  • Page 1 OPERATING INSTRUCTIONS PR/LR 170-310-390 & LF 140-340...

  • Page 2: Table Of Contents

    INDEX ............PAGE Location and building in .

  • Page 3: Location And Building In

    Location and building in The cabinet should be placed in a room which is dry and sufficiently ventilated. To operate efficiently it should not be positioned in direct sunlight or near warm appliances. Please note that optimal cabinet performance is obtained at an ambient temperature between +16°C and +32°C. In environments with both high temperature and high air humidity, the appliance is approved in climate class 4+.

  • Page 4: Solid/Glass Door

    If necessary, please contact your local distributor or Arctiko for information on wiring location. Cable entries through the cabinet wall should be equipped with a lead-through tube and kit. Such kits are available through local distributors.

  • Page 5: Important

    Important! Applies to cabinets with glass door and/or drawers: Anti-topple brackets must be installed to avoid the cabinet toppling over when opening the door. The brackets which are delivered with the cabinet must be fastened to the wall behind the cabinet, as shown in the drawings.

  • Page 6: Connection To Electricity

    Connection to electricity The cabinet is intended for connection to alternating current. The connection voltage (V) and frequency (Hz) are shown on the name plate in the cabinet . Power connection is made by a three pin plug to a wall socket. Any requirement for earthing from the local power supply must be met.

  • Page 7: Starting Up

    Starting up (PC-Board MPC 46) Code/parameter setting Temperature s etting Display Defrosting Keylock Start/s top Plug in the cabinet To start, press the START/STOP key. When starting up the display will first show the software version of the cabinet followed by the program variant.

  • Page 8: Setting Th Temperature

    Setting the temperature emperature adjustments are done by holding the button and pressing either Confirm the settings by letting go of the buttons. Lighting inside the cabinet - Only applicable to cabinets with glass doors - The settings for the lighting inside the cabinet can be turned off by pressing and holding for 3 seconds.

  • Page 9: Alarms

    Alarms Door alarm The upper alarm limits, (LHL) is or has been activated Alarm codes The lower alarm limits, (LLL) alarm is or has been activated The low-temperature protection alarm is or has been activated Cancelling an acoustic alarm Cancelling a door alarm: [A1] flashes in the display. Press to cancel.

  • Page 10: Defrosting

    Defrosting Refrigerator Defrosting is automatically performed 4 times every 24 hours, by circulating the air inside the cabinet during compressor standstill periods. The defrost LED lights to indicate the defrosting cycle is running. Freezer Defrosting is automatically performed 4 times every 24 hours, by a heating element mounted at the evaporator.

  • Page 11: Reversing The Door

    Reversing the door The door can be changed from righthand-hinged to lefthand-hinged, or vice versa. To do so, proceed as follows: Models with solid door: 1. Switch off the power at the mains socket. 2. Dismantle the two screws that hold the control panel at front and back, pull the panel a little forward, and then tilt it upwards.
  • Page 12 The condenser fan air outlet above the compressor must be free of leaves, paper etc. to ensure normal operation of the cabinet. Cleansing agents containing chlorine or compounds of chlorine as well as other corrosive means, must not be used, as they might cause corrosion to the stainless panels of the cabinet and the evaporator system.

  • Page 13: Spare Parts

    There might be special requirements/conditions to be observed. You can obtain information on the disposal of refrigeration appliances from: Your supplier Arctiko A/S Authorities (The local council, Ministry of the Environment, etc.) Cabinet type number and serial number is stated Type on the name plate.
  • Page 14 Wire-diagram for PR 170 / PR 390 LED light strip Evaportor fan Compressor Trafo 230V/12V Trafo 230V/24V 230V Supply Alarm Alarm Connector Power Supply Display PCB Programming Connector GDL Connetctor Door switch Cabinet E-sensor Sensor Condenser Defrost Sensor Sensor...
  • Page 15 Wire-diagram for LR 170 / LR 310 / LR 390 Evaportor fan Compressor Trafo 230V/12V 220V Supply Alarm Alarm Connector Power Supply Display PCB Programming Connector GDL Connetctor Door switch Cabinet E-sensor Sensor Condenser Defrost Sensor Sensor...
  • Page 16 Wire-diagram for LF 140 / LF 340 Evaporator Drip tray Defrost Heater Heater Compressor Klixon Trafo Circuit breaker 20V/12V 230V Supply Alarm Alarm Power Supply Connector Display PCB Programming Connector GDL Connector Door switch Cabinet E-sensor Sensor Condenser Defrost Sensor Sensor...
  • Page 17 Notes:...
  • Page 18 Notes:...
  • Page 19 Notes:...
  • Page 20 WWW.ARCTIKO.COM LAMMEFJORDSVEJ 5 DK-6715 ESBJERG N DENMARK TEL. +45 70 20 03 28 +45 70 20 03 29 INFO@ARCTIKO.COM WWW.ARCTIKO.COM 50 80 03 -0 GB...
