- Page 1 User Manual Refrigerator-Freezer HRF510BHC HRF510BW HRF510BS HRF510FHC HRF510FHS HRF510FS...
-
Page 2: Table Of Contents
Contents 4 Intended use 5 Safety information Before first use Installation Daily use 9 Product description 13 Control panel 14 Use Adjust the temperature for fridge Adjust the temperature for freezer 15 Super-Cool function Super-Frz function 21 Equipment 23 Energy saving tips 24 Care and cleaning 27 Troubleshooting 31 Installation... - Page 3 Thank you Thank you for purchasing a Haier Product. Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
-
Page 4: Intended Use
Intended use Accessories Check the accessories and literature in accordance with this list: Egg tray Warranty User manual card Ice cube tray Door hinges Hinge Cover (Only (Only (Only HRF510B*/ HRF510B*/ HRF510B*/ HRF510F*) HRF510BH*) HRF510BH*) Intended use This appliance is intended to be used in household and similar applications such as –... -
Page 5: Safety Information
Safety information Before switching on the appliance for the first time read the following safety hints: WARNING! Before first use ▶ Make sure there is no transport damage. ▶ Remove all packaging and keep out of children´s reach. ▶ Wait at least two hours before installing the appliance in order to ensure the re- frigerant circuit is fully efficient. -
Page 6: Daily Use
Safety information WARNING! ▶ Use a separate earthed socket for the power supply which is easy accessible. The appliance must be earthed. Only for UK: The appliance’s power cable is fitted with 3-cord (grounding) plug that fits a standard 3-cord (grounded) socket. Never cut off or dismount the third pin (grounding). - Page 7 Safety information WARNING! ▶ Do not store or use inflammable, explosive or corrosive materials in the appli- ance or in the vicinity. ▶ Do not store medicines, bacteria or chemical agents in the appliance. This ap- pliance is a household appliance. It is not recommended to store materials that require strict temperatures.
-
Page 8: Refrigerant Gas Information
Safety information WARNING! ▶ Hold the plug, not the cable, when unplugging the appliance. ▶ Do not clean the appliance with hard brushes, wire brushes, detergent powder, petrol, amyl acetate, acetone and similar organic solutions, acid or alkaline solu- tions. Please clean with special refrigerator detergent to avoid damage. ▶... -
Page 9: Product Description
Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HRF510B*) 6-Upper freezer storage drawer 1-Control panel 7-Lower freezer storage drawer 2-Rating plate 8-Adjustable feet 3-Cabinet shelf 9-Adjustable door shelf 4-Fresh Storage bin cover 10-Full-width door shelf 5-Fresh Storage bin... - Page 10 Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HRF510BH*) 1-Control panel 9-Ice storage drawer 2-Rating plate 10-Lower freezer storage drawer 3-Cabinet shelf 11-Adjustable feet 4-Fresh Storage bin cover 12-Adjustable door shelf 5-Fresh Storage bin 13-Water tank...
- Page 11 Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HRF510F*) 1-Control panel 7-Upper freezer storage drawer 2-Rating plate 8-Lower freezer storage drawer 3-Cabinet shelf 9-Adjustable feet 4-Cabinet shelf 10-Adjustable door shelf 5-Humidity bin cover 11-Full-width door shelf...
- Page 12 Product description NOTICE Due to technical changes and different models, some of the illustrations in this manual may differ from model. (HRF510FH*) 1-Control panel 10-Lower freezer storage drawer 2-Rating plate 11-Adjustable feet 3-Cabinet shelf 12-Adjustable door shelf 4-Fresh Storage bin cover 13-Water tank 5-Fresh Storage bin 14-Fridge compartment light...
-
Page 13: Control Panel
Control panel Control panel Indicators: Buttons: A Super Cool function K1 Holiday selector B Temperature display K2 Fridge selector /Surper cool function Fridge/Freezer selector (Press 3 seconds), C Super Freeze function K3 Freezer selector /Surper freeze func- tion selector (Press 3 seconds), D Panel look function K4 Panel look selector E Holiday Function... -
Page 14: Use
Sensor keys The buttons on the control panel are sensor keys, which already respond when lightly touched with the finger. Switch on /off the appliance The appliance is in operation as soon as it is connected to the power supply. When the appliance is powered on for the first time, temperature indicators “B”... -
Page 15: Adjust The Temperature For Fridge
Adjust the temperature for fridge 1. Unlock the panel if it is locked. 2. Press the button “K2” (Fridge) to select the Fridge compartment. Indicator “B” is flashing. 3. Press the button “K2” to set the fridge temperature. The temperature reduce in sequences of 1°C, from a maximum of 9°C to a minimum of 1°C. -
Page 16: Super-Cool Function
Super cool function Switch on the Super cool function if larger quantity of food should be stored (forexample after the purchase). The Super cool function accelerates the cooling of fresh food and protects the goods already stored from undesirable warming. The factory setting temperature is + 1 °C. -
Page 17: Holiday Function
Holiday function This function sets the refrigerator temperature permanently to 17°C. This allows to keep the door of the empty refrig- erator closed without causing an odour or mold - during a long absence (e.g. during holiday). The freezer compartment is free for your setting. 1. - Page 18 1. Ensure that the water tank is properly inserted (see EQUIPMENT) 2. Rotate and lift the round lid (A) and fill the water tank up with fresh drinking water. 3. Fill water only up to the mark (2 L); as it could overflow when the door opens and closes.
- Page 19 Storing into the refrigerator compartment • Keep your fridge temperature below 5°C. • Hot food must be cooled to room temperature before storing in the appliance. • Foods stored in the refrigerator should be washed and dried before storing. • Food to be stored should be properly sealed to avoid odor or taste alterations.
- Page 20 WARNING! ▶ Acid, alkali and salt etc. could erode the internal surface of the freezer. ▶ Do not place the food with these substances (e.g. sea fish) directly on the inter- nal surface. Salt water in the freezer should be cleaned up immediately. ▶...
-
Page 21: Adjustable Shelf
Equipment NOTICE Due to different models, your product may not have all of the following features. Please refer to chapter Product Description.l. Multi-air-flow The refrigerator is equipped with a multi- air-flow system, with which cool air flows are located on every shelf level. This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer. - Page 22 Equipment Humidity Zone drawer In this compartment the humidity level is controlled automatically by the system and it is suitable to store fruits, vegetables, salads etc. Removable drawer To remove the drawer out of the fridge or freezer compartment, pull out to the maximum extent (1), lift and remove (2).
-
Page 23: Energy Saving Tips
Energy saving tips Energy saving tips ▶ Make sure the appliance is properly ventilated (see INSTALLATION). ▶ Do not install the appliance in direct sunlight or near the heat sources (eg. stoves, heaters). ▶ Avoid unnecessarily low temperature in the appliance. The energy consump- tion increases with the decreasing of the setting temperature in the appliance. - Page 24 In case some small part or component gets stuck inside of the fridge (bet- ween shelves or drawers), use small soft brush to release it. If you could not reach the part, please contact Haier service ▶ Rinse and dry with soft cloth.
- Page 25 Model Voltage Max Power HRF510BW HRF510BS HRF510FS HRF510BHC HRF510FHS HRF510FHC Non-use for a longer period if the appliance is not used for an extended period of time, and you will not use the Holiday-function for the refrigerator: Take out the food.
-
Page 26: Moving The Appliance
Care and cleaning Moving the appliance 1. Remove all food and unplug the appliance. 2. Secure shelves and other moveable parts in the fridge and the freezer with adhesive tape. 3. Do not tilt the refrigerator more than 45° to avoid damaging the refrigeration system. -
Page 27: Troubleshooting Table
Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! ▶ Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. - Page 28 Troubleshooting Problem Possible Cause Possible Solution The inside of the The inside of the refrigerator needs cleaning. Clean the inside of the refrigerator. refrigerator is Food with strong odour is stored in the dirty and/or with Wrap the food thoroughly. refrigerator.
- Page 29 Troubleshooting Problem Possible Cause Possible Solution The foods were not adequately packaged. Always pack the foods well. A door/drawer of the appliance is not tightly Close the door/drawer. closed. The door/drawer has been opened too Do not open the door/drawer too Strong ice and frequently or for too long.
-
Page 30: Power Interruption
After the recovery of power, the appliance continues with the settings that were set before the power failure. To contact the technical assistance, visit our website: https://corporate.haier-eu- rope.com/en/ Under the section “website”, choose the brand of your product and your country. -
Page 31: Environmental Conditions
Space requirement Required space when door is opened. Appliance width in mm Appliance Didth in mm Model HRF510BW HRF510BS 1249 1439 HRF510BHC Appliance width in mm Appliance Didth in mm Model HRF510FS HRF510FHS 1020 1250 1039 HRF510FHC... - Page 32 Installation Environmental conditions This appliance should be installed in a room 50 mm that is dry and well ventilated. To provide ade- quate ventilation,make sure the refrigerator is at least 30mm clear on all sides from kitchen cabinetry(If HRF510B*,HRF510BH*,at least 50mm), and 50mm from the back wall.
-
Page 33: Electrical Connection
Installation Aigning the appliance The appliance should be placed on a flat and solid surface. 1. Tilt the refrigerator slightly back- wards. 2. Set the feet to the desired level. Make sure the distance to the wall on the hinge side is at least 100 mm for the door to open properly. -
Page 34: Door Reversibility
Installation Door Reversibility Before connecting the appliance to the power supply, you should check whether the door swing must be changed from right (as delivered) to left, if this is required by the installation location and the usability. WARNING! ▶ The appliance is heavy. You need two persons to carry out the door reversibility. ▶... - Page 35 Installation 15..Rotate the middle hinge 180 ° and install it on the left end of the middle beam . 16. Remove the hinges and corners at the bottom of the refrigerator, and install the corners on the right side of the bottom of the refrigerator.
-
Page 36: Technical Data
Technical data Product parameters according to regulation Based on standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located Trademark Haier Model No. HRF510B* HRF510BH* Category of the model... - Page 37 Technical data Trademark Haier Model No. HRF510F* HRF510FH* Category of the model Refrigerator-freezer Voltage/frequency 220V-240V~/50Hz Energy Star 5tar Frost-free system Pruduct group Total storge volume(L) Fresh food compartment Volume(L) Freezer compartment Volume(L) Climate class Redrigerant R600a 70g Insulation blowing gas...
- Page 38 Q.C.PASSED CERTIFICATE OF QUALITY DESIGNATION: CHECKER No: REFRIGERATOR 2025 Version A 0000000000...
Need help?
Do you have a question about the HRF510BHC and is the answer not in the manual?
Questions and answers
Will the shelves of my old Haier model hrf520bhc haier 517litre fridge fit into the newer model HRF510BHC. Thank you.
