Item# 1005 874 065
Item# 1005 874 063
Model # URA062001-LRS1
URA062001-LRSB
USE AND CARE GUIDE
10X10FT OFFSET UMBRELLA WITH LED LIGHT
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
trive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the URA062001-LRS1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Home Decorators Collection URA062001-LRS1

Summary of Contents for Home Decorators Collection URA062001-LRS1

  • Page 1 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU trive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Package Contents ..............4 Save These Instructions ............2 Assembly ..............5 Read All Instructions Before Use ..........2 Operation .......

  • Page 3: Warranty

    Warranty 2 YEAR FRAME AND 5 YEAR FABRIC WARRANTY WHAT IS COVERED We warrant to be free of manufacturing defects to the original purchas WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover is warranty.

  • Page 4: Package Contents

    Pre-Assembly PACKAGE CONTENTS Part Description Quantity Lower Bracket Upper Bracket Base Tube Crank Umbrella Shade Turn Plate Pedal Pedal Tube Side Base Middle Base Upper Base Cover Base Cover Solar Receiver...

  • Page 5: Assembly

    Assembly Pouring Sand and Water Into the Bases Open the side bases (I) and the middle bases (J) in the counterclockwise direction. Pour sand and water into the side bases (I) and the middle bases (J). Close the side bases (I) and the middle bases (J) in the clockwise direction. NOTE: Place the bases in the area where the umbrella is to be used.
  • Page 6 Assembly (continued) Pulling Out the Base Tube from the Umbrella Shade Place the umbrella shade (E) on a soft surface. Pull out the base tube (C) from the umbrella shade (E).
  • Page 7 Assembly Assembly (continued) Attaching the Base Tube to the Turn Plate Attach the pedal tube (H) to the turn plate (F) using M6x10 bolt (AA) and hex wrench S5 (GG). Attach the upper bracket (B) onto the lower bracket (A). Attach the turn plate (F) to the brackets (A&B) using M10x30 bolts (DD), M10 washers (EE) and hex wrench S8 (FF).
  • Page 8 Assembly (continued) Attaching the Middle Bases to the Brackets Attach the middle bases (J) onto the brackets (A&B).
  • Page 9 Assembly Assembly (continued) Attaching the Side Bases to the Brackets Attach the side bases (I) onto the brackets (A&B). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
  • Page 10 Assembly (continued) Inserting the Base Cover and the Upper Base Cover into the Base Tube Insert the base cover (L) into the base tube (C). Insert the upper base cover (K) into the base tube (C).
  • Page 11 Assembly (continued) Connecting the Pedal to the Pedal Tube Connect the pedal (G) to the pedal tube (H) using M6x10 bolt (AA) and hex wrench S5 (GG). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
  • Page 12 Assembly Assembly (continued) Attaching the Solar Receiver Insert the plug into the plug hole of the solar receiver (M). Attach the solar receiver (M) to the umbrella shade (E) by turning the solar receiver (M) clockwise until fully tightened. NOTE: Please leave the solar receiver (M) out in a sunny area to charge before the first time turning on the LED lights.
  • Page 13 Assembly (continued) Inserting the Umbrella Shade into the Base Tube Insert the umbrella shade (E) into the base tube (C) using M6x20 bolt (BB) and hex wrench S5 (GG). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...

  • Page 14: Operation

    Operation Attaching the Crank to the Umbrella Shade and Raising the Umbrella Shake the canopy to separate the umbrella ribs before opening the umbrella. Attach the crank (D) to the umbrella shade (E). Loosen the knob on the umbrella shade (E) by turning it in the counterclockwise direction. Hold the umbrella handle and push the umbrella shade upward to the desired position.
  • Page 15 Operation (continued) Opening the Umbrella Once the umbrella is at the desired position, fully tighten the knob on the umbrella shade by turning it in the clockwise direction. Slowly turn the crank (D) clockwise to open the umbrella. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
  • Page 16 Operation (continued) Adjusting the umbrella If need to adjust the umbrella shade position, loose the knob on the umbrella shade (E) by turning it in the counterclockwise direction. Hold the umbrella handle and push the umbrella shade to the desired position. ①...
  • Page 17 Operation (continued) Turn the LED Light On and Off Press the ON/OFF switch to turn the LED light on and off. ON-OFF HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
  • Page 18 Operation (continued) Rotating the Umbrella Hold the pedal (G) with one foot and rotate the umbrella pole (The umbrella can rotate up to 360 degrees).
  • Page 19 Operation (continued) Closing the Umbrella Loosen the knob on the umbrella shade (E) by turning it in the counterclockwise direction. Hold the umbrella handle and push the umbrella shade downward. Turn the crank counterclockwise to close the umbrella. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance...
  • Page 20 Operation (continued) Tying the Umbrella to the Umbrella Pole Tie the umbrella to the umbrella pole with the Velcro belt when not in use, as shown below.
  • Page 21 Operation (continued) Attaching and Detaching the Crank Attach the crank (D) without using the tap as shown in figure 1. To detach the crank (D), just take the crank out. Attach the crank (D) to the handle as shown in figure 2. Attach the crank (D) by aligning the tap with the hole on the crank (D) until it snaps into place.

  • Page 22: Care And Cleaning

    Care and Cleaning For best results, clean the umbrella with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrasive materials, bleach, or solvents. Store the umbrella in a dry sheltered place when not in use.
  • Page 23 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
