Summary of Contents for Taramps THS 4004
- Page 1 Instruction manual 4 x 100W RMS CLASS D The installation of this product must be made by a qualified professional.
- Page 2 In case of doubt even after reading this manual, please contact our technical support at the number +55 18 3266 4050 or our website www.taramps.com.br. Presentation The TARAMPS THS 4004 is a Receiver developed with high technology to integrate different environments. Compact and powerful it can be used in several applications providing quality sound.
-
Page 3: Important Recommendations
Important recommendations - The THS 4004 must be installed in a rm and ventilated place, away from heat and humidity places. Avoid locations with direct sunlight. - Do not block the ventilation holes on the top and rear. - Avoid falls and impacts. - Page 4 Knowing your equipment Front Panel 1 - MICRO SD: Micro SD memory card input. (The card must be positioned as the image shows, with the terminals facing up). 2 - USB: Flash Drive input. 3 - Aux. (P2 Connector): Receives audio signal from the P2 output of your phone, tablet, MP3, computer, among others.
- Page 5 Front Panel (sequence) 09 10 13 14 9 - OPTICAL: LED indicating the presence of an optical signal. Indicates that the current auxiliary input is optical. 10 - ATT: LED audio attenuation indicator. When identifying an audio signal from the microphone input or emitting the ding-dong signal (GONGO), the equipment attenuates the output signal, allowing higher evidence of the microphone.
- Page 6 1 - POWER CABLE: Plugged it into a powered outlet. This product operates from 127V AC to220V 2 - SPEAKER OUT: Power outputs for connecting speakers. The THS 4004 has 4 individual power outputs. Follow the indicated polarity and the recommended minimum impedance of 2 Ohms.
-
Page 7: Protection System
If the protection system or system meets frequently, review the settings and installation of your system. Remote control functions The THS 4004 has a compact remote control, so you can remotely control the device with practicality. ON / OFF: Press this key to turn the player on or off. - Page 8 Bluetooth When selecting the Bluetooth function (identi ed with “bt” on the display), the THS 4004 waits for a Bluetooth connection. Search for the device called “TARAMPS” using your phone, tablet, PC or other and match it. - To connect to a new device, disconnect the current one and make the new Bluetooth pairing.
- Page 9 TARAMPS long range remote control which allows you to control your sound over wide distances and without the need to point the control at the device. The THS 4004 does not lose the functionality of the USB port, as the connect control allows a Flash Drive to be plugged into its USB port.
-
Page 10: Examples Of Connections
12 months from the date of purchase. In case of defect during the warranty period, TARAMPS responsibility is limited to the repairing or replacement of the device of its own making. -
Page 11: Technical Features
The values mentioned are typical and may change due to the tolerance of components or the manufacturing process. For more information or questions visit our website or contact TARAMPS support. Taramps reserves the right to modify the contents of this manual without prior notice and not to apply the modi cations to units previously produced. - Page 12 Manufactured by: TARAMPS ELECTRONICS LTDA TAX ID: 11.273.485/0001-03 Rodovia/Highway: Julio Budisk, SN, KM 30 Alfredo Marcondes - SP Made in Brazil...
