105g 有光铜版纸
骑马钉(
风琴折 + 对折 页面顺序
16P 页面顺序
9
10
11
12
13
14
1
2
3
5
6
7
1.品牌互转
更
改
记
录
T0523.V01
2023.5.17
版本号
日期
)
20P 以上
用骑马钉
封面
封底
4
8
1.内容调整，参考TDLI20035说明书
2.添加货号TDLI20051xy
LX
T0723.V02
设计师
版本号
105*143mm
Pantone485C
Black（三色印刷）
20P 页面顺序
11
15
1
6
LX
2023.7.14
日期
设计师
12
13
14
封面
封底
16
17
18
2
3
4
5
7
8
9
10
1.公司名地址更新
T0723.V03
2023.7.26
版本号
日期
LX
设计师
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Total TDLI200528 Series
Summary of Contents for Total TDLI200528 Series
- Page 1 105g 有光铜版纸 105*143mm Pantone485C Black（三色印刷） 骑马钉( 20P 以上 用骑马钉 风琴折 + 对折 页面顺序 16P 页面顺序 20P 页面顺序 封面 封面 封底 封底 1.品牌互转 1.内容调整，参考TDLI20035说明书 1.公司名地址更新 2.添加货号TDLI20051xy 更 改 记 录 T0523.V01 2023.5.17 T0723.V02 2023.7.14 T0723.V03 2023.7.26 版本号 日期 设计师 版本号 日期 设计师...
-
Page 2: Product Manual
PRODUCT MANUAL LITHIUM-ION CORDLESS DRILL TDLI200528 UTDLI200528 TDLI20051 UTDLI20051 TDLI200528xy UTDLI200528xy TDLI20051xy UTDLI20051xy x(blank,1,2,3,4,5,6,7,8,9,E,S,A,M) y(blank,-1,-2,-3,-4,-5,-6,-7,-8,-9,E,S,A,M) -
Page 3: General Power Tool Safety Warnings
| English Original Instructions GENERAL POWER TOOL SAFETY WARNINGS ⚠ WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. - Page 4 | English 3) Personal safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
- Page 5 | English pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 6 | English Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 130 °C may cause explosion.
- Page 7 | English BATTERY TOOL SAFETY WARNINGS Save these instructions. ⚠ CAUTION Only use genuine original batteries. Use of non-genuine batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury, and damage. It will also void the warranty for the tool and charged and dark areas invite accidents.
- Page 8 | English dirty. Secondary cells and batteries need to be charged before use. Always use the correct charger and refer to the manufacturer's instructions or equipment manual for proper charging instructions. Do not leave a battery on prolonged charge when not in use. After extended periods of storage, it may be necessary to charge and discharge the cells or batteries times to obtain maximum performance.
- Page 9 | English Do not expose battery cartridge to water or rain. A battery short can cause a large current flow, overheating, possible burns and even a breakdown. Do not store the tool and battery cartridge in locations where the temperature may reach or exceed 50°C (122°F). Do not incinerate the battery cartridge even if it is severely damaged or is completely worn out.
- Page 10 | English that its activities comply with the applicable regulations. Protecting the environment Separate collection. This product must not be disposed of with normal household waste. Should you find one day that your product needs replacement, or if it is of no further use to you, do not dispose of it with household waste.
- Page 11 | English THE SYMBOLS IN INSTRUCTION MANUAL Double insulated for additional protection Read the instruction manual before using. CE conformity. Safety alert. Please only use the accessories supported by the manufacturer. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
-
Page 12: Additional Safety Warning
| English ADDITIONAL SAFETY WARNING Drill safety warnings Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring. Cutting accessory contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock. -
Page 13: Specifications
| English SPECIFICATIONS 1. Adjusting torque ring 5. Speed change lever 2. Chuck 6. Motor 3. Lamp 7. Reversing switch lever 4. Switch Symbols The followings show the symbols used for tool. volts direct current .../min revolutions or reciprocation per minute r/min... -
Page 14: Technical Specifications
| English Technical specifications UTDLI20051, UTDLI20051xy TDLI200528, TDLI200528xy, UTDLI200528, TDLI20051, TDLI20051xy UTDLI200528xy x (blank, 1, 2, 3, 4, 5, 6, 7, 8, 9, E, S, Model No. x (blank, 1, 2, 3, 4, 5, 6, 7, 8, A, M) 9, E, S, A, M) y (blank, -1, -2, -3, -4, -5, -6, -7, -8, -9, y (blank, -1, -2, -3, -4, -5, -6, - E, S, A, M) - Page 15 | English ⚠ WARNING! Only use original battery pack and battery charger as below for this power tool: x (blank, 1, 2, 3, 4, 5, 6, 7, 8, 9, E, S, A, M) y (blank, -1, -2, -3, -4, -5, -6, -7, -8, -9, E, S, A, M) Product Battery pack TFBLI2001...
- Page 16 | English OPERATION PICTURE...
- Page 17 | English OPERATION PICTURE...
-
Page 18: Function Description
| English FUNCTION DESCRIPTION ⚠ CAUTION Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool Electrical safety Installing or removing battery cartridge (see Figure A) Figure A: 1. Button 2. -
Page 19: Electric Brake
| English Indicator lamps Remaining capacity Lighted • >80% • 30% to 80% • <30% ⚠ NOTE Depending on the conditions of use and the ambient temperature, the indication may differ slightly from the actual capacity. Switch action:(see Figure C) Figure C: 1. - Page 20 | English ⚠ NOTE Use a dry cloth to wipe the dirt off the lens of the lamp. Be careful not to scratch the lens of lamp, or it may lower the illumination. Reversing switch action:(see Figure E) Figure E: 1. Reversing switch lever ⚠...
- Page 21 | English To change the speed, switch off the tool first. Select the "2" side for high speed or "1" for low speed but high torque. Be sure that the speed change lever is set to the correct position before operation. If the tool speed is coming down extremely during the operation with "2", slide the lever to the "1"...
-
Page 22: Drilling Operation
| English OPERATION ⚠ CAUTION Always insert the battery cartridge all the way until it locks in place. If you can see the red part on the upper side of the button, it is not locked completely. Insert it fully until the red part cannot be seen. If not, it may accidentally fall out of the tool, causing injury to you or someone around you. - Page 23 | English exceptions are iron and brass which should be drilled dry. ⚠ CAUTION Pressing excessively on the tool will not speed up the drilling. In fact, this excessive pressure will only serve to damage the tip of your drill bit, decrease the tool performance and shorten the service life of the tool.
- Page 24 | English MAINTENANCE&MALFUNCTIONS Possible malfunctions and methods of their eliminations Malfunction Probable causes Actions ● Switch failure ●The power cord or wiring is broken, Disconnect When the machine is turned power cord plug malfunction; machine from the on, the electric motor does ●...
- Page 25 TOTAL TOOLS WORLD MADE IN CHINA T0723.V03 NEWWAY TECHNOLOGY (SUZHOU) CO., LIMITED No. 20 Dagang Road, Fuqiao Town, Taicang City, China...
