EELEX 8000 USER MANUAL
EELEX 8000 USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EELEX 8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for X SHORE EELEX 8000

Summary of Contents for X SHORE EELEX 8000

  • Page 1 EELEX 8000 USER MANUAL EELEX 8000 USER MANUAL...

  • Page 2: Table Of Contents

    Recommended Safety Equipment Lifting and transporting Risk of Loss of Stability Lifting Risk of Flooding Transporting Through Hull Fittings including Seacocks Strainers System Descriptions Risk of Fire High voltage batteries Fire Fighting Equipment Response in case of malfunction X SHORE EELEX 8000...
  • Page 3 Black & Grey Water Hull / Exterior Household Waste Interior Noise Polishing and Waxing the Boat (Every 4 Months) Wash / Waves Cleaning Covers (2-3 Times a Year) Maintenance of Teak and Cork (Annually) Appendix Cork Repair X SHORE EELEX 8000...

  • Page 4: Welcome

    Ch. 1 Welcome Welcome This chapter introduces you to your boat and its basic handling. It provides an overview of your new boat This chapter introduces you to your boat and its basic handling. It provides an overview of your new boat and outlines your responsibilities as an owner.

  • Page 5: Get To Know Your Boat

    WELCOME Congratulations on your purchase of the X Shore Eelex 8000! Congratulations on your purchase of the X Shore Eelex 8000! This manual has been compiled to help you to operate your craft with safety and pleasure. It contains details of the craft, the equipment supplied or fitted, its systems and information on their operation, set up, maintenance, prevention of risks and management of those risks.
  • Page 6 6. Main Control Panel (MCP) with switches and fuses (behind console hatch) 12. Battery compartment hatch 100 NM 30 Knots 170 kW 8 m/ 26 ft 2.6 m /8.5 ft 0.8 / 2.6 ft Range Max Speed Electric motor Length Beam Depth X SHORE EELEX 8000...
  • Page 7 WELCOME Seating 10 passengers Eelex with sunbeds and sofas Eelex without modules X SHORE EELEX 8000...

  • Page 8: Quick Start Ui

    (or visit xshore.com/manuals) Compass and Home tab • Turn the start key. The screen starts up and the X Shore Infotainment interface appear on the right side of the touchscreen with the Home tab pre-selected. •...

  • Page 9: Responsibility

    Inspect the craft regularly especially after any kind of suspected damage. Always adjust 4. Ensure that the anticipated wind and sea the speed and direction of the craft to sea X SHORE EELEX 8000...

  • Page 10: About This Manual

    Ch. 2 About This Manual About This Manual Learn how to navigate this manual, including how to use and maintain the boat’s installed accessories, as Learn how to navigate this manual, including how to use and maintain the boat’s installed accessories, as well as how to understand the warnings provided for safe operation.

  • Page 11: Original Equipment Manufacturer (Oem) Manuals

    More detailed • Steering gear • Battery charger/monitor information regarding such equipment can • Navigation lights • VHF radio be found in manuals provided by the OEM. • Bilge pumps • Stereo components • Batteries X SHORE EELEX 8000...

  • Page 12: Saftey Labels

    Fuel fill point: letter ’D’ denotes suitability for diesel fuel Dedicated discharge opening for extinguisher Fuel fill point: letter ’P’ (or no letter) denotes suitability for Location of fire extinguisher petrol fuel Escape Sling position for safe lifting of the vessel X SHORE EELEX 8000...

  • Page 13: Explanation Of Warnings

    Caution Do not remove or obstruct any safety label. Replace any label which becomes illegible. If you need a new label, contact X Shore or your local X Shore distributor. X SHORE EELEX 8000...
  • Page 14 • Hatch upper bow step • Console hatch • Hatch lower • Anchor hatch bow step • Rudder hatch Location Description Deck next to helm and charging Warning socket Electrical shock and fire hazard when charging. X SHORE EELEX 8000...
  • Page 15 Look out for people in water Warning • Check weather forecast • Wear safety lanyard • Do not operate when under influence • Wear a life jacket • Drive and navigate safely • Observe driver’s visibility • Read the owner’s manual X SHORE EELEX 8000...

  • Page 16: General Arrangement

    Ch. 3 General Arrangement General Arrangement Detailed descriptions of the boat’s layout and its main specifications, such as hull dimensions, engine Detailed descriptions of the boat’s layout and its main specifications, such as hull dimensions, engine power, weight, and the capacity of various tanks. power, weight, and the capacity of various tanks.

  • Page 17: Boat Identification & Ce Marking Classification

    Depending on characteristics. A watercraft given design category C is atmospheric conditions, winds can gust to considered to be designed to operate in about 18 m/s. X SHORE EELEX 8000...

  • Page 18: Principal Dimensions

    Air draft: max. 2,75 m 9 ft 0.3 in Maximum Recommended Power Power measurement to EN ISO 8665 Marine propulsion engines and systems - Power measurements and declarations Horsepower 231 hp (metric) 228 hp (imperial) Kilowatts (kW) X SHORE EELEX 8000...

  • Page 19: Weights

    2274.27 m EC The boat in the 'empty craft condition' has a mass of 1700 3747.86 m LCC Unladen weight (lightcraft) including engine 2940 6481.61 m LDC Weight Fully Laden 3972 8757.68 Lifting Weight 3000 6613.87 X SHORE EELEX 8000...
  • Page 20 The outer skin of the craft is strong enough to resist the design ensure good operation. pressure but not local damage from hitting hard/sharp objects. If the outer skin is damaged, it shall be repaired immediately. X SHORE EELEX 8000...

  • Page 21: Lifting And Transporting

    Check and determine applicability of federal, state, or local 3. Check the boat ́ s lift points, weights and other information. requirements. 4. Straddle lift operation is highly technical and requires trained 2. Follow the lift equipment manufacturer’s requirements and operators. recommendations. X SHORE EELEX 8000...
  • Page 22 The position of the slings may need to be adjusted Note the location of the log transducer to avoid damaging it. depending on how the boat is loaded. Protect the hull sides well to avoid damages. X SHORE EELEX 8000...

  • Page 23: Transporting

    The hull of the boat can be sufficient to also carry the weight of the engine, fuel and damaged if the boat swings against a single support during equipment. transport. X SHORE EELEX 8000...

  • Page 24: System Descriptions

    Ch. 4 System Descriptions System Descriptions An overview of all major onboard systems, from bilge pumps to electrical systems, fuel systems, and more. An overview of all major onboard systems, from bilge pumps to electrical systems, fuel systems, and more. This section explains how each system functions and interacts with other parts of the boat.

  • Page 25: High Voltage Batteries

    Caution Any work on the HV batteries is strictly forbidden without permission from X Shore. The battery performance is largely affected by the battery temperature. For operation, the optimal battery temperature range is 15-35 °C (59–95 °F).
  • Page 26 Technical Support. We are happy to answer your questions and look forward Email info@xshore.com to your feedback. You can reach our Technical Support during our Hours 9.00-17.00 (Sweden Time CET) business hours. X SHORE EELEX 8000...
  • Page 27 Work on the HV battery may only be The training includes: • Check that the HV battery is intact and carried out by X Shore employees or, after manual service disconnect (MSD) is • safety regulations consultation with X Shore, by qualified removed when working on the batteries.
  • Page 28 (e.g., sea water). The battery X SHORE EELEX 8000...

  • Page 29: Response In Case Of Malfunction

    Avoid skin contact All components in the fluid circuit must be Technical Support. with the electrolyte and inhalation of escaping compatible with the dielectric Shell Thermal gases caused by chemical reactions. Fluid E5 TM 410. X SHORE EELEX 8000...
  • Page 30 HV battery must not be used or opened to avoid injury or • Immediately inform the responsible safety specialists/emergency damage. services (fire prevention officer/fire service). • For further information please contact our Technical Support without delay. X SHORE EELEX 8000...

  • Page 31: Storage

    Risk of damage to the HV battery! Storing the battery outside the temperature and state of charge limits for storage may cause accelerated aging of the battery and may lead to damage to the HV battery. X SHORE EELEX 8000...

  • Page 32: Charging During Storage

    Pumps When the boat is out of the water, make sure to disable the sea water pumps. This is done by flipping toggling Land Mode ON in the X Shore Interface Pumps Tab under Seawater pumps. When the boat is launched again, make sure to enable the sea water pumps by switching to Land Mode OFF.

  • Page 33: Disposal

    Disposal The HV battery must be classified as disposal in accordance with the applicable X Shore and/or to dispose of it with a qualified hazardous waste in case of a complete country-specific guidelines. specialist company. In the event of a justified...

  • Page 34: Inspections

    Check the degassing unit for contamination. Remove dirt with a clean and dry cloth. Every month during operation • Check the degree of contamination of the dielectric fluid. Change a contaminated dielectric fluid at room temperature. If dirty, contact our Technical Support. X SHORE EELEX 8000...

  • Page 35: Electrical System

    Voltage Rating Battery Location Disconnect Switch Main 12V 75Ah Under deck midship Inside console Main 12V 75Ah Under deck midship Inside console The battery selector switch is located at: Console Main DC Panel Board Location: Helm X SHORE EELEX 8000...

  • Page 36: Main Components Of The Electrical System

    USB chargers and 12V outlets (in front 10. 12V batteries (PDU), Inverter, OBC and EVCC deck compartment and in glove 11. Charge port for 400V batteries (on side of compartment) 4. DCDC console) 8. Thermal management system pumps X SHORE EELEX 8000...
  • Page 37 Position Description Blade fuse boxes, se following page for details Stern thruster 250A fuse and power switch (X Shore Pro option) Bow thruster 250A fuse and power switch Console manual reset circuit breaker 150A for electronics in the steering console...
  • Page 38 SYSTEM DESCRIPTIONS X Shore Eelex Specification of the fuses in the Fuse boxes on the Main Control Panel Position Fuse Amperage Work lights side left Critical power (VCU + Ignition + Start) Work lights side right Navigation light (front) Radar...
  • Page 39 SYSTEM DESCRIPTIONS X SHORE EELEX 8000...

  • Page 40: Battery Disconnection

    Essential service such as electric bilge pumps are wired directly to the batteries and will run even if the battery disconnect switch is open. X SHORE EELEX 8000...

  • Page 41: Battery Maintenance

    Steering System Steering System Notice The boat’s steering system has the following components Steering Hardware: Wheel Turning Device: Rudder Mechanism: Hydraulic The craft is fitted with the following steering position(s): Primary: Main steering position behind console X SHORE EELEX 8000...
  • Page 42 Refer to the maintenance section of this manual for further Caution details. A kill-chord is provided at the helm so that the engine will cut- out when pulled. The helmsman should connect him/herself to the kill-chord when the engine is running. X SHORE EELEX 8000...
  • Page 43 The safety of the boat depends on effective steering, so the oil level in the pump should be checked before casting off. Hydraulic oil is added to the steering system via the filling plug in the steering wheel pump. The oil level must be approx. 10 mm below the filler hole. Read the manufacturers manual for oil recommendation for the steering system. X SHORE EELEX 8000...

  • Page 44: Starting And Powering Off

    Start up Turn the key Access the X Shore app via the phone on https://app.xshore.net 2. When the screen lights up and the X Shore interface has loaded 2. Authenticate yourself the system is powered on 3. Then unlock the boat.

  • Page 45: Emergency Steering Arrangements

    Be aware that vision from the emergency steering position may The tiller will not be able to turn the stock unless the hydraulic be restricted. Ensure that a lookout is posted at all times. system has been ”by-passed”. See point two above. X SHORE EELEX 8000...

  • Page 46: Thrusters

    The craft is fitted with thrusters as follows: Thruster Power Source Electric These units are controlled by joystick from the steering position. Caution Ensure the joysticks are in neutral to prevent the thrusters from running when not required. X SHORE EELEX 8000...

  • Page 47: Bilge Pumps

    If seacocks are fitted in the fore and aft against accidental loss. normal. Large amounts of water or any signs peak bulkheads, they shall be kept closed and Warning Never use flammable solvents (i.e. kerosene) for bilge cleaning, however oily it becomes. X SHORE EELEX 8000...

  • Page 48: Pre-Launch Observations

    Ch. 5 Pre-Launch Observations Pre-Launch Observations Essential reading before departure, covering everything from safety equipment to potential hazards such Essential reading before departure, covering everything from safety equipment to potential hazards such as loss of stability, water ingress, and fire risk. as loss of stability, water ingress, and fire risk.

  • Page 49: Recommended Safety Equipment

    3. Compass 13. Knife in protective sheath 8. Bucket 4. Charts 14. Drinking water 9. A 10-mm Allen key 5. Anchor and line 10. Distress flares 6. At least 2 warps - see section Navigation & X SHORE EELEX 8000...

  • Page 50: Risk Of Loss Of Stability

    The following comments should be observed when navigating: Caution Breaking waves are a serious stability hazard The stability of the boat is further reduced when bringing your catch on board if you handle fishing rods or nets outboard. X SHORE EELEX 8000...

  • Page 51: Risk Of Flooding

    In addition, it is recommended that all but drains & bilge discharges are closed when the craft is to be left unattended. Ref. Description Location Means of Closure cooling water intake On stbd side under aft deck hatch valve cooling water outlet On stbd side on transom valve X SHORE EELEX 8000...

  • Page 52: Strainers

    (shut off valves, switches) • smoke while handling fuel or gas • stow combustible material in engine space. If other items are • use gas lights in craft stowed in engine space, secure against movement X SHORE EELEX 8000...

  • Page 53: Fire Fighting Equipment

    Open designated vent Never store petrol in an area not designed to store petrol openings while appliances are in use. Never obstruct ventilation openings and ensure that flued appliances are operating correctly. X SHORE EELEX 8000...

  • Page 54: Risk Of Falling Overboard

    Most slips and falls occur during boarding and disembarking. not pushed under the platform if the vessel is pitching. Consider Be aware that wet decks can be slippery. Wear slip resistant recovery by use of a dinghy if necessary. footwear at all times. X SHORE EELEX 8000...

  • Page 55: Liferaft Stowage

    X SHORE EELEX 8000...

  • Page 56: Navigation & Operation

    Ch. 6 Navigation & Operation Navigation & Operation Instructions for safely navigating and operating your boat, including tips on engine use, manoeuvring, Instructions for safely navigating and operating your boat, including tips on engine use, manoeuvring, and guidance on visibility and lighting requirements. and guidance on visibility and lighting requirements.

  • Page 57: Use Of Engines

    Avoid placing flammable materials on or near hot parts. Charging Charging The charge port The charge port is located on the starboard side of the steering console. Before charging, dock the boat securely to ensure the charge cable easily reaches the charge port. X SHORE EELEX 8000...

  • Page 58: Plugging In

    Stop Charging Stop charging at any time by pressing the sleep/wake button or the button in the X Shore Interface on the touch screen. This will release the charger and discontinue the charging process. To prevent unauthorized unplugging of the charge cable, the cable latch remains locked and the boat system must be engaged via the key before you can disconnect the charge cable.

  • Page 59: Handling Characteristics

    Ensure all crew are informed about the craft’s behaviour. X SHORE EELEX 8000...

  • Page 60: Visibility From The Main Steering Position

    When the boat of the console. navigation lights. is moving, all navigation lights must be on (both the all-round light and the sidelights). Notice Night boating requires running lights. The craft is fitted with the following navigation lights: X SHORE EELEX 8000...

  • Page 61: Anchoring, Mooring & Towing

    It is recommended that the chain be tied onto a local strong point. Caution The breaking strength of lines / chains should not exceed 80% of the breaking strength of the strong point to which it is attached. X SHORE EELEX 8000...

  • Page 62: Maintenance & Service

    Ch. 7 Maintenance & Service Maintenance & Service Advice and guidelines for regular boat maintenance to ensure its long-term performance and safety, Advice and guidelines for regular boat maintenance to ensure its long-term performance and safety, including seasonal upkeep such as winter storage. including seasonal upkeep such as winter storage.
  • Page 63 Modifications that may affect the safety characteristics of the craft should be assessed, executed and documented by competent people. Any change in the disposition of the masses aboard may significantly affect the stability, trim and performance of the boat X SHORE EELEX 8000...
  • Page 64 Zinc anodes Check and replace As needed Hull Check for loose, damaged or missing Whenever out of the water and always after striking an object Controls Steering Check for proper operation Electrical Connections Check for looseness X SHORE EELEX 8000...
  • Page 65 Inspect and replace if signs of deterioration, visible Non-metallic strong points surface cracks or permanent deformation. Topside & Fittings Check for loose, damaged or missing Closing appliances Installed and tight Gearbox Fluid level Check level Fluid Replace X SHORE EELEX 8000...

  • Page 66: Hull / Exterior

    Polishing and Waxing the Boat (Every 4 Months) If your boat is in continuous use, the hull should be polished and waxed at least every four months to maintain its appearance and value. More frequent polishing may be required depending on operating conditions. X SHORE EELEX 8000...

  • Page 67: Cleaning Covers (2-3 Times A Year)

    2. Apply a thick layer of boiled linseed oil, reapplying as long as it absorbs. 3. Allow to sit for an hour, ensuring no sticky residue remains. 4. Wipe off excess oil and let dry completely. Note: Spread out oil-soaked rags to dry to prevent fire hazards. X SHORE EELEX 8000...

  • Page 68: Anodes (Regular Inspection)

    4. Securely tighten the screws. Worn propeller anode Cooling System Maintenance Cooling System Maintenance Your X Shore 8000 has two separate cooling systems: 1. Battery Cooling system: Uses Shell Thermal Fluid E5 TM 410 (clear color). 2. Drive Train Cooling System: Uses Motorex Glycol Coolant M4.0 Ready-to-Use (pink color).

  • Page 69: Checking Coolant Levels (Every 2 Months)

    Your vessel has three seawater filters. Open the lid, remove the mesh filter, and rinse it with fresh water. Gelcoat Repair Gelcoat Repair Sand out deep scratches and clean with acetone. 2. Fill with polyester resin filler. 3. Wet sand with 800 and 1500 grit sandpaper. 4. Clean with acetone before applying gelcoat. X SHORE EELEX 8000...

  • Page 70: Steering System Check (Annually)

    Your boat and the systems and fittings on board can be damaged if they are not properly prepared for the winter. You should refer to the advice given in the various handbooks supplied with this manual. X shore recommendations Wash the hull and interior thoroughly. 3. Drain bilge and seawater pumps. 2. Store cushions in a dry location. 4. Activate ”land mode.” X SHORE EELEX 8000...

  • Page 71: General Recommendations

    Check all terminals for corrosion - corroded terminals and connectors should be replaced or thoroughly cleaned. Power feeds for accessory equipment must not be taken from the voltmeter terminals. Tighten all terminals securely and spray them with light marine preservative oil X SHORE EELEX 8000...

  • Page 72: Environmental Awareness

    Ch. 8 Environmental Awareness Environmental Awareness Tips and best practices for minimising your boat’s environmental impact, from managing spills to Tips and best practices for minimising your boat’s environmental impact, from managing spills to reducing noise levels and emissions. reducing noise levels and emissions.

  • Page 73: Black & Grey Water

    It is the responsibility of the boat user to ensure that they are aware of local legislation regarding discharge X SHORE EELEX 8000...

  • Page 74: Household Waste

    Adapt your speed to the water in which you are navigating. Consider the comfort and safety of other (particularly small) boats around you. Caution Be aware that in some areas speed restrictions are in place to avoid erosion of banks/coastline. X SHORE EELEX 8000...

  • Page 75: Appendix

    Ch. 9 Appendix Appendix Additional information and resources supporting the main text of the manual, including technical Additional information and resources supporting the main text of the manual, including technical specifications and reference material. specifications and reference material.
  • Page 76 -LV_BATT_2 -LV_BATT_1 DC - High Voltage (+) DC - High Voltage (-) DC - Low Voltage (+) DC - Low Voltage (-) (GND) -POS_BUSBAR 50-RD 50-RD 4-RD Bilge Pump Circuit Stern_Thruster_SW -Stern_Thruster1 -Stern_Thruster_Controller 50-RD 50-RD 50-BK Bow_Thruster_SW -Bow_Thruster -Bow_Thruster_Controller 50-RD 50-RD TO Power Relay-K30 (Main Power) 50-BK...
  • Page 77 X Shore strives to keep the contents of this manual accurate and up to date. For updates, please visit xshore.com The content of this manual is the property of X Shore and is protected by copyright. Copying or any other use without permission from X Shore is prohibited.
