LIFE Ø4x22mm Ø3.5x35mm 1 pc 4 pcs 1 pc P-20...
  • Page 22 DESIGNED FOR LIFE Ø10x40mm M8x75mm 2 pcs 4 pcs 8 pcs 1 pc 4 pcs 4 pcs 4 pcs Step 3 Step 2 Step 1 Step 5 Step 4 P-21...
  • Page 23 DESIGNED FOR LIFE M6x35mm 6 pcs Step 1 Step 2 Step 3 Step 4 M6x35mm 11 pcs P-22...
  • Page 24 DESIGNED FOR LIFE Step 1 Step 2 Step 3 Ø15x12mm 3 pcs Ø3.5x14mm 4 pcs 1 sets P-23...
  • Page 25 DESIGNED FOR LIFE Ø15x12mm 8 pcs Step 1 Step 2 Step 3 Ø7x38mm 8 pcs P-24...
  • Page 26 DESIGNED FOR LIFE Ø15x12mm Ø3.5x25mm 2 pcs 6 pcs Step 1 Step 2 Step 3 M6x35mm 6 pcs Step 1 Step 2 Step 3 Step 4 P-25...
  • Page 27 DESIGNED FOR LIFE Ø15x12mm 6 pcs Step 1 Step 2 Step 3 Ø3.5x25mm 2 pcs P-26...
  • Page 28 DESIGNED FOR LIFE M6x35mm 8 pcs Ø15x12mm 8 pcs Step 1 Step 2 Step 3 P-27...
  • Page 29 DESIGNED FOR LIFE Ø8x30mm Ø10x30mm M6x35mm 11 pcs 3 pcs 1 pc Step 1 Step 2 Step 3 Step 4 Ø8x30mm Ø10x30mm Ø15x12mm 11 pcs Step 1 Step 2 Step 3 P-28...
  • Page 30 DESIGNED FOR LIFE Align the "S-2" with the "S-1" guideway and gently push it in to complete the assembly Ø3.5x14mm 6 pcs 6 pcs P-29...
  • Page 31 DESIGNED FOR LIFE Thank you for your support! Contact our customer service team 1-424-220-6888 support@tribesigns.com Contact us anytime except www.tribesigns.com 12:00 AMto 8:00 AMEST. Follow Tribesigns Instagram WhatsApp Facebook Pinterest Twitter YouTube TikTok...
