  • Page 1 ATR6600 Handheld Raman Spectrometer USER MANUAL...

  • Page 2: Table Of Contents

    Content 1. OVERVIEW ............................. 2 2.Configuration List ..........................3 3.Hardware Interface ..........................4 3.1 Probe ............................4 3.2 Power button ..........................4 3.3 USB Port ............................. 5 3.4 Charge Port ..........................5 4. Operating guide ..........................6 4.1 Power on & Login........................6 4.2 Basic detect operation .........................

  • Page 3: Overview

    ATR6600-User Manual V1.1 1. OVERVIEW ATR6600 is a set of 1064nm handheld Raman analyzer that is excel at fluorescence resistance suit to high fluorescence materials detection. With compact size, lightweight (1150kg), and easy-to-held, it can be widely applied to industries of customs, public safety, lab, plant, warehouse, deck etc. It can fast detect drugs, precursor chemicals, explosives, gemstones, raw materials, and also fast identify additives, residues of pesticide &...

  • Page 4: Configuration List

    ATR6600-User Manual V1.1 2.Configuration List ITEM ATR6600 Power Adaptor USB Cable Sample Cell ATR6600 User Manual...

  • Page 5: Hardware Interface

    ATR6600-User Manual V1.1 3.Hardware Interface Front Camera Probe USB Port Power ON/OFF Charge Port Scan 3.1 Probe The user should aim the probe tube at the sample to be tested when measuring. For different samples, the distance between the probe tube and the object to be tested needs to be fine-tuned to ensure that the laser emitted by the probe can focus on the surface of the object to be tested, so as to keep the lens surface clean and prevent accidental damage.

  • Page 6: Usb Port

    3.3 USB Port Fig 3.3.1 USB port User can connect USB to export data or transfer document 3.4 Charge Port Fig 3.4.1 Charge port Users shall connect standard wire cord configured by Optosky via port marked in red rectangle.

  • Page 7: Operating Guide

    ATR6600-User Manual V1.1 ：Disassembly/modification of instruments is strictly prohibited without the permission of the company, which may lead to instrument damage or even threaten personal safety. 4. Operating guide 4.1 Power on & Login Press power button to wait login screen popup as shown in Fig4.1. Input user name and password, click login to access detect screen.

  • Page 8: Basic Detect Operation

    ATR6600-User Manual V1.1 4.2 Basic detect operation Setup Spectragram Display Recognize method History Detect Fig 4.1.1 Detect Main Screen [Setup]：Click icon , or right slide screen to open setup interface can set integration time and laser power etc. [Detect]：Click icon...
  • Page 9 ATR6600-User Manual V1.1 Fig 4.2.2 Setup Menu Click Configuration can set scan parameters Fig 4.2.3 Configuration Screen...
  • Page 10 ATR6600-User Manual V1.1 Fig 4.2.4 Scan Process Wait for scan to popup detect result ① ② ③ Fig 4.2.5 Detect Result ① ：Identify high-matched materials(It can display Max 3 materials, left-and-right slide can switch from one material to another.) ② ：Detect material name and category ③...
  • Page 11 ATR6600-User Manual V1.1 [Spectra]： Fig 4.2.6 Raman Spectra : How to read Raman spectra? Shift peak shift Raman Frequency (wavenumber) Confirm materials composition Raman polarization (Raman shift) Confirm crystal symmetry Raman peak width(FWHM) Confirm crystal quality Raman peak intensity(Integration time)

  • Page 12: Configuration

    ATR6600-User Manual V1.1 4.3 Configuration Fig 4.3.1 System Configuration Setup 1. Detect Modes： (1).Accurate Detect - select accurate mode to scan spectrum, it will scan dark background every time, then start laser to scan, scan result can deduct dark background.
  • Page 13 ATR6600-User Manual V1.1 Fig 4.3.2 Detect interface in the simple mode 6. Delay scan time: how long can wait for starting scan? 7. Detect result sound: Finish detect will produce a humming sound when click it. 8. Spectral library management: Click standard library, users add library, or total library.

  • Page 14: Library Management

    ATR6600-User Manual V1.1 4.4 Library Management Fig 4.4.1 Spectral library interface Access to Library Management interface can display current spectral data lists of the selected library. Click search can proceed key words search, click add data can self-built spectral library. Or click current material can review detailed description.
  • Page 15 ATR6600-User Manual V1.1 Fig 4.5.1 Add Material-Scan Interface Firstly Detect spectra, input spectra info into the system, finish Detect click Next. Fig 4.5.2 Add Material-Material Info Interface...

  • Page 16: Review Historical Records

    ATR6600-User Manual V1.1 4.6 Review Historical Records Fig 4.6.1 Historical Records Interface How to review historical records? Click the item can review the detailed detect records. Time Filter: Screen detect records in any time of period through time filter. Look up：Fast search any records detected through fast look up.
  • Page 17 ATR6600-User Manual V1.1 图 4.6.2 Historical Records- Material Interface Click export report can export pdf file. Export report path：storage/HandheldRaman/pdf Fig 4.6.3 Detect Report...
  • Page 18 ATR6600-User Manual V1.1 Click export data can export peak info file. Export data path：storage/HandheldRaman/txt Fig 4.6.4 Data interface...

  • Page 19: User Management

    ATR6600-User Manual V1.1 4.7 User Management Fig 4.7.1 User Management Interface User information can be added, deleted and revised. User permission classes: Super administrator Supervisor Operator User Management Revise configuration in the setup Detect Choose Standard Library Revise self-built spectral library...

  • Page 20: Suggest Detect Distance

    ATR6600-User Manual V1.1 Laser power 130-200mW, or if Raman signal is weak increase to 300-349mW Delay detect When detect explosive and inflammable materials, delay detect can be used and set laser power as low as possible. 4.8.2 Suggest detect distance （1）Usually package is transparent or semitransparent, and packing thickness shall...

  • Page 21: Technical Parameters

    ATR6600-User Manual V1.1 5. Technical Parameters ATR6500 System Operative System Android Excitation Wavelength 1064 ± 0.5nm Wavenumber Range 200-2800 cm-1 Resolution 12-16 cm-1 Touch Screen 5.5", 1920×1080, c Size 22.5"×11"×5" Weight <1.2Kg Interface WIFI, USB Type-C, Bluetooth, GSM Library Item...
