Smart Meter SMBP802-Ga-001 User Manual

Cellular blood pressure monitor

Advertisement

Quick Links

Manufactured for / Fabricado por:
Smart Meter LLC
6005 Benjamin Road, Suite A
Tampa, FL 33634 USA
version / versión: A/1
技术要求:
1、黏合不可露胶
2、保持印刷面板上的清洁
3、注意套印的准确性
4、表面处理不可爆开
5、须满足RoHS、Reach的环保要求
6、结构工艺以结构受控图为准
7、颜色参考:
产品型号
BB802-AC01-01-001
产品名称
血压计
比例
单位
对应结构图纸:-
材质:105g哑粉纸
1:1
尺寸:210*145mm(折后105*145 mm)
mm
印色:单黑
表面处理:-
版本:A/2
Cellular Blood Pressure Monitor
/2BF010642R
2BF007715R
共 1 张
第 1 张
SMBP802-Ga-001
2025-03-10
零件名称
2BF010642R-BB802-AC01-01-001-GB-08-说明书-A2
零件图号:BB802-AC01-01-001-GB-06
设计
李秋燕 2025-03-10
审核
陈文丽 2025-03-10
批准
李胜利 2025-03-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMBP802-Ga-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Smart Meter SMBP802-Ga-001

  • Page 1 Cellular Blood Pressure Monitor SMBP802-Ga-001 Manufactured for / Fabricado por: Smart Meter LLC 6005 Benjamin Road, Suite A Tampa, FL 33634 USA version / versión: A/1 技术要求: 1、黏合不可露胶 2、保持印刷面板上的清洁 3、注意套印的准确性 2025-03-10 4、表面处理不可爆开 5、须满足RoHS、Reach的环保要求 6、结构工艺以结构受控图为准 /2BF010642R 2BF007715R 7、颜色参考: 零件名称 产品型号 BB802-AC01-01-001 对应结构图纸:-...
  • Page 2 ENGLISH-TABLE OF CONTENTS INTRODUCTION 3|EN General Description Indications for Use Measurement Principle Safety Information Display and Symbols Get to Know your Device Contents/Product Includes BEFORE YOU START 10|EN Power Supply Options Installing and Replacing the Batteries MEASUREMENT 1 2|EN Applying the cuff Taking a Measurement HELPFUL INFORMATION 15|EN...
  • Page 3: General Description

    Thank you for choosing the iBloodPressure Classic blood pressure monitor. The symbols below might be in the user manual, labeling or other components. They are (SMBP802-Ga-001). It is equipped with the following key features. Please read this the requirement standards of use.
  • Page 4 INTRODUCTION INTRODUCTION Warning Precaution * This Blood Pressure Monitor is intended to be operated by adults, including medical staff and lay * DO NOT self-diagnose the measurement results and start treatment by yourself. The measu- persons. Adult patients may also be intended users or operators. rement results given by this device are not a diagnosis.
  • Page 5: Display And Symbols

    INTRODUCTION INTRODUCTION Display and Symbols SYMBOL EXPLANATION Systolic blood pressure reading Diastolic blood pressure reading Excessive body motion detection symbol Appears when talking, moving, or shaking of the arm with the cuff on is detected during a measurement. NOTE: The measured blood pressure reading may not be accurate when this symbol is displayed .
  • Page 6: Before You Start

    Contents/Product Includes • The display does not light up. Steps of replacing the batteries: 1 Cellular Blood Pressure Monitor (SMBP802-Ga-001) • Slide off the battery cover. 1 Cuff (Type BF applied part) Options for cuff sizes: • 16-36 cm (6 ¹ ⁄ - 14 ¹ ⁄ inch) upper arm cuff •...
  • Page 7 BEFORE YOU START MEASUREMENT Applying the cuff (Not made with natural rubber latex) Note : When you insert or replace batteries into the device, the symbols will be displayed on the LCD screen alternately. This indicates that the divice is searching and Only use a cuff that has been approved by the manufacturer for this device model.
  • Page 8: Taking A Measurement

    MEASUREMENT MEASUREMENT Taking a Measurement 2. After the measurement, the data transmission starts. The symbol will blink on the LCD. 1. After applying the cuff to your upper arm, press the button to turn on the device. It will automatically start the measurement process.
  • Page 9: Helpful Information

    HELPFUL INFORMATION HELPFUL INFORMATION Tips for Measurement Maintenance Measurements may be inaccurate if taken under the following circumstances. In order to get the best performance, please follow the instructions below. 1. Cleaning Process: Step 1: Before cleaning the monitor, make sure that the monitor is switched off and disconnected from the power adapter.
  • Page 10: About Blood Pressure

    ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE What are systolic pressure and diastolic pressure? CAUTION Only a physician can tell you your normal BP range. Please contact a physician if your When ventricles contract and pump blood out of the heart, the blood pressure reaches its measurement result falls out of range.
  • Page 11: Troubleshooting

    ABOUT BLOOD PRESSURE TROUBLE SHOOTING Why does my blood pressure fluctuate throughout PROBLEM DISPLAY CHECK THIS REMEDY the day? Batteries are drained. Replace with new batteries. No power Display will 1. Individual blood pressure varies multiple times everyday. It is also affected by the way Batteries are inserted Insert the batteries not light up...
  • Page 12: Specifications

    Pressure: 5℃-40℃ within ±3 mmHg (0.4 kPa) Accuracy Pulse value: ±5% Smart Meter guarantees its products free of defects in materials and workmanship in normal use for a period of TWO years from the date of retail purchase. This warranty Temperature: +5°C to +40°C...
  • Page 13: Emc Guidance

    Pulse value: ±5% Compliance Emissions test RF emissions Group 1 The Basis Safety of the Blood Pressure Monitor (SMBP802-Ga-001) is as following: CISPR 11 Deviation from normal operation that poses an unacceptable risk to the patient or RF emissions operator.
  • Page 14 EMC GUIDANCE EMC GUIDANCE Table 2 Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Guidance and manufacturer’s declaration – electromagnetic Immunity IEC 60601-1-2 Radiated RF Test Maximum Compliance Immunity Test Compliance level Band Distance 60601-1-2 IEC61000-4-3 Frequency Service Modulation Power level Test level...
  • Page 15: Fcc Statement

    SPECIFICATIONS FOR 4G FCC STATEMENT FCC ID: OU9LS802GAM2 Specifications for 4G This device complies with Part 15 of the FCC Rules. Operation is subject to the following Supporting Cat-M1: two conditions: (1) this device may not cause harmful interference, and (2) this device band:...
