- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference RQ768N4GBE English...
- Page 2 Contents Thank you for choosing Hisense. We are sure you will find your new refrigerator a pleasure to use. However, before you use the appliance, we recommend that you carefully read the instructions, which provide details about installing and using the product.
- Page 3 Safety and warning information For your safety and correct usage before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with it operation and safety features.
- Page 4 Safety and warning information Safety for children and others who are vulnerable people According to IEC standard This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 5 Safety and warning information General safety WARNING This appliance is intended to be used in household and similar applications such as 1. staff kitchen areas in shops, offices and other working environments; 2. farm houses and by clients in hotels, motels and other residential type environments;...
- Page 6 Safety and warning information General safety WARNING Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING Do not damage the refrigerant circuit. WARNING Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 7 Safety and warning information Replacing the illuminating lamps WARNING The illumination lamps must not be replaced by the user! If the illumination lamps is damaged, contact the customer helpline for assistance. This warning is only for refrigerators that contain illumination lamps. Refrigerant The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance, a natural gas...
- Page 8 Safety and warning information Refrigerant WARNING Refrigerators contain refrigerant and gases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal. WARNING Risk of fire / flammable materials If the refrigerant circuit should be damaged:...
- Page 9 Safety and warning information Electrical safety 1. The power cord must not be lengthened. 2. Make sure that the power plug is not crushed or damaged. A crushed or damaged power plug may overheat and cause a fire. 3. Make sure that you can access the main plug of the appliance.
- Page 10 Safety and warning information Daily use Do not store flammable gas or liquids in the appliance, There is a risk of an explosion. Do not operate any electrical appliances in the appliance (e. g. electric ice cream makers, mixers etc.). When unplugging always pull the plug from the mains socket, do not pull on the cable.
- Page 11 Safety and warning information The appliances manufactures storage recommendations should be strictly adhered to. Refer to relevant instructions for storage. Do not place carbonated or fizzy drinks in the freezer compartment as it creates pressure on the container, which may cause it to explode, resulting in damage to the appliance.
- Page 12 Safety and warning information and lips. To avoid items falling and causing injury or damage to the appliance, do not overload the door racks or put too much food in the crisper drawers. Caution! Care and cleaning Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket.
- Page 13 Safety and warning information too close to a wall to avoid touching or catching warm parts (compressor, condenser) to prevent the risk of fire, follow the instructions relevant to installation. The appliance must not be locate close to radiators or cookers.
- Page 14 Installing your new appliance 908mm(case) Before using the appliance for the first time, you should be aware of the following tips. ≥3mm ≥3mm Ventilation of appliance 911mm(door) Door closing status for refrigerator in the build-in status In order to improve efficiency of the cooling system and save energy, it is necessary to maintain good ventilation around the...
- Page 15 Installing your new appliance Whenever you want to move the appliance, remember to turn the feet Note back up, so that the appliance can roll freely. Reinstall the appliance This appliance performs well in the when relocating. climate class from SN to ST. It may not work properly if being left at a temperature above or below the indicated range for a long period.
- Page 16 Description of the appliance View of the appliance 01. Rotary separator 07. Vacuum fresh drawer 13. Temperature sensing probe 02. Fridge door rack 08. Freezer zone LED light 14. Humidity control drawer 03. HI-NANO Progress 09. Freezer upper drawer 15. Convertible compartment LED light 04.
- Page 17 Display controls Use your appliance according to the following control regulations, your appliance has the corresponding functions and models as the control panels showed in the pictures below. When the appliance is powered on for the first time, the backlighting of the icons on display panel starts working.
- Page 18 Display controls Then the Keys on the Control Panel can All the icons will go off on the be operation. condition of all the keys Press and hold “ ” for 3 seconds or untouched and all the doors no key operation for 20 seconds to lock closed for one minute.
- Page 19 Display controls After that, touch the key continuously, Note the temperature will be set according to the following sequence: When setting the temperature of 8°C→7°C→6°C→5°C→4°C→3°C→2°C the convertible compartment, if the key is not operated for about Note 10 seconds, the temperature display will stop flashing, When setting the temperature of indicating that the setting is...
- Page 20 Display controls Note Note When setting the temperature of Super Cool will automatically turn the freezer compartment, if the off after a period of time, and the key is not operated for about 10 refrigerator will revert to its seconds, the temperature display previous temperature setting.
- Page 21 Display controls “Vacuum Mode” “Holiday” If leaving the appliance for a long Press “ ” , you can turn on or off the period of time, you can switch the vacuum function. appliance over to the holiday mode. When the Vacuum Mode turn on, the Icon “...
- Page 22 Using your appliance This section tells you how to use most The figure shows the position of the door of the useful features. We recommend shaft adjusted by the C-shaped adjusting that you read through them carefully spcaer. before using the appliance. Install the 1.
- Page 23 Using your appliance Humidity Control Drawer opened, and the refrigerator is There are three operating modes for not working properly, the the Humidity Control Drawer for you humidity in the Humidity Control to choose from. Drawer cannot meet the When the control panel is unlocked, requirements.
- Page 24 Using your appliance Vacuum Fresh Drawer Steps for using the vacuum fresh drawer There are three operating modes for the Vacuum Fresh Drawer for you to Step1, Initial state. choose from. Step2, Raise the handle control lever. When the control panel is unlocked, Step3, After the air enters and the press “...
- Page 25 Using your appliance Disassembly of the fresh pantry 1. Move the fresh pantry cover plate to the upper shelf adjustment position. 2. Pull the fresh pantry to its Disassembly and installation of maximum stroke. the fridge shelf part 3. Lift the front of the fresh pantry up to disengage the mounting holes on Lift the rear end of the shelf upwards.
- Page 26 Using your appliance There is a rotary separator on the 3. Using your freezer compartment left-hand side refrigerator The freezer compartment is suitable compartment door. for storage of foods required to be When closing the left-hand door, the frozen, such as meat, fish, ice cream rotary separator folds behind the and other perishable items.
- Page 27 Cleaning and care For hygienic reasons the appliance Warning (including exterior and interior accessories) should be cleaned Do not use sharp objects as they regularly (at least every two months). are likely to scratch the surface. Do not use Thinner, Car detergent Warning Clorox, ethereal oil, abrasive cleansers or organic solvent such...
- Page 28 Helpful hints and tips Energy saving tips Hints for refrigeration We recommend that you follow the Meat (All Types) Wrap in polythene tips to save energy. food: wrap and place on the glass Try to avoid keeping the door open shelf above the vegetable drawer.
- Page 29 Helpful hints and tips Switching off your appliance It is recommended to label and date If the appliance needs to be each frozen package in order to switched off for an extended period, keep track of the storage time. the following steps should be taken Hints for fresh food refrigeration to prevent mould on the appliance.
- Page 30 Troubleshooting Problem Possible cause & Solution The ambient temperature is too low. Try setting the chamber temperature to a colder level to solve this Appliance is not problem. working correctly It is normal that the refrigerator is not operating during the automatic defrost cycle, or for a short time after the appliance is switched on to protect the compressor.
- Page 31 Troubleshooting Problem Possible cause & Solution Check that the air outlets are not blocked by food and ensure food is placed within the appliance to allow A layer of frost sufficient ventilation. occurs in the Ensure the door can be fully closed . To remove the frost, compartment please refer to the cleaning and care chapter.
- Page 32 Disposal of the appliance It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1.
- Page 33 Disposal of the appliance To avoid contamination of food, please respect the fllwing instructions Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. Clean regularly surfaces that can come in contact with food and accessible drainag esystems.
- Page 34 Disposal of the appliance Order Compartments Target storage Appropriate food type temp.[°C] Seafood (fish, shrimp, shellfish), freshwater aquatic products and meat products (recommended for 2 **-Freezer ≤-12 months, the longer the storage time, the worse the taste and nutrition), are not suitable for frozen fresh food.
- Page 35 Food needs to be packed in bags before putting into the refrigerator, and liquids need to be packed in bottles or capped containers to avoid the problems because that the product design structure is not easy to clean. Hisense Service Help Line : 0191 387 0804...
- Page 36 Hisense UK Ltd Ground floor Munroe Court White Rose Office Park Millshaw Park Lane Leeds LS11 0EA...
