Hartman Aries 69807096 Assembly Instructions

90cm square adjustable table

Advertisement

Quick Links

Assembly Instructions
Aries 90cm Square Adjustable Table
PLEASE RETAIN THIS DOCUMENT ALONG WITH YOUR
Congratulations on your recent purchase of your beautiful Hartman furniture. We hope it
brings you bountiful special moments with friends and family for many years to come.
Please follow these simple steps to build your furniture. We also have a very useful video
available online to assist with the assembly, please visit www.hartmanuk.com
TOP TIPS
Please read these instructions carefully before assembly, for further assistance
please view our assembly video online for an easy step by step demonstration
Aluminum is a soft metal and over tightening may strip the thread or break the part,
please loosely assembly your furniture before tightening to secure.
Please do not use power tools, please use the allen key provided in the bolt pack
Please allow 1 hour for assembly
This furniture can be assembled with 2 persons; however, you may need someone
to assist you when turning the furniture over into position.
(69807096&69808096)
