- Page 1 OPERATING INSTRUCTIONS FLEXALINE PRE Models – 60US / 125US / 285US / 380US / 490US LRE Models – 60US / 125US / 285US / 380US / 490US LFE Models – 60US / 125US / 285US / 380US / 490US...
- Page 2 OPERATING INSTRUCTIONS...
- Page 3 Certificate of Quality Checker: OPERATING INSTRUCTIONS...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Symbols Abbriviations SAFETY Intended use Personal safety HANDLING & TRANSPORTATION Moving the unit Packaging Unpacking Inactivity for extended period Diposal INSTALLATION Preparing the appliance Refrigerant Location Electrical connection Getting started PRODUCT DESCRIBTION Cabinet overview LFE Cabinet overview LRE Cabinet overview PRE Cabinet details Cabinet description... - Page 5 Adjust the set temperature Calibration of display temperature Export data to USB flash Erasing of recorded data LED lightning Rating plate Code description MAINTENANCE General maintenance Cleaning Long term storing Defrosting Service Spare parts Warranty WIRING DIAGRAM LFE – Laboratory freezer LRE –...
-
Page 6: Introduction
Please take a few minutes to read and become familiar with the advantages of your unit. To This unit contains flammable refrigerants. meet the high-quality demands required by the medical and pharmaceutical industry, all FLEXALINE units that leave Arctiko are carefully Grounding checked tested ensure high performance and quality. -
Page 7: Safety
SAFETY SAFETY Arctiko is obligated as a supplier to ensure the users PERSONAL SAFETY safety when operating one of our units. To prevent When operating FLEXALINE Refrigerator or Freezer, personal and material injury or damage, please you are exposed to a variation of possible dangerous follow the instructions in this manual. - Page 8 SAFETY When removing the power plug from the outlet, pull on the plug, not the cord. Pulling the power cord may result in electric shock or fire by short circuit. Follow procedures If the unit is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
-
Page 9: Handling & Transportation
If • Compressor and compressor oil damage is observed, report to the shipping • Battery company and your local Arctiko distributor. • Electronics 2. Remove all packaging material, plastic and straps. All packing materials are entirely WARNING recyclable. -
Page 10: Installation
INSTALLATION INSTALLATION PREPARING THE UNIT • Warning flammable material: Do not damage the refrigerant circuit. • Unpack the unit: Remove all packaging • Warning flammable material: To reduce materials, protective film, plastic bags and flammability hazards, the installation of this straps from all surfaces. -
Page 11: Location
INSTALLATION • Main power plug: The power supply flex exits LOCATION the unit at the bottom lefthand side (as Place the unit in a location that complies with viewed from the back). For ease of access, the the following conditions in order to achieve flex should be retrieved prior to positioning optimal operating results: the Medical Refrigerator in its final location. -
Page 12: Electrical Connection
INSTALLATION ELECTRICAL CONNECTION of cooling will be on at the same time). This temperature is the actual temperature recorded In order to ensure an economical and reliable by the probes inside the unit and as the unit installation that complies with the limits of cools to the set point (factory set at 39°F for temperature and voltage drop, it is necessary to fridge;... -
Page 13: Getting Started
INSTALLATION GETTING STARTED During the initial startup and continuous usage of the unit, the following procedures shall be followed: 1. Place the unit on a solid levelled floor. Make sure the room is ventilated, dry and the ambient temperature is between 16°C & 32°C. -
Page 14: Product Describtion
PRODUCT DESCRIPTION PRODUCT DESCRIPTION CABINET OVERVIEW LFE - Laboratory Freezer OPERATING INSTRUCTIONS... -
Page 15: Cabinet Overview Lre
PRODUCT DESCRIPTION CABINET OVERVIEW LRE - Laboratory Refrigerator OPERATING INSTRUCTIONS... -
Page 16: Cabinet Overview Pre
PRODUCT DESCRIPTION CABINET OVERVIEW PRE - Pharmaceutical Refrigerator OPERATING INSTRUCTIONS... -
Page 17: Cabinet Details
PRODUCT DESCRIPTION CABINET DETAILS CABINET DESCRIPTION AREA DESCRIPTION Front Panel Access to bottom condenser. 60L, 125L & 285 model equipped with levelling feet, Levelling feet / roller 380L & 490L model equipped with rollers. Compressor compartment The compressor compartment is located in the bottom of the unit. Shelfs The units are equipped with adjustable shelfs. -
Page 18: Probe And Access Ports
Insert the probe into the cabinet and seal the access port with the back cover. The Arctiko FLEXALINE range also comes with our single compressor technology. In contrast to Always seal the holes with putty on both sides the normal cascade system, these appliances of the hole. -
Page 19: Display / Controller
PRODUCT DESCRIPTION DISPLAY / CONTROLLER Easy to use control panel with 4-key resistive keybord. You can access a variation of settings, in order to adjust your unit for your exact needs. CONTROLLER OVERVIEW DESCRIPTION Lights constant when compressor is working, Compressor indicator Flashes when compressor start is delayed. -
Page 20: Power Failure
PRODUCT DESCRIPTION POWER FAILURE Caution The unit needs power to operate the cooling The factory setting for high temperature system. In case of power loss, the controller will alarm activation is -15°C (5°F) for freezers, go into power failure mode, and the display will and 9°C (48°F) for refrigerators. -
Page 21: Adjust The Set Temperature
PRODUCT DESCRIPTION ADJUST THE SET TEMPERATURE 4. The successful download will be confirmed by long beep sound, and the display writes “OK”. 1. Keep long pressing SET key for more than 3 5. Unplug the USB flash drive. sec. Then the screen displays code The data can now be used with excel and a PC. -
Page 22: Rating Plate
PRODUCT DESCRIPTION RATING PLATE The rating plate is placed on the unit´s right side, upper left corner. Company logo Contact details Serial number Model & temp. range Compressor type Power 231250FZ12500 Hermetic cooling system Applicated standards cETLus mark Pressure Refrigerant type and charge Flammable refrigerant Weight in kg... -
Page 23: Maintenance
Frequent and correctly executed maintenance is CLEANING essential to ensure high performance and Perform the following instructions at least once a functionality of the unit. Arctiko recommends a month: thorough examination twice a year and cleaning at least once a month. -
Page 24: Long Term Storing
6. Leave the door slight open for final drying and to prevent odor. To not affect the service life, ARCTIKO SERVICE recommends to not leave the appliance unused Arctiko recommends that service is performed, for a longer period. -
Page 25: Wiring Diagram
WIRING DIAGRAM WIRING DIAGRAM LFE – Laboratory refrigerator 6A 20A Power NO COM 1 2 3 4 5 6 7 5 4 3 DESCRIPTION LED lightning Door switch for LED lightning Light driver AC to DC Main power supply 3 prong; 110V (grounded) Fuse Compressor cooling fan Refrigerant compressor... -
Page 26: Lre - Laboratory Refrigerator
WIRING DIAGRAM LRE – Laboratory refrigerator 6A 20A Power NO COM 1 2 3 4 5 6 7 5 4 3 DESCRIPTION LED lightning Door switch Light driver AC to DC Main power supply 3 prong; 110V 60Hz (grounded) Fuse Freeze guard thermal switch (2°C). -
Page 27: Pre - Pharmaceutical Refrogerator
WIRING DIAGRAM PRE – Pharmaceutical Refrigerator 6A 20A Power NO COM 1 2 3 4 5 6 7 5 4 3 DESCRIPTION LED lightning Door switch Light driver AC to DC Main power supply 3 prong; 110V 60Hz (grounded) Fuse Freeze guard thermal switch (2°C). -
Page 28: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Most malfunctions arise in wrong use of the unit and can often be solved on the spot. In order to resolve some of the most common malfunctions please see the following troubleshooting scheme: PROBLEM CAUSE ACTION The appliance is not The plug of the unit is not correctly Check the appliance is plugged in correctly working... -
Page 29: Notes
NOTES NOTES OPERATING INSTRUCTIONS... - Page 30 NOTES NOTES OPERATING INSTRUCTIONS...
- Page 31 NOTES NOTES OPERATING INSTRUCTIONS...
- Page 32 ARCTIKO US Inc. | 1400 Donelson Pike, Ste B5 | Nashville, TN 37217 | USA +1 615 988 7000 | www.arctiko.com | sales@arctiko.com Follow us on: We reserve the right to change specifications without notice. Subject to confirmation, availability and errors.
